DURASTEEL F-H-MKI Assembly Instructions

Faucet Installation Kit
If you have 1/2" NPT female water inlet, you might need a faucet installation
kit to complete installation.
· 2 x 90-Degree Elbows
· 2 x Nipples
· 2 x Rubber Washers
· 2 x Metal Washers
· 2 x Lock Nuts
Assembly Instructions
*Te on tape must be applied by turning it clockwise around the thread.
*Part #1 - 3, please refer to previous page.
1. Turn o water supply.
2. Flush lines.
3. Apply Te on tape or pipe joint compound to one side of thread of pipe nipples.
4. Thread the side of pipe nipples which are appilied Te on tape or pipe joint compound
onto #4 coupling nuts. (Do not tighten at this time.)
5. On front side of backsplash, insert pipe nipples through backsplash.
Place rubber washer, metal washer, lock nut onto pipe nipples on back side of
6.
backsplash.
7. Follow washer with nut and sung rmly against backsplash.
8. Adjust #4 coupling nuts to mate with male threads of #1 faucet body. *Please check if
the rubber washer which faucet comes with is between coupling nut and faucet body.
9. Using crescent wrench, tighten #4 coupling nuts to pipe nipples.
10. Insert #2 spout into #1 faucet body. Using crescent wrench, tighten #3 spout nut onto
threads of #1 faucet body.
11. On back side of backsplash, apply Te on tape or pipe joint compound onto the pipe
nipples, and then thread 90° elbow onto the pipe nipple and tighten it.
12. Attach supply lines onto 90° elbow.
13. Turn on water supply and check for leaks.
14. Remove aerator and ush lines for 1 to 2 minutes.
This product contains chemicals known to the State of California to cause birth defects or other reproductive harm.
Lead, which is contained in all brass and bronze faucets, in very limited amounts, appears on the state's list.
4
Note to users:
© 2021 DuraSteel All Rights Reserved
a. 1/2" Nipple
b. Rubber or Plastic Washer
c. Metal Washer
d. Lock Nut
e. 1/2" 90° Brass Elbow
a
b c d e
Backsplash
