深 圳 市 诺 瓦 机 器 人 技 术 有 限 公 司
地址：深圳市宝安区松岗街道潭头社区芙蓉路中展科技园厂房二栋四层
Whale3 Super 14K Firmware Upgrade Operation Guide
IMPORTANT NOTES: Please make sure to follow the upgrade operation guide for the printer firmware
upgrade!
If you need the upgrade files and reference videos, please contact NOVA3D customer service.
Official Email: amzus@nova3dp.com
Prepare Work
1.
(1)Tools Preparation: Prepare a USB stick (2.0 interface) with a capacity of at least 4G. Ensure
the USB stick reads reliably.
Whale 3 Super 14K
(2)Confirm the Model of Printer:
(3) Machine Preparation: Adjust the machine cantilever to the middle height of the linear
guide.
Advertisement
Related Manuals for NOVA3D Whale3 Super 14K
Summary of Contents for NOVA3D Whale3 Super 14K
- Page 1 Whale3 Super 14K Firmware Upgrade Operation Guide IMPORTANT NOTES: Please make sure to follow the upgrade operation guide for the printer firmware upgrade! If you need the upgrade files and reference videos, please contact NOVA3D customer service. Official Email: amzus@nova3dp.com Prepare Work (1)Tools Preparation: Prepare a USB stick (2.0 interface) with a capacity of at least 4G.
-
Page 2: Firmware Upgrade Method
地址：深圳市宝安区松岗街道潭头社区芙蓉路中展科技园厂房二栋四层 Firmware Upgrade Method (1) Unzip the latest version of the firmware compression package: Whale3 Super 14K V100_V4302.zip Then copy the three files in the unzipped folder to the root directory of the USB stick. The corresponding name of three files are as follows: ChituUpgrade.bin... - Page 3 地址：深圳市宝安区松岗街道潭头社区芙蓉路中展科技园厂房二栋四层 (4) Click ‘File’ - Select ‘USB File’. (5) Choose the corresponding upgrade file ‘Whale3 Super 14K V100.gcode’ and then click the print button. Please wait until the upgrade is successful. Tip: There is no need to turn off the machine after printing files with a gcod suffix. Please wait until the final leveling steps have been successfully saved before restarting the machine.
- Page 4 深 圳 市 诺 瓦 机 器 人 技 术 有 限 公 司 地址：深圳市宝安区松岗街道潭头社区芙蓉路中展科技园厂房二栋四层 Firmware 3.Confirm the upgrade results (1)Check the latest firmware version model is: V1.0.0/V43.02 (2) Unplug the USB disk, return to the main menu, and select ‘manual control’. Click the rise ‘10’ button, check whether the motor with lead screw rises 10mm.
- Page 5 深 圳 市 诺 瓦 机 器 人 技 术 有 限 公 司 地址：深圳市宝安区松岗街道潭头社区芙蓉路中展科技园厂房二栋四层 (3) Remove the Platform (This operation is to prevent the lead screw from spinning out from the liner guide or platform pressure the monochrome LCD screen when confirming the direction of the lead screw motor after the printer has been upgraded).
- Page 6 深 圳 市 诺 瓦 机 器 人 技 术 有 限 公 司 地址：深圳市宝安区松岗街道潭头社区芙蓉路中展科技园厂房二栋四层 (5) Enter the 'Leveling Setting' interface, re-check and confirm the leveling height, and click the ‘Save’ button. Attention: This leveling setup is just a check of the leveling memory position and does not require loosening the leveling screws.
