Brush Grubber BG-08 Manual

IMPORTANT SAFETY INFORMATION
Read and understand all safety precautions and instructions
before use.
The Heavy Duty Brush Grubber is designed for outdoor use.
Check Heavy Duty Brush Grubber before each and every use
for signs of wear. Do Not use if damaged or if not working
properly
The Heavy Duty Brush Grubber is designed to remove brush
up to 4" diameter
The Heavy Duty Brush Grubber is not to be used on people
or pets.
INSTRUCTIONS
1.Cut brush/tree off at 3ft to 4ft above the ground prior to removal.
2.Place Heavy Duty Brush Grubber on each side of trunk of brush near the base/ground with spring on Heavy Duty Brush
Grubber placed towards the ground as shown in figure 1.
3.Attach a chain to the clevis of Heavy Duty Brush Grubber and the opposite end of the chain to the towing/pulling vehicle.
Take caution that the chain is long enough so the brush will not hit/strike the operator of the towing/pulling vehicle.
DO NOT jerk the Brush Grubber while there is slack in the chain.
4.To remove Heavy Duty Brush Grubber from the trunk of brush push back on the clevis (towards the trunk).
* Take caution of all pinch points on the Heavy Duty Brush Grubber.
* Take caution of Grip Pads when opening the jaws of the Brush Grubber HD. Keep fingers and hands free
and clear.
For use on shallow-rooted trees and brush. Functionality can vary by root system/tree type, soil type,
and ground conditions.
PARTS DESCRIPTION
WARNING
BAC Industries, Inc. and Brush Grubber will not be held liable for any damages, losses or injury due to the misapplication or misuse of
this product or any other reason. Always wear approved safety glasses, protective clothing, and proper hand and foot protection at all
times. Keep all people, pets, or animals clear from brush removal work area.
FOR ANY QUESTIONS PLEASE CONTACT OUR OFFICE OR VISIT WWW.BRUSHGRUBBER.COM
Brushgrubber.com
PO BOX 155
Miltona, MN 56354
Figure 1
Qty
Ref. #
1 2 BG05-01
2 2 BG05-02
3 2 BG05-04
4 3 BG05-10
5 1 BG05-03
6 1 BG08-01
7 1 BG08-02
8 1 BG08-03
9 2 BG05-08
10 2 BG05-09
11 4 BG05-07
12 1 BG08-04
13 2
PH: 218-943-6290
www.brushgrubber.com
Email: info@brushgrubber.com
BG-08
Description
Part #
Main Arm
Clevis Arm
Spring Shaft 18x65mm
Washer 18
Spring
Center Shaft 18x65mm
Clevis
Shaft 18x75mm
E-clip (Grip Pad) 10
E-clip (Spring Bolt) 8
Washer 13
Pin 3x40mm
Grip Pad
BG-003
