Winjet WJ20-0003 User Manual

Headlights

Download this manual

USER MANUAL

Model.: WJ20-0003

Chevy Blazer 1992-1994

Chevy c1500 Pickup 1988-1999

Chevy c1500 Suburban 1992-1999

Chevy c2500 Pickup 1988-2000

Chevy c2500 Suburban 1992-1999

Chevy c3500 Pickup 1988-2000

Chevy k1500 Pickup 1988-1999

Chevy k1500 Suburban 1992-1999

Chevy k2500 Pickup 1988-2000

Chevy k2500 Suburban 1992-1999

Chevy k3500 Pickup 1988-2000

Chevy Tahoe 1995-2000

HEADLIGHTS

Gmc c1500 Pickup 1988-1999

Gmc c1500 Suburban 1992-1999

Gmc c2500 Pickup 1988-2000

Gmc c2500 Suburban 1992-1999

Gmc c3500 Pickup 1988-2000

Gmc k1500 Pickup 1988-1999

Gmc k1500 Suburban 1992-1999

Gmc k2500 Pickup 1988-2000

Gmc k2500 Suburban 1992-1999

Gmc k3500 1988-2000

Gmc k3500 Pickup 1998

Gmc Yukon 1992-1999

Need help?

Do you have a question about the WJ20-0003 and is the answer not in the manual?

Page 1 USER MANUAL HEADLIGHTS Model.: WJ20-0003 Chevy Blazer 1992-1994 Gmc c1500 Pickup 1988-1999 Chevy c1500 Pickup 1988-1999 Gmc c1500 Suburban 1992-1999 Chevy c1500 Suburban 1992-1999 Gmc c2500 Pickup 1988-2000 Gmc c2500 Suburban 1992-1999 Chevy c2500 Pickup 1988-2000 Chevy c2500 Suburban 1992-1999...
Page 2: Required Tools
REQUIRED TOOLS Socket Ratchet lineman Pliers Installation Instructions 2. Remove the four phillips screw to remove the parking lights. 3. Remove the parking lights from the vehicle. 4. Twist off the parking light bulb sockets. 6. Repeat the steps 1~5 for the other side. 2pcs Bolts...
Page 3 4pcs Bolts 2pcs Bolts 9. Pull the grill away from the vehicle. 10. Twist off the corner light socket from the grill. 11. Remove the four 10mm screws holding 12. Pull the headlight away from the vehicle. in the headlight assembly. 13.
Page 4 17. Plug in the wire harness socket for the new Wolfstorm head light. 4pcs Bolts 20. Put the connector on the black wire of 21. Use pliers if you need to. low beam and black wire of DRL, squeeze it along those two wires.
Page 5 22. Put the connector on the red wire of low beam and brown wire, squeeze it. high beam light low beam light 26. Repeat the steps 11~25 for the other side. 27. Reinstall the original removed parts and bolts.
