H110
User Manual
(English)
http://www.91machinist.com/
1
https://z.wiki

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the H110 and is the answer not in the manual?

Questions and answers

Related Manuals for MACHINIST H110

Summary of Contents for MACHINIST H110

  • Page 1 H110 User Manual (English) http://www.91machinist.com/ https://z.wiki...

  • Page 2: Table Of Contents

    Any problem with motherboard, please feel free to contact us for help. Contents Item Specifications ....................1 Structure of Motherboard ..................2 Install CPU & Fan ....................3 Install Memory ....................... 4 Install Expansion Card ....................4 Back Panel Connectors ...................4 USB 2.0 Port ..................... 5 USB 3.0 Port .....................
  • Page 3 Any problem with motherboard, please feel free to contact us for help. https://z.wiki...

  • Page 4: Item Specifications

    Any problem with motherboard, please feel free to contact us for help. Item Specifications H110 Motherboard Support Core/Pentium/Celeron 6th,7th,8th,9th CPU processor with LGA 1151 pin Processor series Southbridge H110Chipset Technology Dual channel DDR4 Desktop RAM Maximum 32GB (16GB*2) Capacity Memory Slot...

  • Page 5: Structure Of Motherboard

    Any problem with motherboard, please feel free to contact us for help. Structure of Motherboard Package List: H110 Motherboard * 1 SATA Cable * 1 I/O Shield * 1 — 2 — https://z.wiki...

  • Page 6: Install Cpu & Fan

    Any problem with motherboard, please feel free to contact us for help. Install CPU & Fan Please install the CPU into the CPU socket (LGA 1151) as shown below. Important! • Make sure that the motherboard supports the CPU. • Always unplug the power cord from the power outlet before installing or removing the CPU to prevent hardware damage.

  • Page 7: Install Memory

    Any problem with motherboard, please feel free to contact us for help. Install Memory The motherboard provides 2x DDR4 DIMM slots, each with a maximum capacity of 16GB. 1. Wrench the latches on both sides of the memory slot outwards. 2.

  • Page 8: Usb 2.0 Port

    Any problem with motherboard, please feel free to contact us for help. USB 2.0 Port It comes with 4pcs rear and 1pcs front USB 2.0 interfaces, those USB ports with 480Mbps fast speed and hot-swappable function allow you to connect multiple USB 2.0 devices. USB 3.0 Port Comes with 2pcs rear and 1Pcs front USB 3.0 interfaces, those USB ports with 5Gbps fast speed and hot-swappable function allow you to connect more devices.

  • Page 9: Audio Port

    Any problem with motherboard, please feel free to contact us for help. Audio Port — 6 — https://z.wiki...

  • Page 10: Internal Connectors

    Any problem with motherboard, please feel free to contact us for help. Internal Connectors F_PANEL1 Connector SPK2 Connector F_AUDIO1 Connector This connector allows you to connect audio jacks on the front panel. Important! • An incorrect connection between the module connector and the motherboard header will make the device unable to work or even damage it.

  • Page 11: Clear Cmos

    Any problem with motherboard, please feel free to contact us for help. Insert your M.2 SSD into the M.2 slot at a 30-degree angle. Secure the M.2 SSD in place with the screw. (How to switch the SATA M.2 or NVME M.2 Mode? Please read the picture of the item’s listing online.) Clear CMOS JCMOS1: CMOS jumper(If it’s a 2-pin, short them for about 5 seconds.)

  • Page 12: Atxpwr

    Any problem with motherboard, please feel free to contact us for help. ATXPWR Motherboard and CPU Power Connectors: With the use of the power connector, the power supply can provide enough stable power to all the components on the motherboard. Before plugging the power connector, make sure the power supply is turned off and all devices are properly installed.

  • Page 13: Fan Connectors

    Any problem with motherboard, please feel free to contact us for help. Fan Connectors CPU_FAN1 is a 4-pin interface for the CPU cooler. The 4-pin fan has no PWM speed regulation function, which can’t intelligently control the fan speed based on load and temperature changes.

  • Page 14: Bios Setting

    Any problem with motherboard, please feel free to contact us for help. BIOS Setting BIOS (Basic Input and Output System) records the hardware parameters of the system in the CMOS on the motherboard. BIOS identifies, configures, tests, and connects computer hardware to the OS immediately after a computer is turned on..

  • Page 15: Enter Bios Setup

    Any problem with motherboard, please feel free to contact us for help. Enter BIOS Setup When the computer is turned on, BIOS enters the self-test process. The following message will display after the self-test is completed: Press the " DEL " key to enter the BIOS Setup Menu.

  • Page 16: Frequently Asked Questions (Faq)

    Any problem with motherboard, please feel free to contact us for help. Frequently Asked Questions (FAQ) Can't Boot That means pressing the boot button, but the computer does not respond, the fan does not rotate, and the indicator light does not light. There are seven ways to troubleshoot as below: 1.

  • Page 17: No Display

    Any problem with motherboard, please feel free to contact us for help. No Display There are two states for monitor no display as below: State①: The fan is rotating, press the Caps Lock key, but the Caps Lock indicator of the keyboard does not respond.
