Hillsdale Furniture HASTINGS 50975A Manual

Examine all packaging material for small parts that may have come loose during shipment. Periodic checks are recommended to insure that all
components are in proper position, tight and free from damage. Keep this assembly instruction for future reference. Adult assembly is required.
The product of Hillsdale Furniture, LLC is designed for residential use only. Customer Service Phone Number: 502-562-0000
HARDWARE LIST
A (4) Long Allen Bolts 1/4" x 1-1/2"
B (4) Allen Bolts 1/4" x 5/8"
C (8) Flat Washers
D (8) Spring Washers
E (1) Allen Wrench
PARTS LIST
F (1) Seat
G (2) Leg Panels
H (1) Support Ring
F
G
C C
D D
B B
CARE & MAINTENANCE: The touch of a soft cloth is all the maintenance the finish will ever need. Please do not use harsh or abrasive cleaners for polishing,
as they may cause damage to the finish. Periodic checks are recommended to make sure that all hardware is securely tightened.
HASTINGS VANITY STOOL
C C
C C
D D
D D
A A
A A
H
C C
C C
D D
D D
B B
B B
Model #50975
PART QTY
A 4
C 8
E 1
STEP 1
Begin assembly by crossing the Leg
Panels (G). Then insert the Support Ring
(H) on to the legs and secure it with 1
Allen Bolt (B), 1 Spring Washer (D) and 1
Flat Washer (C) per leg.
STEP 2
Attach Seat (F) to top of Leg Panels (G)
G
using 4 Long Allen Bolts (A), 4 Spring
Washers (D) and 4 Flat Washers (C).
Tighten all bolts with Allen Wrench (E)
provided. The assembly is now complete.
C C
D D
B B
HARDWARE PART QTY
B
D
