Camco 43953 Manual

RV
Screen Door Opener
Makes getting out easier!
Open your screen door • Keep your slide closed • Leave bugs outside
Installation Instructions:
Parts
Grommet
Latch
Exterior
DRILL HERE
DON'T
DRILL
HERE
1. Choose location to install Screen Door Opener:
a. From outside, close screen door and slide.
b. Mark location to drill on exterior side of slide.
c. When slide is closed completely, hole should be
centered directly above screen door handle
(see figure 1).
d. Hole must be drilled on flat area (do not mark or drill
through bend or angle in slide (see figure 1).
e. Carefully drill hole with 9/16" bit
(recommend drilling smaller pilot hole first).
Our return policy is limited to the replacement of original purchase. No
other liability, responsibility or warranty is expressed or implied,
including any regarding merchantability or suitability for a particular
purpose. Our return policy is limited to the replacement of original
purchase. No other liability, responsibility or warranty is expressed
or implied, including any regarding merchantability or suitability for a
particular purpose.
Endcap
Assembled
Will not work with
Airstream™ doors*
Interior
Tools Needed
*Airstream is a trademark
of Airstream Inc.
Exterior
2. Gently ease endcap and grommet off latch.
3. From interior side of screen door, insert grommet into
drilled hole with grommet hole angled downward
(see figure 2).
4. Slide latch through hole and reattach endcap
(see figure 3).
5. Adjust latch until it moves up and down freely when
exterior RV door is closed (see figure 4). If desired,
add 1 drop super glue between latch and grommet to
permanently fix location.
Drill and 9/16" bit
Side
View
Camco Manufacturing Inc.
121 Landmark Dr. / Greensboro, NC 27409
1-800-334-2004 / www.camco.net
z885066
