iBOLT TabDock LockBox Manual

IBBZ - 33779 | TabDock LockBox
Mounting Base & Holder
1
Using a screwdriver and/or drill, attach the metal AMPS mounting base
to a flat surface with 4 screws (not included).
Inserting Tablet
1
To size the tablet holder to your tablet, begin by unlocking the top of
the tablet holder with the key and push up on the locking arm. Use
included adhesive pads to secure tablet in holder.
Adhesive pads
3
Unscrew the screws at the bottom sides of the holder to adjust the tablet
holder's width to the tablet. Tighten to secure.
Safety Precautions
!
Do not install iBolt products over an air bag cover or an air bag deployment zone.
iBolt. is not responsible and assumes no liability for injury or death as a result
of a car crash and / or air bag deployment.
iBolt is not responsible for any damages caused to your vehicle, your device, or yourself
due to the installation or use of this product.
Package Contents:
22168 - 25mm to AMPS Metal
21242 - Tablet LockBox Kit Holder
21249 - 4 Screw & Nut Pack
23504 - 4-HOLE METAL PLATE W/SCREW PAC
Device Compatibility: Fits 7"-10" screen size tablets
Tools Needed: 7mm and 10mm socket wrenches
Locking Arm
Adhesive pads
2
Connect the tablet holder to the mounting base (screws provided)
using the 4-Hole AMPS mounting pattern. Loosen adjustment knob to
reposition shaft, retighten to desired position.
2
Unscrew the three screws/washers at the back/center of the holder to
adjust the tablet holder's height to the tablet (not included). Retighten
the screws/washers to secure.
4
To lock down tablet, close down on the locking arm on the top of the
tablet and lock with key (included).
www.ibolt.co
11 Flower St. Arcadia Ca 91006
Questions? info@ibolt.co
22158 - BIZMOUNT 4"" SHAFT
23516 - Security Hardware for Bizmount
(Tablet not included)
Adjust
Unscrew
to adjust
