Aries Offroad 2049 Installation Instructions

01-02 Toyota Tacoma 4WD / 2 WD Pre-Runner
Parts List
2 – Frame Mounting Brackets
4 – 7/16 x 1 ¼ Hex Bolts
6 – 7/16 Hex Nuts
2 – 3/8 x 1" Button Bolts
2 – 3/8 Flat Washers
Installing Front Bar
1. Remove tie down from bottom of driver side frame rail.
2. Using bolts from tie down, attach driver side frame bracket to bottom of frame.
Do not secure.
3. Remove tow hook and tie down from bottom passenger side frame rail.
4. Using bolts, along with tow hook, removed in step 3, attach passenger side frame
bracket to bottom of frame. Do not secure.
5. Attach the front bar assembly to the outside of lower frame brackets, using the
7/16 x 1 ¼ hex bolts, 7/16 hex nuts and washers.
6. Align front bar assembly with front of vehicle and secure all bolts and nuts.
Mount in this direction
Installation Instructions
Front Bar Part # 2049
Driver Side Mounting Bracket Shown
2 – top support brackets
2 – 7/16 x 3 ½ Hex bolts
12 – 7/16 Flat washers
2 – 3/8 Hex Nuts
NOTE: Should be outside
of skid plate
