Hicrank LFP4L-BS User Manual & Warranty

Lithium powersports batteries

Advertisement

Quick Links

Hicrank
User Guide & Warranty
Lithium Powersports Batteries
Warnings:
BEFORE USING THIS PRODUCT, PLEASE CAREFULLY READ AND UNDERSTAND
THE SAFETY INFORMATION. Failure to follow these safety instructions may result in
ELECTRICAL SHOCK, EXPLOSION, FIRE, potentially leading to SERIOUS INJURY,
DEATH, or PROPERTY DAMAGE.
Fire. This product is an electrical storage device that can generate heat. Do not cover
the product or place objects on top of it. Keep the product away from flammable
materials
Explosion. Never short-circuit the battery terminals. Do not use an incompatible charging
device. Do not attempt to jump start, charge, or discharge the battery if it is damaged or
frozen. Never charge or discharge the product outside its operating temperature range.
Never overcharge or overdischarge the battery. Never exceed the maximum charging
currents of the battery. Never incinerate the product.
Electrical Shock. This product is an electrical device that can deliver a shock and
cause serious harm. Do not submerge it in water or get it wet.

Advertisement

loading
Need help?

Need help?

Do you have a question about the LFP4L-BS and is the answer not in the manual?

Questions and answers

Summary of Contents for Hicrank LFP4L-BS

  • Page 1 Hicrank User Guide & Warranty Lithium Powersports Batteries Warnings: BEFORE USING THIS PRODUCT, PLEASE CAREFULLY READ AND UNDERSTAND THE SAFETY INFORMATION. Failure to follow these safety instructions may result in ELECTRICAL SHOCK, EXPLOSION, FIRE, potentially leading to SERIOUS INJURY, DEATH, or PROPERTY DAMAGE.
  • Page 2: Installation

    Below is a table displaying the charging times based on a 100% depth of discharge (DOD) with the recommended smart battery chargers: Battery Models 12V1A Charger 12V2A Charger 12V5A Charger LFP4L-BS,5L-BS,7L-BS,7S,7A-BS Recommonded Not Recommonded Not Available LFP9-BS,10S,12A,12-BS,12S,14S Not Recommonded...
  • Page 3 Full function Battery Management System The product is equipped with a Battery Management System (BMS) that monitors the internal lithium-ion batteries and disconnects them in case of a fault. The BMS prevents overcharging, over-discharging, overcurrent, short circuits, overheating, and thermal faults. It also includes battery balancing to maintain voltage equilibrium among individual batteries, ensuring optimal battery performance.
  • Page 4: Technical Specifications

    Technical Specifications LFP4L-BS LFP5L-BS LFP7SL LFP7B-BS LFP7A-BS Replace Sizes YTX4L-BS, YTZ5S YTX5L-BS, YTZ6V YTZ7SL,YTX7L-BS YT7B-BS,GT7B-4 LFP7A-BS Type Lithium - Ion Battery Chemistry Lithium Iron Phosphate (LiFePO4) Nominal Voltage (V) 12.8 Amp-Hours Watt-Hours (Wh) 25.6 38.4 51.2 51.2 51.2 Starting Current...
  • Page 5 Technical Specifications LFP9-BS LFP10S LFP12-BS LFP12B-BS LFP14S Replace Sizes YTX9-BS YTZ10S YTX12-BS YT12B-BS YTZ14S Type Lithium - Ion Battery Chemistry Lithium Iron Phosphate (LiFePO4) Nominal Voltage (V) 12.8 Amp-Hours Watt-Hours (Wh) 64.0 76.8 76.8 76.8 76.8 Starting Current Continuous Current Charging Voltage (V) 14.6V Charging Current (A)
  • Page 6 Technical Specifications LFP14-BS LFP14L-BS LFP20L-BS LFP30L-BS Replace Sizes YTX20L,YTX14H YTX14L-BS YTX20L,YTX20L-BS,YB16CL-B YIX30L,YIX30L-BS,YB30L-B,YB30CL-B Type Lithium - Ion Battery Chemistry Lithium Iron Phosphate (LiFePO4) Nominal Voltage (V) 12.8 Amp-Hours Watt-Hours (Wh) 102.40 102.40 153.60 230.40 Starting Current Continuous Current Charging Voltage (V) 14.6V Charging Current (A) 8A (Max)
  • Page 7 48 hours. Hicrank guarantees that this product (the "Product") will be free from defects in materials and workmanship for one (1) year from the date of purchase (the " Warranty Period"). During this Warranty Period, Hicrank will determine at its discretion whether to repair or replace any defective Product.
  • Page 8: Important Safety Warnings

    14.6V. Use caution with low-quality chargers, as they can pose severe electrical risks, leading to personal injury, property damage, shortened product life, and product failure. Hicrank is not responsible for the safety of using accessories or chargers not approved by Hicrank.
  • Page 9 Minors. If the "Purchaser" intends for a minor to use the product, the adult Purchaser agrees to provide detailed instructions and warnings to any minor prior to use. The "Purchaser" agrees to indemnify Hicrank for any accidental use or misuse by a minor.

This manual is also suitable for:

Lfp5l-bsLfp7l-bsLfp7sLfp7a-bsLfp9-bsLfp10s ... Show all
