I N S T R U C T I O N S
Elongated Tall-ette
With Bolt-Down Lok-In-El
For Catalog Numbers 72583-1002, 72583-1004 and 72583-1006
Place the Tall-ette® Elevated Toilet Seat upside down on a table or bench with its two
bracket holes visible. Hold the Lok-In-El®
Bracket with the two pegs lined up with the
holes on the seat. The bolt-down bracket
tongue should be facing away from the
seat. Press the pegs into the holes until the
bracket is in place.
To Install on Toilet:
1. Loosen the nuts on the toilet seat
bracket that hold the toilet seat and lid
to the bowl. Be sure to loosen them
enough to slide the Lok-In-El® bracket
between the seat and the bowl.
2. Lift the toilet seat to a raised position
and pull up slightly - approximately
3/8".
3. Slide the Lok-In-El® bracket tongue
under the seat bracket so that the wide
section fits between the toilet seat
screws and the two narrow sections fit
outside of the screws.
4. Tighten the nuts on the screws to
secure the seat and bracket. The Tall-
ette® Elevated Toilet Seat should be in
contact with the china bowl with the
bottom flange fitting inside the rim of
the toilet bowl. Before tightening the
screws, move the seat forward as much
as possible to make sure the seat sits firmly in the bowl.
If you require further assistance in the installation, operation or use of this product please
contact us.
Caution:
Do not use these models without the Lok-In-El® Bracket.
Do not remove the Lok-In-El® Bracket.
Do not use the Tall-Ette® Elevated Toilet Seat if it does not fit into the toilet bowl rim.
6 INDUSTRIAL ROAD • PEQUANNOCK, NJ 07440-1993 USA
973-628-7600 •
fax
972583101
973-305-0841 •
email
® Elevated Toilet Seats
Arrows
Show Where
Pegs Fit
Tall-Ette®
Elevated
Toilet Seat
Lok-In-El®
Bracket
Screw Cap
Screw
Toilet Bowl (tank
removed for illustra-
tion purposes only)
custservice@maddak.com • www.maddak.com
® Bracket
Seat Bracket
(seat and lid
removed for
illustration
purposes only
