Hicrank LFP4L-BS User Manual & Warranty

Lithium powersports batteries
Hide thumbs

Advertisement

Quick Links

Download this manual
User Guide &Warranty
LITHIUM
POWERSPORTS
BATTERIES

Advertisement

loading
Need help?

Need help?

Do you have a question about the LFP4L-BS and is the answer not in the manual?

Questions and answers

Related Manuals for Hicrank LFP4L-BS

Summary of Contents for Hicrank LFP4L-BS

  • Page 1 User Guide &Warranty LITHIUM POWERSPORTS BATTERIES...
  • Page 2 Hicrank User Guide & Warranty Lithium Powersports Batteries Warnings: BEFORE USING THIS PRODUCT, PLEASE CAREFULLY READ AND UNDERSTAND THE SAFETY INFORMATION. Failure to follow these safety instructions may result in ELECTRICAL SHOCK, EXPLOSION, FIRE, potentially leading to SERIOUS INJURY, DEATH, or PROPERTY DAMAGE.

  • Page 3: Installation

    Below is a table displaying the charging times based on a 100% depth of discharge (DOD) with the recommended smart battery chargers: Battery Models 12V1A Charger 12V2A Charger 12V5A Charger LFP4L-BS,5L-BS,7L-BS,7S,7A-BS Recommended Not Recommended Not Available LFP9-BS,10S,12A,12-BS,12S,14S Not Recommended...
  • Page 4 Full function Battery Management System The product is equipped with a Battery Management System (BMS) that monitors the internal lithium-ion batteries and disconnects them in case of a fault. The BMS prevents overcharging, over-discharging, overcurrent, short circuits, overheating, and thermal faults. It also includes battery balancing to maintain voltage equilibrium among individual batteries, ensuring optimal battery performance.

  • Page 5: Technical Specifications

    Technical Specifications LFP4L-BS LFP5L-BS LFP7SL LFP7B-BS LFP7A-BS Replace Sizes YTX4L-BS, YTZ5S YTX5L-BS, YTZ6V YTZ7SL,YTX7L-BS YT7B-BS,GT7B-4 LFP7A-BS Type Lithium - Ion Battery Chemistry Lithium Iron Phosphate (LiFePO4) Nominal Voltage (V) 12.8 Amp-Hours Watt-Hours (Wh) 25.6 38.4 51.2 51.2 51.2 Starting Current...
  • Page 6 Technical Specifications LFP9-BS LFP10S LFP12-BS LFP12B-BS LFP14S Replace Sizes YTX9-BS YTZ10S YTX12-BS YT12B-BS YTZ14S Type Lithium - Ion Battery Chemistry Lithium Iron Phosphate (LiFePO4) Nominal Voltage (V) 12.8 Amp-Hours Watt-Hours (Wh) 64.0 76.8 76.8 76.8 76.8 Starting Current Continuous Current Charging Voltage (V) 14.6V Charging Current (A)
  • Page 7 Technical Specifications LFP14-BS LFP14L-BS LFP20L-BS LFP30L-BS Replace Sizes YTX20L,YTX14H YTX14L-BS YTX20L,YTX20L-BS,YB16CL-B YIX30L,YIX30L-BS,YB30L-B,YB30CL-B Type Lithium - Ion Battery Chemistry Lithium Iron Phosphate (LiFePO4) Nominal Voltage (V) 12.8 Amp-Hours Watt-Hours (Wh) 102.40 102.40 153.60 230.40 Starting Current Continuous Current Charging Voltage (V) 14.6V Charging Current (A) 8A (Max)
  • Page 8 48 hours. Hicrank guarantees that this product (the "Product") will be free from defects in materials and workmanship for one (1) year from the date of purchase (the " Warranty Period"). During this Warranty Period, Hicrank will determine at its discretion whether to repair or replace any defective Product.

  • Page 9: Important Safety

    Important Safety Warnings Operation. Operating temperature range is -4ºF(-20ºC) to 140ºF(60ºC). Charging temperature range is 14ºF(-10ºC) to 122ºF(50ºC). Do not operate outside the recommended temperature ranges. Storage. Recommended storage temperature range is -4ºF(-20ºC) to 140ºF(60ºC). Do not exceed 140ºF(60ºC) under any circumstances. For optimal lifespan, store at 25ºC and maintain a state of charge above 70%. Self-discharge rate is less than 1%/month.
  • Page 10 Retrofit. Lithium-ion batteries are significantly lighter than lead-acid batteries of comparable capacity. Some equipment is designed to utilize th weight of lead-acid batteries for weight distribution. Using this product as a replacement battery may affect the weight distribution of the equipment. Understand the consequences of changing the weight distribution and ensure safe weight distribution.
  • Page 11 Personal Protection. Use this product only as intended. In case of an emergency, have someone present when using this product. When working near batteries, wear full protective gear, including eye protection and protective clothing. Wash hands after handling batteries and related materials. Do not wear any metal objects, including tools, watches, or jewelry, when handling batteries, as they can cause sparks or short circuits, leading to electric shock , fire, explosion, and resulting injury, death, or property damage Proposition 65.
  • Page 12 Medical Devices. This product may emit electromagnetic fields. It contains magnetic components that may interfere with pacemakers, defibrillators, or other medical devices. Consult your doctor before use. If you suspect this product is interfering with medical equipment, stop using it immediately and consult your doctor. Disposal.

This manual is also suitable for:

Lfp5l-bsLfp7l-bsLfp7sLfp7a-bsLfp9-bsLfp9-10s ... Show all
