Camco POWER GRIP 55343 Manual

Instructions for 30A Connector Body – NEMA TT-30:
Disconnect power
before wiring
NOTE: Select wire size adequate for load. Refer to NEC tables article 400.
CORD TYPE: S, SJ, SJO, SO, ST, STO; 0.94-in max cord diameter.
WIRE SIZE: #10 through #12 AWG
IMPORTANT: Use copper wire only. Do not solder the ends of the wire.
0.625"
WHITE
0.75"
3"
1.75"
GREEN
BLACK
"
3 /
4
FIG. 1
3"
1 / "
WaRNING: DISCONNECT POWER BEFORE WIRING. FAILURE TO WIRE 7
8
/ "
5
8
AS INSTRUCTED MAY CAUSE PERSONAL INJURY OR DAMAGE TO
DEVICE OR EQUIPMENT. MUST BE INSTALLED BY AN ELECTRICIAN OR
QUALIFIED PERSON ONLY. DO NOT USE AT ANY TIME IF HOUSING IS
BLACK
CHIPPED, CRACKED OR BROKEN.
Camco Manufacturing, Inc.
121 Landmark Dr. / Greensboro, NC 27409
1-800-334-2004 / www.camco.net
GREEN
RD
30
Sturdy handle for easy removal
3"
1
/ "
3
4
BLACK
GREEN
BLACK
"
5 /
3"
8
1 "
/
7
8
/ "
5
8
1 / "
1
4
GREEN
WHITE
FIG. 2
BLACK
RED
"
5 /
8
G
1 / "
1
X
4
WHITE
RED
W
This product is guaranteed to be free from
defects in material or workmanship under NEMA 14-50
normal use and service conditions for 1
year after the date of purchase. Our liability
GREEN
is limited solely to the replacement of any GR
defective product returned to us. We make no
other warranty, either expressed or implied,
RD
including any regarding merchantability or
suitability for a particular purpose, nor do
we assume any liability or responsibility for
WH
incidental or consequential damages resulting
z885523 WHITE
from the use of this product.
GR
RED
BK
amp Replacement female connector body with handle
1. Strip cable and wire sheath as shown in Fig. 1. Inspect wire sheath
for nicks (cut and re-strip all if nicked).
2. Remove the Cover from the Replacement Connector Body.
3. Remove the Strain Relief Clamp from the Replacement Connector
Body.
4. Raise terminal to access screw and clamping pole.
NEMA TT-30
5. Back set screws out of terminals to allow an opening large enough
to insert copper wire. As each wire is placed into position, tighten
the set screw to secure the wire in place as shown in Fig. 2. Make
sure that all individual copper strands of each wire are completely
inside of each terminal (twist strands together if needed). Start with
the white wire first.
a. White wire (neutral) to top-right terminal
/ "
3
4
b. Black wire (hot) to top-left terminal
c. Green wire (ground) to bottom-center terminal
GREEN
6. Make sure wires do not interfere with screw holes or other mating
surfaces and then replace the Cover and secure with the three screws
"
5 /
8
" provided.
7 /
8
"
5 /
8
WHITE 7. Determine the cable size and configure the Strain Relief Clamp
1 / "
1
4
GREEN
appropriately.
a. For cord sizes 0.37 to 0.59-in diameter (includes flat cables):
WHITE
RED Use Strain Relief Clamp with Insert oriented as shown in Fig.3.
G
b. For cord sizes 0.59 to 0.75-in diameter: Use Strain Relief Clamp
STRAIN with Insert oriented as shown in Fig.4.
X
RELIEF
CLAMP
c. For cord sizes 0.75 to 0.94-in diameter: Use Strain Relief Clamp
with Insert oriented as shown in Fig.5.
W
8. Fasten the Strain Relief Clamp to the body with the two screws
provided.*
NEMA 14-50
Y
WHITE
* If the strain relief clamp does not appear to have a secure grip on the
GREEN
GR
cord, remove clamp and apply five wraps of electrical tape to the cord
in the area of the clamp grip. Reattach clamp. If grip is still not secure,
RD BK
repeat until secure.
----------------------------- Strain Relief Clamp -------------------------
WH
WHITE
RED
BK
BLACK
STRAIN
RELIEF
Heavy duty construction
G
X
Y
W
G
Y
NEMA 14-50
W
G
NEMA TT-30P
3"
W
NEMA TT-30P
BLACK
BLACK
FIG. 3
GREEN
Accepts a 30 amp plug
G
W
GREEN
NEMA TT-30P
3"
1 / "
3
4
1"
GREEN
BLACK
1"
1 / "
3
4
WHITE
GREEN
FIG. 4 FIG. 5
BLACK
GR
3
G
B
GR
BK WH
