Thank you for purchasing the XCQQ smart bidet toilet seat.
Please ensure that you read the instruction manual prior to using the product and store it in a
secure location for future reference.
Instruction Manual
SMART BIDET TOILET SEAT
S9BL
(Panel Control)
ATTENTION
When installation, please make sure to open the water supply valve first, wait 3-5
minutes for the water to fill the bidet, then plug it.
When the power is activated the LED light will start to blink, the spray bar will
automatically extend (without spray) and the water will flow down the bar into the
toilet. This is the unit performing a water spray check.
Stop blinking the LED light (blue night light): If the LED light blinks continuously
for more than 5 minutes, please unplug the bidet and turn off the water valve. Turn
on the water valve first, wait 3-5 minutes, then plug it and do not operate any
functions. The blue light will stop blinking in 1 minute.
S9BR
(Panel Control)
Advertisement
Related Manuals for XCQQ S9BL
Summary of Contents for XCQQ S9BL
- Page 1 (without spray) and the water will flow down the bar into the toilet. This is the unit performing a water spray check. Thank you for purchasing the XCQQ smart bidet toilet seat. Stop blinking the LED light (blue night light): If the LED light blinks continuously Please ensure that you read the instruction manual prior to using the product and store it in a for more than 5 minutes, please unplug the bidet and turn off the water valve.
- Page 2 Safety precautions Be sure to carefully read this "Saftety Precautions" document before beginning installation. Please comply with all safety warnings and cautions! Meaning Symbol TABLE OF CONTENT Warns you how to avoid causing personal injury. Indicates that there are actions you must follow or avoid to prevent damage to this unit or other items.
- Page 3 Do not dispose of lit cigarettes or any other combustible materials in the bidet Avoid sitting on the heated toilet seat for extended periods. toilet seat. • Doing this may result in low-temperature burns. • The guardian should turn off the toilet seat heating function to prevent the following •...
- Page 4 Parts Names CAUTION If the unit is not to be used for an extended period of time, close the water supply LED display screen valve and drain all water from the main unit, pipe and hose. When using the unit again, allow the main unit, pipe and hose of the unit to fill with water and then use the cleaning function several times to drain off the water.
- Page 5 Installation Installation a. Remove the original toilet seat and fixing fittings and clean the bolt holes and toilet bowl of stains. Precautions before installation b. Press the rubber expansion screws firmly into the toilet bolt holes. Align the fixing plate and metal 1.
- Page 6 Trial operation Installation Connection of water pipe and hose 1. Please make sure to open the water supply valve first, wait 3-5 minutes for the water to fill the bidet, then plug it. Otherwise the LED light will blink as a reminder. 2.
- Page 7 Press this button to adjust the water position during toilet seat. cleaning. There are 4 adjustable levels: forward 2nd gear The S9BL / S9BR side panel model emits a beep, and the button illuminates adjustment and backward 2nd gear adjustment. blue to indicate that ECO mode is activated.
- Page 8 Maintenance Non-use over a long period Unit cleaning In the following cases, turn off the water inlet valve and power supply, and drain the water from the hose and bidet toilet seat tank: 1. In cold areas, water may freeze. Clean the surface with a damp, soft cloth.
- Page 9 Trouble Shooting Trouble Shooting Type Trouble Causes Solution Type Trouble Causes Solution Some cold water Inlet water too cold Close the water supply valve LED night light keep The water's not full in Unplug the power supply, open the before spraying warm due to the low appropriately to reduce the water blinking, water does...
- Page 10 Technical parameter Specification S9BL S9BR Power Rating AC 110V-127V, 60Hz, 1300W-1500W Inlet Water Temperature ℉ - ℉ Inlet Water Inlet Water Pressure 0.05 - 0.75Mpa Adjustable 4 Levels Warm Water Temperature Actual water temperature, 91℉, 97℉, 102℉ Wash Device Heater...
