SierraTeck WT0102PO1 Quick Start Manual

This guide will help you hit the ground running in no
time!
Red LED Indictor
Working Mode
Playing On (steady) while playing
audio
Low charge/power Flashes 4 times after audio
playback
Charging or Flashes slowly
connected to
computer
Full Charge Flashed 2 times every 5
seconds
(when connected to
power)
Button Function
Button Name Operation
On/Off Button Pull Up/Down
Short Press
Button A
Hold for 3
seconds
Short Press
Button B Hold for 3
seconds
Volume Dial Dial up or
down
STEP 1: Charging:
 Use USB power cord to recharge or keep plugged-
in to use directly from outlet. Recharge from
empty will take up to 4 hours
STEP 2: Adding Audio
 Use a Windows-based PC only to write MP3 audio
to the device. Ensure only MP3 files are used.
Non-MP3 files will prevent proper operation. All
files must be in the root directory and not in
folders/sub-folders.

Do not use MACs/iOS devices, as they often leave
hidden non-MP3 files on memory, which will
prevent the device from functioning properly
Important:

Total size of audio file(s) must be less than 4MB to fit
onto the device

To transfer audio files, use the USB cable provided or
any other micro-USB data cable.

STEP 3: Select Playback Mode
Status
Play a single file every time



Play multiple files in sequence


Function
Turn on/off
Previous
STEP 5: Attach to Wall
Sequence Play
Back Mode

Next
Single File Play

Back Mode
Increase or
decrease
volume



If there is any way we can assist or if you've
encountered any issues whatsoever, please email us,
we are here to help and make sure you are 100%
satisfied.
There is approximately 1 second lag between motion
detection and playback
With device on, press and hold button "B" and
release when the indictor light starts flashing
Now, use buttons "A" and "B" to go to the file you
want and stop there. The file you stop at is the
one selected to be played back every time.
If you later press "A" or "B" again, it will select a
new file to playback again
With device on, press and hold button "A" until
indictor starts flashing
Playback will now be in the same sequence as
written to memory, see full user guide for more
details
Using the 2 screws provided, attach unit to wall
either directly or using ball mount supplied
Regardless of method chosen, only bottom 2
screw holes at back of unit are used, upper ones
are unused
IMPORTANT:
We test all units after manufacturing by pre-placing
audio onto the device. This is normal and does not
indicate unit is used
To avoid false triggers, do not install in areas that
have direct sunlight, areas with large temperature
variation, or near air conditioners and heaters.
For indoor use. External use may result in moisture
damaging internals of device and void warranty
