- Page 1 F250 F350 F450 F650 Series Radio Installation Instructions...
- Page 2 THANKS About the product Thank you for choosing us! I will provide you with detailed instructions and help Package Details Packages are shipped by Amazon. Please note the status of the package when you sign for it! Guaranteed to receive the product in good condition! Before disassembling the car, read the instructions carefully Please note:...
- Page 3 Common Troubleshooting-A About the camera Note: Factory cameras, or retro t cameras, are connected using a CVBS harness! Attention If the camera screen appears unstable or fails to display after docking, check the settings: 1. Put into reverse gear and enter the reverse screen 2.
- Page 4 Common Troubleshooting-B gaoding chanpin Modi ed Camera If the original camera is damaged or not available, then you can use our complimentary camera for you!
- Page 5 Common Troubleshooting-C gaoding chanpin Camera settings 1. Put into reverse gear and enter the reverse screen 2. Tap the screen 3. Reverse setting 4. Click Signal type 5. Try different formats in turn...
- Page 6 Common Troubleshooting-D gaoding chanpin Screen Settings If the screen is upside down and cannot be controlled during use or after installation Don't worry, it's all in the settings. 1. Access to settings 2. Factory settings, password: 7890 3. Screen Rotatin, select Positive Or Negative 4.
- Page 7 Misinsertion Avoidance Design All plugs are designed to prevent misplugging, plugs and sockets Only 1 to 1 connection, so watch carefully You are a professional mechanic 1 to 1 connection plug and play Anti-Misplug Design When installing, observe carefully, each plug can be inserted into the socket, it is very simple...
- Page 8 About the radio Radio Jack Description The back of the radio has this description of the jacks, just connect the corresponding accessories Host Socket Description All plugs are error-proof and connected one to one Before tting the vehicle, please connect the harness according to the instructions...
- Page 9 About Accessories 4G antenna GPS antenna WIFI antenna CVBS USB Adapter wire SIM card slot SIM card slot...
- Page 10 Power cord This is the power cord where the gray plug is connected to the vehicle Power cord Original car reversing image connection...
- Page 11 Microphone connection The radio has a panel with a built-in microphone This can be installed in the place where the radio is good according to the need For other connection methods, please see the next page...
- Page 12 About the installation section 1. Assemble the radio accessories rst, just like the picture 2. Connect with vehicle 3. Start the vehicle and check the function Just note that the installation is operated without power Installation takes only steps: First: connect the appropriate accessories to the radio Second: just plug the jack of the radio's power cord, which needs to be...
- Page 13 How to connect Car Play.1 gaoding chanpin The radio supports CarPlay and Android Auto functions. Achieving Safer Driving Using Mobile Phones APP：Car Auto CarPlay usage steps: 1. Click the Bluetooth APP 2. Connect Bluetooth with the vehicle 3. Open the [Car Auto] APP 4.
- Page 14 Manual section.1 gaoding chanpin 1. The upper part is the APP interface, you can slide left and right to choose the right APP 2. The middle part shows the time and other information 3. The following is the air conditioning control area 4.
- Page 15 Manual section.1 gaoding chanpin 1. General settings; this section sets the daily use of the radio, theme style, time, language, units, etc. Please note that the radio area is adjusted to North America. 2. Sound settings; set the volume and sound effects 3.
- Page 16 About the After-sales contact us I can be contacted at Amazon Mail. I will get back to you within 12 hours Send video to: mryang115@gmail.com Scan QR code, Or Number ：+86 181 0954 0115, add WhatsApp,can send the video.
