200444
Multi-Function Digital Meter
Parameter:
Measure accuracy: 1% ± 2 words
Voltage: AC 80.0 - 300.0V
Current: AC 0 - 99.99A, minimum resolution is 0.01A
Active Power: 0 - 30000W
The minimum resolution of 0-9999.9W: 0.1W
The minimum resolution in other range: 1W
Electric energy: 0 - 99999kwh
The minimum resolution of 0 - 999.9kwh: 0.01kwh
The minimum resolution of 1000.0 - 9999.9kwh: 0.1kwh
The minimum resolution of 10000.0 - 99999kwh: 1kwh
Power frequency: 45.0Hz - 65.0Hz
Power factor: 0.00 - 1.00PF
Speed: 2 times / second
Size: 79 * 43 * 48mm
Installation size: 76 * 39mm
Auto-saving: When power off, the electric energy will be saved.
The saved electric energy will be accumulated continue when the
meter power-on next time.
Extreme working conditions:
Working temperature: -10 ~ 50℃
Working humidity: 10 ~ 80% (no frost)
Working pressure: 80 ~ 106 kPa
Sun: no directly sunshine
Measure Voltage Input
Current Transformer
(green terminal)
Input (blue terminal)
Current Transformer
(CT)
AC 80.0~300.0V
Thread the wire of the testing
circuit through the hole of the CT
It'll damage the instruments if the voltage input wires
!
and CT wires are connected wrong.
Load
Advertisement
Related Manuals for Drok 200444
Summary of Contents for Drok 200444
- Page 1 Extreme working conditions: Parameter: 200444 Working temperature: -10 ~ 50℃ Measure accuracy: 1% ± 2 words Working humidity: 10 ~ 80% (no frost) Voltage: AC 80.0 - 300.0V Working pressure: 80 ~ 106 kPa Current: AC 0 - 99.99A, minimum resolution is 0.01A...
- Page 2 Press down the button for 5 seconds, the electric energy will be cleared. Digital Multimeter USB 2.0 Visit DROK Store on Amazon: Attention: The meter will be destroyed when you make wrong connection. This meter is suitable for 50 - 60HZ AC power, it couldn’t be used to the square wave, output of inverter and correction sine wave.
