Bearing Type
*
Ball Bearings
Material
*
Impeller & Frame : Plastic (UL 94V-0)
Lead Wires :
*
UL 1571 AWG #28 OR Equivalent
Red Wire Positive (+)
Black Wire Negative (-)
Weight : 17g (0.60 oz)
*
MODEL
PART NO.
FUNCTION
BFB04512MD
-R00 / -F00
BFB04512HD
-R00 / -F00
BFB04512HHD -R00 / -F00
BFB04512VHD -R00 / -F00
* Function type is optional.
*
The max. air flow and the speed are measured in free air ; max. air pressure is measured at zero air flow.
*
Noise is measured in anechoic chamber in free air, one meter from intake side.
*
All readings are typical values at rated voltage.
*
Specifications are subject to change without notice.
BFB
DIMENSIONS DRAWING
P & Q CURVE
Operating
Rated
Input
Voltage
Voltage
Current
Range
VDC
VDC
Amp
12
5.0 to 13.8
0.07
12
5.0 to 13.8
0.10
12
5.0 to 13.8
0.13
12
5.0 to 13.8
0.15
45 x 45 x 20 MM SERIES
(AT RATED VOLTAGE)
Input
Speed
Power
3
Watt
R.P.M.
m /min
0.84
3300
0.120
1.20
3800
0.139
1.56
4200
0.161
1.80
4500
0.170
102
Maximum
Maximum
Air Flow
Air Pressure
CFM
mmH
O
IN H
2
4.24
6.83
0.269
4.91
9.29
0.366
5.68
12.95
0.510
6.01
14.15
0.557
http://www.deltaww.com
mm
UNIT:
(INCH)
Noise
O
dB-A
2
21.0
24.5
28.0
30.5
