Getting to Know your Pedestal Tower Fan
A.
Control Panel/Display
B.
Body
C.
Support Base Front
D.
Support Base Rear
E.
Exhaust Grille
F.
Carry Handle
G.
Air Intake Grille
H.
Remote Control
I.
Remote Control Storage
J.
Adjustment Nut
K.
Pipe
Easy 1-2-3 Assembly
1
D- Support Base Rear
C- Support Base Front
Align the slots on part D
with tabs on part C.
Snap Together.
Quick Start Guide
B
E
H
D
C
2
Loosen nut by turning
counterclockwise,
extend pipe up, then
tighten nut by turning
clockwise.
A
3
K- Pipe
Twist and push
lower pipe down
into base.
Model: EST100
F
I
G
K
J
4
B- Body
Twist and push head
assembly down
onto pipe.
