SVBONY SV503 Assemble

/
SYBONY
Observation Discovery &Exploration
Astronomy Telescope 80/560 Assemhle Guider
For those who want to enjoy outdoor activities in the
garden,you deserve to have SV50380ED telescope.
SV50380ED telescope's objective lens features an S FPL-51
extra-low dispersion glass ED element,which virtually elimi-
nates chromatic aberration.This results in the great color cor-
rection for an ED doublet lens.
A thoroughly though-out design and high-quality mechanical
components.This very special SV503 telescope provides as-
trophotographers,visual observers or nature watchers with
bright,wide field views when observing starry skies or nature
watching.
SvBONY
1.2 inch to 1.25inch adapted
2.1:10 gear ratio
3.Metal hoop
(Three 1/4x20 screws hole on the hoop)
4.Telescope tube
5.80mm Objective lens
6.Adjusting nut
7.Dovetail(1/4 inch screw hole)
8.Dual focus wheel
1
FINDERSCOPE INSTALLATION
1.Metal hoop Three 1/4x20 screws hole on the hoop of the telescope on the top,
2.Connect the finderscope to the telescope through the 1/4x20 screws hole
INSTALLING THE DIAGONAL AND EVEPIECE
The diagonal is a prism that diverts the light at a right angle to the light path of the telescope.This
allows you to observe in a position that is more comfortable than if you had to look straight
through.
Need to buy a diagonal is an erect mage model that corrects the image to be right side
up and oriented correctly left-to-right which is much easier to use for terrestrial observing. Also,
the diagonal can be rotated to any position which is most favorable for you.To install the diagonal
and eyepiece:
1.The 2 inch telescope scope focuser coming with a 2 inch to 1.25 inch adapter.So that you could
also use your 1.25 inch diagona to work with the SV503 telescope.
2.Put the chrome barrel end of one of the eyepieces into the diagonal and tighten the
thumb screw.When doing this make sure the thumbscrew is not protruding into the
diagonal before inserting the eyepiece.
3.The eyepieces can be changed to other focal lengths by reversing the procedure in step 2
above.
ATTACHING THE TELESCOPE TUBE TO THE TRIPOD
The telescope optical tube attaches to the tripod by using the
mounting bracket on the bottom of the optical tube a
nd the mounting platform of the tripod.Before starting make
sure all of the knobs on the tripod are locked.
2
