- Page 1 USER MANUAL TRUE HEPA AIR PURIFIER READ AND SAVE THESE INSTRUCTIONS LIFETIME WARRANTY IF REPLACES THE FILTER ON TIME YOUR SATISFACTION IS OUR TOP CONCERN...
-
Page 2: Table Of Contents
Content Safety Information......................3 Package Contents......................4 Specification & Unique Features................5 Know Your Air Purifier....................7 How To Use........................10 How To Replace Filter....................13 Care & Maintenance..................... 15 Disposal and Recycling....................18 Tips to Buy Air Purifier....................18 Trouble Shooting......................19... -
Page 3: Safety Information
SAFETY INFORMATION To reduce the risk of fire, electric shock, or other injury, follow all instructions and safety guidelines. GENERAL SAFETY • Only use your air purifier as described in this manual. • Always place the air purifier on a firm, leveled surface. •... -
Page 4: Package Contents
WARNING • If the power adapter is damaged, please contact our customer service directly to replace with new replacement. • This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety. -
Page 5: Specification & Unique Features
SPECIFICATION & UNIQUE FEATURES Power Supply 100-240V 50/60hz Rated Power Temperature: Noise Level 22–58dB Operating Conditions 14°F– 104°F / - 10°C–40°C Humidity: < 85% RH GENUINE TRUE HEPA H13 FILTRATION SYSTEM TRUE HEPA H13 FILTRATION Removes up to 99.97% of airborne particles as small as 0.3 microns, such as allergens, pollen, dust, germs, pet dander, odor, mold spores, and smoke from the air that passes through the filter. - Page 6 PRE-FILTER Captures large particles such as dust, lint, fibers, hair, and pet fur.Maximizes the life of the True HERA Filter by protecting it. PROTECTIVE NET FILTER Air Quality Indicator This automatic sensor uses an infrared light to detect airborne particles and display the air quality with 4 colors. Blue Green Yellow...
-
Page 7: Know Your Air Purifier
KNOW YOUR AIR PURIFIER Front Back&Upside Down A: Control Panel B: Air Outlet C: Body Shell D: Air Inlet E: Air Quality Sensor Cover F: Power Adapter Interface G: Air Filter Cover H: H13 HEPA Filter Note: Filter and base are one-piece design. Upside Down... -
Page 8: Control Panel
CONTROL PANEL A: On/Off Button B: Sleep Mode Button C: Timer Button D: Filter Rest Button E: Fan Speed Button F: Air Quality Indicator LED DISPLAY... - Page 9 Sign Fan Speed Auto Mode Medium High Turbo(Top) Note: when time left over 1H, it will shows hours left; only when less than 1H, it will show minutes left. For example, if you choose 4H,it will show 4H on led display.When only 58minutes left, it will show 58M on led display.
-
Page 10: How To Use
HOW TO USE BEFORE TURNING THE UNIT ON Take the air purifier out of the box and remove the clear protective plastic bag. Open bottom filter cover to take filter out,then take the power adapter out.Finally put air filter back and lock filter cover. Place the air purifier on a firm, leveled surface. -
Page 11: Auto Mode
Switch Fan Speed This air purifier has 4 fan speed settings: F1- Low,F2- Medium,F3- High and F4- Turbo(Top). The higher the fan speed setting, the faster the air will be purified. To select or change fan speed, press the fan speed button until the desired setting is reached. -
Page 12: Sleep Mode
many minutes left. For example, if you choose 3H, led display will show 3H- 2H-59M-off. The air purifier will automatically power off once the timer is finished. If LED display does not show any timer, it means the timer function is not turned To cancel the timer at any time, press the timer button and hold it for 2 seconds. -
Page 13: How To Replace Filter
HOW TO REPLACE FILTER FILTER REPLACE INDICATOR For optimal performance, replace every 3,000 hours under normal usage conditions.The smart replace filter indicator illuminates when it is time to replace the True HEPA H13 filter based on the air purifier’s hours of use. - Page 14 Rotate the twist handle Take the old filter out counterclockwise to unlock Remove the new filter protective Tighten the filter buckle bag before installation.Place the clockwise until it clicks into place filter into the air purifier and install the base cover properly...
-
Page 15: Care & Maintenance
CARE & MAINTENANCE NOTE: For the best performance, vacuum the pre-filter once a month under normal usage. Cleaning the Air Purifier Wipe the outside of the air purifier with a dry cloth. Do not clean with water or any other liquid to avoid risk of electric shock. Clean the white side of the filter with a brush or vacuum hose each month to prevent buildup of hair or dust. - Page 16 3. Dry the sensor lens with a dry cotton swab. 4.Close the sensor cover. Storage If not using the air purifier for an extended period of time, wrap the filter in plastic packaging and store in a dry place to avoid moisture damage. When Should I Replace the Filter? The filter should be replaced every 6-8 months (3000h).
-
Page 17: Use Environment
Use Environment Moisture may damage the filter. This air purifier should be used in an area with a humidity level below 85% RH. If you use the air purifier in excessively humid areas, the surface of the filter will become moldy. Note: Water or moisture will allow mold to grow. -
Page 18: Disposal And Recycling
Disposal and Recycling This air purifier should be recycled as electronic waste and the filter recycled as plastic. Tips to Buy Air Purifier Clean Air Delivery Rate (CADR) Clean Air Delivery Rate (CADR) measures the efficiency of an air purifier by indicating the volume of clean air that an air purifier produces per minute. -
Page 19: Trouble Shooting
Filter failure-replace the Check if filter in correct Can't feel the effect filter. location Use in inappropriate Use in bedroom,living room places (excessive area) or other indoor places If your problem is not listed here, please contact our Customer Support. info@dayette.com...
