Crest Audio VSL 1500 - TECHNICAL Technical Data

SPECIFICATIONS

VsL 460
Output power into 8 ohm load 150W
at 1kHz & 0.01% THD+N
Output power into 4 ohm load 240W
at 1kHz & 0.01% THD+N
Output power into 2 ohm load 325W
at 1kHz & 0.01% THD+N
Bridged mono power in 8 ohm 450W
Bridged mono power in 4 ohm 650W
Frequency response
Power bandwidth at 4 ohm
THD+N @ 1kHz
SMPTE IMD
Hum + N "A" @ rated 4 ohm power
Crosstalk "A" @ rated 4 ohm power
Slew rate
Voltage gain
Input CMRR @ 1kHz
Input impedance
Damping factor @ 100Hz >700:1
Input sensitivity 0.775V
Output operating class Class AB
PSU reservoir capacitance 69 Joules
Mains voltage
AC power consumption @ idle 125W
AC power consumption @ 1/8 700W
AC power consumption @ max 1150W
Dimensions H5.25" xW19" xD12"
Net weight 33 lbs
† Power figures are watts per channel, both channels driven, 1kHz, 1% THD+N. * 3-Year Warranty with 2 additional years is Registration Card is sent to Crest Audio. (USA, UK, Canada, and
many other countries). Crest Audio reserves the right to make improvements in manufacturing or design which may affect specification. Crest Audio specification literature is available in down-
loadable PDF format; visit our website at: http://www.crestaudio.com.
v. 1.0 11/10/97
VsL900 VsL1500
250W 400W
450W 750W
550W 1000W
900W 1500W
1100W 2000W
10Hz–65kHz, +0/-0.3dB @ 1W into 8Ω
10Hz to 20kHz, @ 1% THD+N
<0.02%
<0.1%
- 105dB
> -60dB
18V/microsecond
standard
> -60dB
20kΩ balanced, 10kΩ unbalanced
>1000:1 >1000:1
1.0V 1.4V
Class AB Class H
116 Joules 121 Joules
220V AC~50Hz
150W 175W
1250W 1850W
1850W 2525W
xD12" xD13.25"
36lbs 42lbs
100 Eisenhower Dr., Paramus NJ 07652 USA
: 201.909.8700
TEL
http://www.crestaudio.com
©1997 Crest Audio Inc.
Crest Audio Inc.
: 201.909.8744
FAX
Printed in USA
PROFESSIONAL
POWER AMPLIFIERS
Ch A Signal Clip
Active Protect
Ch B Signal Clip
Ch A Signal Clip
Active Protect
Ch B Signal Clip
Ch A Signal Clip
Active Protect
Ch B Signal Clip
SPECIFICATIONS
-6
-10 -3
-15
-1
-30
-80 0 dB
CH A
-6
-10 -3
-15
-1
-30
-80 0 dB
CH B
-6
-10 -3
-15
-1
-30
-80 0 dB
CH A
-6
-3
-10
-15
-1
-30
-80 0 dB
CH B
-6
-10 -3
-15
-1
-30
-80 0 dB
CH A
-6
-3
-10
-15
-1
-30
-80 0 dB
CH B
FEATURES
BENEFITS
