Installation 1. Attach the top panel to the bottom panel...
Page 7
Installation M3*5 countersunk screw 2. Fix the metal housing with M3*5 screws...
Page 8
Installation M3*5 countersunk screw 3. Use M3*5 countersunk screws to fix the side bracket to the housing...
Page 9
Installation 4. Plug the connector of the PoE HAT into the GPIO pins of the Raspberry Pi, slide the connected whole into the mounting plate, aligning the cutouts and screw holes. 5. Place the hex standoff in the middle of the Pi and HAT, and secure them to the mounting bracket with the long M2.5*25 screws.
Page 10
Installation The connection way is the only one. 6. Please connect the power button, OLED display, and SD card adapter according to the diagram. Wire for Display Wire for Power Button SD card Adapter SD card Adapter 7.Just push the 5 installed modules into the housing and simply tighten the loose-off...
Page 11
Then save and exit. Reboot to verify that the screen comes up on boot! NOTE: This script is only available for Raspberry Pi OS. For more scripts, check out our GitHub page: https://github.com/UCTRONICS/U6143_ssd1306, and we will keep online up-to-date continuously for other OSs.
Page 12
CONTACT US If any problem, feel free to contact us. Website: www.uctronics.com Email: support@uctronics.com metal...
