Brush Grubber Xtreme Instructions

Brush Grubber Xtreme
Important Safety Information
Read and understand all safety precautio ns and
i nstructio ns before use.
The Brush Grubber Xtreme is designed for outdoor use.
•
Check Brush Grubber Xtreme before each and every use
•
for signs of wear.
working properly
The Brush Grubber Xtreme is designed to remove brush
•
up to 5" diameter
The Brush Grubber Xtreme is not to be used on people or
•
pets.
For use with tractors 45HP or l ess.
•
Instructions
1. Cut brush/tree off at 3ft to 4ft above the ground prior to
removal.
2. Place Brush Grubber Xtreme on each side of trunk of brush near the base/ground with spri ng o n
the Brush Grubber Xtreme placed towards the ground as shown in figure 1.
3. Securely Attach a chain to the clevis of the Brush Grubber Xtreme and the opposite end of the
chain to the towing/pulling vehicle. Take caution that the chain is long enough so the brush will
not hit/strike the operator of the towing/pulling vehicle. DO NOT jerk the Brush Grubber
Xtreme whi l e there is slack in the chai n.
4. To remove the Brush Grubber Xtreme from the trunk of brush push back on the clevis (towards
the trunk) or pull jaws open using the large rugged handles on each side of the jaws.
*Take caution of all pinch points on the Brush Grubber Xtreme.
*Take caution of Grip Pads when openi ng the jaws of the Brush Grubber Xtreme.
Keep fing ers and hands free and cl ear.
14
1
WARNING
BAC Industries, Inc. and Brush Grubber will not be held liable for any damages, losses, or injury, due to
! misapplication or misuse of this product or for any other reason. Always wear approved safety glasses, protective
clothing, and proper hand and foot protection at all times. Keep all people and pets or animals clear from brush
removal work area.
WARNING
FOR ANY QUESTIONS, PLEASE CONTACT OUR OFFICE OR VISIT WWW.BRUSHGRUBBER.COM
Do Not use if damaged or if not
5
11
4
6 3
8
12
13
2
BrushGrubber.com
PO B OX 5064
HOPKINS, MN
55343
See other unique items at BrushGrubber.com
Ref. # Qty
1 2
9
2 2
3 2
4 3
10
5 1
6 1
7 1
8 1
9 2
7
10 3
11 4
12 1
13 2
14 2
PH: 952-945-9058
www.brushgrubber.com
Email:
i nfo@brushgrubber com
Model #:
Part # Description
BG11-01 Main Arm
BG11-02 Clevis Arm
BG11-03 Spring Shaft Ø18x65mm
BG11-04 Collar Ø18
BG11-05 Spring
BG11-06 Center Shaft Ø18x65mm
BG11-07 Clevis
BG11-08 Shaft Ø18x75mm
BG05-09 E-clip (Grip Pad) Ø10
BG11-10 Roll Pins
Large Washer
BG11-11 Ø50x2.5mm
BG11-12 Pin Ø3x40mm
BG11-13 Grip Pad
Small Washer
BG11-14 Ø50x2.5mm
BG-11
