Pyle PMP35R Quick Manual

30W HAND-GRIP MEGAPHONE
Professional Compact Power Megaphone
QUICK GUIDE
FEATURES
• Dry Cell Operation
• Full ABS Body, Sturdy & Lightweight
• Built-in Siren & Microphone
OPERATION
• Open the back cover by pressing down
on the 'Open' Button
• Insert 4 x "D" Cells then close back
cover until locks into position. Now,
your megaphone is ready for operation.
• To activate the megaphone, press the
'ON/OFF' button on the back cover.
• When using the megaphone, place your
lips as close as possible to the mega-
phone when speaking. Adjust the 'Vol-
ume Control' to the desired level without
causing any howling or feedback.
• Press the 'Siren' button to activate
emergency siren/alarm. To switch off
the alarm, press the same button again,
or press the 'ON/OFF' button.
• Adjust the volume control to the min.
before recording. To record, press the
SIREN button and the PLAY button to-
geather. Now your megaphone is ready for recording. The longest record time is about 10 seconds. Press
the SIREN button and the PLAY button together after finishing recording.
• Press the PLAY Button to activate the recorded materials circularly.
PRECAUTIONS
Ensure correct polarity of cells used. Insert the batteries in
the correct direction by aligning the (-) marks on the batter-
ies with the spring in the back cover.
Use new batteries/cells whenever possible.
When the megaphone is not in use for a long period of time,
remove the dry cells and replace.
Drained cells or rechargeable battery will not give sufficient
sound volume.
Model: PMP35R
• Clear Sound, Long Range & Efficient Design
• Conveniently Located Volume Controls & Switch
• 10 Seconds Voice Recording Function
SPECIFICATIONS
• Power Output: 30 Watts
• Voice Range: 800 Yards
• Power Source: 4 x UM – 1 Cells
• Battery Life: 6 – 8 Hours
• Microphone: Unidirectional
• Dimensions: Diameter: 6 1/4" x Length: 10 1/8"
• Weight: 1.15 LBS.
Design & Specifications subject to change without prior notice
(Not Included)
