Related Manuals for Nexigo SPK03
Summary of Contents for Nexigo SPK03
- Page 1 SPK03 Wireless Speakerphone User Manual Scan the QR code or visit our link to download the latest manual or watch the installation video. nexigo.com/manuals...
-
Page 2: Safety Notes
If the unit is damaged, please exercise the warranty or recycle the ● speakerphone at your nearest electronics store. Do not attempt to repair, disassemble, or modify the speakerphone under any circumstances. Please contact NexiGo Customer Support at cs@nexigo.com if you experience any issues. -
Page 3: Contact Information
If you have any problems, please contact us any time at cs@nexigo.com for further assistance. From all of us here at NexiGo, we want to thank you for your trust in us. We look forward to serving you again in the near future. Sincerely,... -
Page 4: Product Features
PRODUCT FEATURES The NexiGo SPK03 is a wireless conference speakerphone that picks up voices from all directions within 10 feet. It’s designed to be plug-and- play and has both wireless capabilities and a USB port for quick and easy connections. -
Page 5: Wireless Connectivity
8 HOURS OF BATTERY LIFE The built-in 3000mAh battery supports up to 8 hours of wireless audio. HI-FI AUDIO This built-in high-fidelity speaker allows the SPK03 to transmit and receive sound without any disturbance or overlap. ACTIVE SPEAKER TRACKING For meetings with multiple people, the speakerphone will automatically track whoever’s talking by redirecting its microphones... -
Page 6: Product Overview
PRODUCT OVERVIEW 1. LED Ring 2. Wireless Connection On / Off 3. Volume - 4. Mute / Unmute 5. Power Button / Status Light 6. Volume + 7. Answer / Reject / Hang Up 8. USB-C Port (for charging and PC connectivity) 9. -
Page 7: What's In The Box
WHAT'S IN THE BOX? 1 x NexiGo Wireless Speakerphone 1 x USB-C to USB-A Cable 1 x User Manual SPECIFICATIONS Charging Input DV 5V 3000mAh Battery Capacity 2.3W Power Consumption Charging Time 3 hours Talk Time 8 hours Microphone Pickup Range... - Page 8 SETUP POWER ON / OFF Press and hold the button for two seconds to power the speakerphone on / off. The speakerphone will automatically power on once it’s plugged into your PC. Meanwhile, it will automatically power off after either 15 minutes of inactivity or if there’s no power source.
- Page 9 CONNECTING Note: When the speakerphone is connected wirelessly and also by USB, tap the button to switch between wireless and USB transmission. The status light will glow blue for a wireless connection and white for a USB connection. Wireless Connection blue USB Connection white...
- Page 10 ● Next, enable Bluetooth on your computer or mobile device and select ● "NexiGo SPK03" from the list of available devices. The speakerphone will say "Bluetooth connected" when pairing is complete. Wireless Connection Status LED Ring Status Wireless pairing in progress Red and blue lights will flash...
- Page 11 Note: 1) Each time you power on the NexiGo SPK03, it will automatically pair with the last successfully connected device (if available). 2) To turn off wireless capabilities, press the button for about three seconds. 3) For a wired connection, use the provided USB cable to connect the USB-C side to the speakerphone, and the USB-A side to your computer (see diagram below).
-
Page 12: Adjust The Speaker Volume
2. Select the apps on the list that you want to have access to the microphone. 3. Once you have access, open the apps you're planning to use and ensure that you have selected the NexiGo SPK03 as the active speaker and active microphone from the list of available options. -
Page 13: Mute / Unmute The Microphone
ACTIVE SPEAKER TRACKING FUNCTION The SPK03 will automatically track the active speaker by redirecting its microphone toward whoever’s talking. To indicate that the speakerphone is tracking properly, the LED ring will light up in the direction of the active speaker. -
Page 14: Low Battery Warning
Note: 1) The "active speaker" refers to a person who has been consistently speaking for more than three seconds. 2) The LED ring will partially light up in blue, green, or red according to the active speaker’s distance from the speakerphone and their volume level. Blue means your voice is loud, green means your voice is at a normal level, and red means your voice is quiet. - Page 15 CHARGING Charge the speakerphone by connecting it to a power source (wall charger, computer, etc.) with a DC 5V 1A output using the provided USB charging cable. The LED ring will light up from red to blue in a clockwise motion, which helps to let you know the charging status when it’s plugged in.
-
Page 16: Check The Battery Level
CHECK THE BATTERY LEVEL Press the button once, the blue LED ring will light up to indicate the current battery level. US 01... -
Page 17: Fcc Requirement
FCC REQUIREMENT Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. -
Page 18: Correct Disposal Of This Product (Waste Electrical & Electronic Equipment)
WEEE CORRECT DISPOSAL OF THIS PRODUCT (WASTE ELECTRICAL & ELECTRONIC EQUIPMENT) (Applicable in countries with separate collection systems) This marking on the product, accessories or literature indicates that the product and its electronic accessories (e.g. charger, headset, USB cable) should not be disposed of with other household waste at the end of their working life. - Page 19 Get in touch with FREE online services. facebook.com/letsnexigo...
