Summary of Contents for DigiTech BASS SYNTH WAH
-
Page 2: Declaration Of Conformity
European Contact: Your local DigiTech Sales and apparatus has been exposed to rain or moisture, does Service Office or not operate normally, or has been dropped. - Page 3 6.The consumer forfeits the benefits of this warranty if the product's main assembly is opened and tam- pered with by anyone other than a certified DigiTech technician or, if the product is used with AC volt- ages outside of the range suggested by the manufacturer.
-
Page 4: Control Knob
The Bass Synth Wah is an exciting combination of seven different synth and wah effects including envelope filter, synth tones, filter generators, and octave shift. The Bass Synth Wah can be run inline with your current pedals, or parallel with your bass tone to create unique combinations of both bass and synth sounds. - Page 5 2 3 4...
- Page 6 Filter Attack Freq Envelope 7- OctaSub Trigger Sensitivity Sub Level Synth Level Effects Matrix 4. Range Knob Controls different functions depending on which Bass Synth Wah Type is selected. See Effects Matrix on this page for detailed Range knob descriptions.
- Page 7 4-SYNTH 2 - Monophonic synth tone generator with a closing filter envelope. 5-FILTER 1 - Digitech’s famous Synth Talk™ effect. 6-FILTER 2 - Synth Talk™ effect with inverse filter envelope. 7-OCTASUB - An octave down pitch shift effect with a variable synth effect mix using the RANGE knob.
- Page 8 Use this output when only one amplifier or mixer channel is used. When both Out 1 Normal (Dry) and Out 2 (Effect) are connected, only dry, unprocessed bass signal is present at Out 1 Normal (Dry) when the Bass Synth Wah is on or bypassed.
-
Page 9: Indicator Led
Connect this output to a second amplifier or to a mixer channel for effect signal only. When Out 2 is connected, only effect signal is present when the Bass Synth Wah is turned on. Out 2 is muted when the Bass Synth Wah is bypassed. - Page 10 Connections The Bass Synth Wah has a single input and a pair of outputs. When possible, the Bass Synth Wah should be the first effect pedal in your effects chain. This insures proper triggering of the different effects. Out 1 Normal (Dry) is used when the Bass Synth Wah is connected to a Out 1 Normal (Dry) single amplifier or mixer input.
- Page 12 CIT™ Cabinet Modeling The Bass Synth Wah also has built-in CIT™ cabinet modeling that can be enabled. CIT cabinet modeling simulates a 4x10 bass speaker cabinet, giving you a through-an-amp sound when running direct to a mixer or recording device.
-
Page 13: Sample Settings
Sample Settings 1. Funky Envelope 2. Slow Synth 3. Synth Bass 4. Synth Ya 5. Octa Sub Synth... -
Page 14: Battery Replacement
Battery Replacement 1. Using the tip of a 1/4” cable, push one of the release pins in on either side of the pedal, and remove the pedal from the pedal chassis. 2. Remove the battery from the battery compartment and disconnect the battery cable. - Page 15 Pedal Pedal Switch 9V DC Battery Pedal Release Battery Compartment Pedal Release Spring Pedal Chassis...
-
Page 16: Specifications
• Power Consumption - 4.8Watts Copyright - Harman Music Group (w/optional PS200R power supply) • Battery Life - Approximately 4 hours Bass Synth Wah Envelope Filter (with continuous usage) Owners Manual 18-1813V-A • Dimensions - 4 15/16”(L) x 3 1/8”(W) Please visit DigiTech x 2 1/8”(H)
