Product Specifications:
Surface finish: Black housing w/ smoked lens
Location: Mounts using factory mounting locations
Weather Sealed: Completely weather sealed to keep the elements out
Package Include: 1 Pair Tail Lights (Left & Right Side)
Note：
The bulb needs to be installed exactly vertically.
Advertisement
Related Manuals for AUTOSAVER88 ATTL5004
Summary of Contents for AUTOSAVER88 ATTL5004
- Page 1 Product Specifications: Surface finish: Black housing w/ smoked lens Location: Mounts using factory mounting locations Weather Sealed: Completely weather sealed to keep the elements out Package Include: 1 Pair Tail Lights (Left & Right Side) Note： The bulb needs to be installed exactly vertically.
- Page 2 Installation: Step 1 1. Make sure the lamp switch is in the off position, then open the tailgate. 2. Remove the (2) rear lamp assembly screws near the tailgate latch and pull out the lamp assembly. Step 2 1. Press the tab and turn the bulb sockets counterclockwise to remove sockets from the taillamp housing.
- Page 3 Wiring Diagram:...
