Delta Nicoli 15849LF Series Manual

15849LF▲
Submitted Model No.:
Specific Features:
8 1/16"
(206 mm)
6"
(152 mm)
1 1/8"~1 1/2"
(29~38 mm)
Hole Size
3/8" Compression
Fitting
▲ Designate proper finish suffix
Delta reserves the right (1) to make changes in specifications and materials, and (2) to change or discontinue
models, both without notice or obligation. Dimensions are for reference only. See current full-line price book or
www.deltafaucet.com for finish options and product availability.
DSP-L-15849LF Rev. B
15849LF▲
With Escutcheon
9 1/16"
(230 mm)
5 1/2"
(140 mm)
4 7/8"
(124 mm)
2 3/16"
(55 mm)
3" (76 mm)
Max. Desk
Thinkness
27 7/16"
(696 mm)
RP100137p
2 1/4"
Push Pop-UP
(56 mm)
8 3/4"
(221 mm)
BATHROOM FAUCET
Min. 2 1/2" (64 mm)
Clearance to Back Splash
Recommended
WARRANTY
• Parts and Finish - Lifetime limited warranty; or
• Electronic Parts and Batteries (if applicable) -
Dia.
1 5/8" (42 mm)
to
2 3/8" (61 mm)
1 1/4"
(32 mm)
Dia.
Single Handle Deck Mount
STANDARD SPECIFICATIONS:
• Maximum low rate 1.2 gpm @ 60 psi, 4.5 L/min @ 414 kPa.
• One or three hole mount (escutcheon optional, included).
• Polymer braided lexible supply hose with
3/8" compression itting thread connection
• Control mechanism is replaceable cartridge with
ceramic plates.
• Model has push pop-up with overf low
for commercial purchasers, 10 years for multi-family
residential (apartments and condominiums) and
5 years for all other commercial uses, in each case
from the date of purchase.
5 years from the date of purchase; or for commercial
purchasers, 1 year from the date of purchase. No
warranty is provided on batteries.
COMPLIES WITH:
• ASME A112.18.1 / CSA B125.1
• ASME A112.18.2 / CSA B125.2
Indicates compliance to
ICC / ANSI A117.1 - Valve control only
®
• EPA WaterSense
Delta Faucet Company
55 E. 111th Street, Indianapolis, Indiana 46280
350 South Edgeware Road, St. Thomas, Ontario Canada N5P 4L1
© 2022 Delta Faucet Company
