Chamberlain POWER DRIVE Whisper Drive 956CB Owner's Manual

Model 953CB
For use with Security garage door openers and light
controls that have an orange "learn" button. The code
between the remote control and the receiver changes with
each use, randomly accessing over a billion new codes.
The additional push buttons can also activate other garage
door openers and/or light controls. (Instructions for
programming light products are included with those
accessories.)
Instructions are described and illustrated below.
1. Press and release the "learn" button on
the motor unit. The learn indicator light
will glow steadily for 30 seconds.
2. Within 30 seconds, press and hold the
button on the hand-held remote.
3. Release the button when the motor unit
light blinks. It has learned the code. If
light bulbs are not installed, two clicks will
be heard.
To Erase All Codes From Motor Unit Memory
To deactivate any unwanted remote, first erase all codes:
Press and hold the "learn" button on motor
unit until the learn indicator light goes out
(approximately 6 seconds). All previous
codes are now erased. Reprogram each
remote or keyless entry you wish to use.
Replacement Parts
Model 953CB SECURITY
(circuit board not included)
3V2032 Lithium battery
Visor clip
114A2107C
Multi-Function Security Remote Control
OWNER'S MANUAL
remote case
41A5056-10
29B137
© 2001, Chamberlain Group Inc.
/
™
To prevent possible SERIOUS INJURY or DEATH from a moving
gate or garage door:
• ALWAYS keep remote controls out of reach of children. NEVER
permit children to operate, or play with remote control transmit-
ters.
• Activate gate or door ONLY when it can be seen clearly, is properly
adjusted, and there are no obstructions to door travel.
• ALWAYS keep gate or garage door in sight until completely closed.
Never permit anyone to cross path of moving gate or door.
To Control the Opener Lights
9 1
9 1
7 3 7 3
5 5
KG KG
With SECURITY
be programmed to operate the opener lights without opening
the door.
1. With the door closed, press and hold the remote button that
you want to control the light.
2. Press and hold the Light button on the door control.
3. Press and hold the Lock button on the door control.
4. After the opener lights flash, release all buttons.
Test by pressing the remote push button. The opener lights
should turn on or off but the door should not move.
The Remote Control Batteries
To prevent possible SERIOUS INJURY or DEATH:
• NEVER allow small children near batteries.
• If battery is swallowed, immediately notify doctor.
The lithium batteries should produce power
for up to 5 years. To replace, pry open case
with visor clip or screwdriver, as shown.
Insert batteries positive side up (+).
Dispose of old batteries properly.
NOTICE: To comply with FCC and or Industry Canada rules, adjustment or modifications of this
receiver and/or transmitter are prohibited, except for changing the code setting or replacing the
battery. THERE ARE NO OTHER USER SERVICEABLE PARTS.
Tested to Comply with FCC Standards FOR HOME OR OFFICE USE. Operation is subject to the
following two conditions: (1) this device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undesired operation.
FOR SERVICE DIAL OUR TOLL FREE NUMBER:
10A20 1-800-528-9131
All Rights Reserved
®
WARNING
transmitters, a remote push button can
WARNING
Printed in Mexico
