Soft Touch Assist Handle
1.
Place the Soft Touch rail at your desired mounting location.
2.
The rail's mounting holes are offset, so you can mount the rail to
your coach's door frame. This rail will only support its user as well
as it is attached to the coach – be sure you secure it to the door
frame or a stud in the wall of your coach.
3.
Mark the four screw holes.
4.
Drill 1/8" pilot holes.
5.
Place waterproof caulk in the holes to prevent moisture from
entering your coach's wall.
6.
Prior to the caulk setting up, mount your Soft Touch rail using the
provided fasteners.
Soft Touch
Assist Handle
Models: AH-100 White
AH-150 Black
1.25" on center
18.5" 14.75" 11.5"
1.25" on center
Contents
(1) Soft Touch Assist Rail
(4) 2-1/4" x #18 Stainless Steel Fasteners
StrombergCarlson.com • 231.947.8600
AH-100, AH-150
PROUDLY MADE IN THE USA
INS-2625 10.29.2020
