OFF-ROAD 4X4 DIY
parts list
INSTALLATION STEPS
STEP1:
Flip up rear seats.
STEP2:
Remove factory hex bolt from rear seat hinge.
If your vehicle did not equip this bolt, then use provided
self tapping screw drill mounting holes to fix storage case.
A
underseat storage box 1 pc
B
mini storage box
C
knob
D
divider
CARE AND USE INSTRUCTIONS
1 pc
2 pcs
2 pcs
-1-
ED0201R001
E
nut
F
washer
G
self tapping screw
2 pcs
2 pcs
1 pc
Advertisement
Related Manuals for OEDRO ED0201R001
Summary of Contents for OEDRO ED0201R001
- Page 1 CARE AND USE INSTRUCTIONS OFF-ROAD 4X4 DIY ED0201R001 parts list underseat storage box 1 pc 2 pcs mini storage box 1 pc washer 2 pcs knob 2 pcs self tapping screw 1 pc divider 2 pcs INSTALLATION STEPS STEP1: Flip up rear seats.
- Page 2 CARE AND USE INSTRUCTIONS OFF-ROAD 4X4 DIY STEP3: Threading the knobs into the mounting holes instead factory hex bolt. STEP 4: Installing the two dividers and mini storage for your needs. STEP 5: Flip down rear seat.
