Summary of Contents for Martin Svensson Jules 91031
- Page 1 Assembly Instructions 91031 Jules 91032 Cassandra 91033 Orsay 91034 Marche 91035 Avalon For Service Concerns & Questions Please Call Us At 1-800-549-3300 1-10...
- Page 2 Two People Required 10 min Approxiamate space required Phillips Head 2-10...
- Page 3 A x 04 B x 04 C x 02 D x 02 Ø3.5x15 (mm) Ø4x30 (mm) ANTI-TIP SET 3-10...
- Page 4 EPE Foam Please lay all components on smooth flat surface to prevent scratches Use the EPE foam to protect the plastic hardware before assembly 4-10...
- Page 5 Open Lock Open Lock Make sure all latches are in the open position before installing 5-10 Bottom Panel (g)
- Page 6 Open Lock Open Lock Make sure all latches are in the open position before installing Top Panel (h) 6-10...
- Page 7 Lock Make sure all latches are in the locked position B x 4 A x 4 7-10...
- Page 8 C x 2 D x 2 8-10...
- Page 9 NOTE: As wall materials vary, screws for attaching to wall are not included. For advice on suitable screw systems, contact your local hardware / home improvement store. ANTI-TIP SET 9-10...
- Page 10 Wall 10-10...
