- Page 1 2013 2014 2015 2016 F250 Lariat 2013 2014 2015 2016 F250 Super Duty 2013 2014 2015 2016 F250 Platinum 2013 2014 2015 2016 F250 King Ranch Radio Installation Instructions...
-
Page 2: About The Product
THANKS About the product Thank you for choosing us! I will provide you with detailed instructions and help Package Details Packages are shipped by Amazon. Please note the status of the package when you sign for it! Guaranteed to receive the product in good condition! Before disassembling the car, read the instructions carefully Please note:... - Page 3 Misinsertion Avoidance Design All plugs are designed to prevent misplugging, plugs and sockets Only 1 to 1 connection, so watch carefully You are a professional mechanic 1 to 1 connection plug and play Anti-Misplug Design When installing, observe carefully, each plug can be inserted into the socket, it is very simple...
-
Page 4: About The Radio
About the radio Radio Jack Description The back of the radio has this description of the jacks, just connect the corresponding accessories Host Socket Description All plugs are error-proof and connected one to one Before tting the vehicle, please connect the harness according to the instructions... -
Page 5: About Accessories
About Accessories All plugs are plug and play Only the power cord adapter plugs into the vehicle... -
Page 6: Power Cord
Common Troubleshooting-A Power cord This is the power cord, this device mainly goes to the power cord output 1. small black plug, connect to the power jack on the back of the radio 2. small yellow plug. Connects to the jack on the back of the radio. - Page 7 About dismantling the car.1 1. Warp out the lower power and cigarette lighter covers with a rubber sheet. 2-Remove the set screw here.
- Page 8 About dismantling the car.2 3. Take o the panel and you'll see the screen with the CD like this 4.Remove the 4 screws that hold the screen in place here to take down the screen...
- Page 9 About dismantling the car.3 4. Took out the screen and found this, with a power plug with a USB adapter plug Note: The power plug comes out by pressing down on the catch...
- Page 10 About dismantling the car.4 Note: The radio needs to retain this module. Remove these 4 screws and install the module on the back of the new screen After securing the module, mount the screen to the panel...
- Page 11 About dismantling the car.2 1. Immobilizing modules to the screen 2. Mount the new screen to the original panel Note: Remove the original radio for safety! Next, we assemble the wires...
- Page 12 About dismantling the car.4 Power cord 2 large black plugs adapted to the original power cord 1. small black plug, connect to the power jack on the back of the radio 2. small yellow plug. Connects to the jack on the back of the radio.
- Page 13 About dismantling the car.4 Retain the original module Screws to new screen Like this.
- Page 14 Common Troubleshooting-B gaoding chanpin Modi ed Camera If the original camera is damaged or not available, then you can use our complimentary camera for you!
-
Page 15: Camera Settings
Common Troubleshooting-C gaoding chanpin Camera settings 1. Put into reverse gear and enter the reverse screen 2. Tap the screen 3. Reverse setting 4. Click Signal type 5. Try different formats in turn... -
Page 16: Screen Settings
Common Troubleshooting-D gaoding chanpin Screen Settings If the screen is upside down and cannot be controlled during use or after installation Don't worry, it's all in the settings. 1. Access to settings 2. Factory settings, password: 7890 3. Screen Rotatin, select Positive Or Negative 4. - Page 17 About the installation section If you are able to dismantle the vehicle to ensure safety! We recommend that you can install it yourself. Just note that the installation is operated without power Installation takes only steps: First: connect the appropriate accessories to the radio Second: just plug the jack of the radio's power cord, which needs to be connected to the car's jacks...
- Page 18 How to connect Car Play.1 gaoding chanpin The radio supports CarPlay and Android Auto functions. Achieving Safer Driving Using Mobile Phones APP：Car Auto CarPlay usage steps: 1. Click the Bluetooth APP 2. Connect Bluetooth with the vehicle 3. Open the [Car Auto] APP 4.
-
Page 19: Manual Section
Manual section.1 gaoding chanpin 1. The upper part is the APP interface, you can slide left and right to choose the right APP 2. The middle part shows the time and other information 3. The following is the air conditioning control area 4. - Page 20 Manual section.1 gaoding chanpin 1. General settings; this section sets the daily use of the radio, theme style, time, language, units, etc. Please note that the radio area is adjusted to North America. 2. Sound settings; set the volume and sound effects 3.
- Page 21 About the After-sales contact us I can be contacted at Amazon Mail. I will get back to you within 12 hours Send video to: mryang115@gmail.com Scan QR code, Or Number ：+86 181 0954 0115, add WhatsApp,can send the video.
