Page 1: User Guide
TEL2 Slim Line Phone User guide Downloaded from: http://www.guardianalarms.net... - Page 2 FUNCTIONS 1 Loudspeaker 6 Volume controls 2 Hook switch 7 Redial button 3 Memory buttons (M1-M3) 8 Store/Mute button & indicator 4 Recall button 9 Digit buttons (0-9, *, # ) 5 Memory button...
-
Page 3: Wall Mounting
Lift the handset and check for dial tone. WALL MOUNTING The Audioline TEL2 can be wall mounted directly onto the standard wall plate or to the wall using the template (provided) and suitable screws (not provided). When wall mounting you will need to rotate the handset retaining clip (located on the cradle) 180 degrees to ensure the handset remains on the cradle. -
Page 4: Direct Memory
DIRECT MEMORY This telephone has 3 direct memories (item 3 on diagram M1-M3) where you can store phone numbers. When you have stored a number in the direct memory, you can dial that number by pressing only one button. Store direct memory: # Lift the handset # Press the button (ignore network tones) - Page 5 After that, the ring signal reverts to the previous setting. RECALL button can be used to access additional Network services and PBX [RECALL] functions. The Audioline TEL2 is pre-set to 100ms Time Break Recall for Australia and 600ms for New Zealand.
-
Page 6: Troubleshooting
TROUBLESHOOTING NO DIAL TONE Try the phone in a known good socket to establish whether the fault is with the phone or the line. PHONE DOES NOT RING Lift and replace the handset and reset the ringer to the previous setting. MEMORY NUMBERS NOT DIALLING CORRECTLY Repeat the memory storage procedure and retry. - Page 7 1 telephone to your telephone line. Your telephone line has a maximum REN capacity of 3 (RN of 5). Your Audioline TEL2 has a REN of 1 (RN of 1), thus it is feasible to connect 2 (4) more telephones of a value of 1 to your system. You should not exceed a value of 3 (5) on the complete system, otherwise the volume of the ringer in any phone will decrease and one telephone may not ring at all.
Need help?
Do you have a question about the TEL2 and is the answer not in the manual?
Questions and answers
erase phone memory
To erase a phone number from memory on the AUDIOLINE TEL2, store a new number in the same memory location. The new number will replace the old one. There is no separate erase function.
