Delta Electronics AHB1748EH Dimensions And Installation Information

Bearing Type
*
Ball Bearings
Material
*
Impeller : Plastic (UL 94V-0)
Frame : Die-Cast Aluminum
Lead Wires :
*
UL 1007 AWG #24 OR Equivalent
Red Wire Positive (+)
Black Wire Negative (-)
Weight : 450g (15.87 oz)
*
MODEL
PART PART O. O. FUNCTION
AHB1748VH -R00 / -F00
AHB1748SH -R00 / -F00
AHB1748EH -R00 / -F00
* Function type is optional.
* The max. air flow and the speed are measured in free air ; max. air pressure is measured at zero air flow.
* Noise is measured in anechoic chamber in free air, one meter from intake side.
* All readings are typical values at rated voltage.
* Specifications are subject to change without notice.
AHB
DIMENSIONS DRAWING
P & Q CURVE
Operating
Input
Rated
Voltage
Current
Voltage
Range
VDC VDC Amp
48 32.0 to 80.0 0.37
48 32.0 to 80.0 0.43
48 32.0 to 80.0 0.52
172 x 25.4 MM SERIES
(AT RATED VOLTAGE)
O O
Input Maximum
Speed
Power Air Flow
3
m
Watt R.P.M. /min
17.76 3400 6.408
20.64 3700 7.059
24.96 4000 7.675
40
MOUNTING PANEL CUTOUT
OUTLET SIDE INLET SIDE
O O
Maximum
Air Pressure
CFM mmH O IN H O
2
2
226.31 13.62 0.536
249.27 16.10 0.634
271.05 18.69 0.736
http://www.deltaww.com
mm
UNIT:
(INCH)
O O
O O
mm
UNIT:
(INCH)
Noise
dB-A
56.0
59.0
61.0
