VideoMate U750F TV Box Connectors
Name
Function
FM
FM Connector
TV
TV Connector
USB
USB Connector
Name
POWER
Power Connector
COMP IN
Composite video in
SVID IN
S-Video input connector
LINE IN
Stereo sound input
connector
4
BOX Back View
FM signal input
TV signal input
To connect TV BOX and the PC with USB 2.0 cable
BOX Side View
Function
Description
Description
USB bus power (reserved)
Composite video in connector, can
connect to DVD, V8, Video Recorder
Video input connector can connect to
video recorder, DVD, V8
Sound input connector can connect to
video recorder, DVD, V8
