Important Safety Information • Please carefully read all instructions before attempting installation. If you have any questions or concerns, please email customer service. • Before starting assembly, verify all parts are included and undamaged. DO NOT use damaged or defective parts. lf you require replacement parts, please email customer service.
Page 4
Supplied Parts and Hardware Desktop Stand Panel Desktop [1] x 1 [3] x 1 [2] x 1 Top Shelf Upper Panel [6] x 1 Top Shelf Vertical Panel Bottom Shelf Panel Side Table Panel Top Shelf Lower Panel [8] x 3 [4] x 1 [5] x 1 [7] x 1...
Page 5
Top Front Tube Middle Long Tube [21] x 1 [18] x 1 Top Front Tube Top Rear Tube [19] x 1 [22] x 1 Top Rear Tube Middle Short Tube [20] x 1 [23] x 1 Bottom Short Tube Top Shelf Support Stand Support [24] x 2 [25] x 2...
IMPORTANT INSTALLATION TIP: Align and loosely thread all bolts into the corresponding holes before fully tightening each bolt one by one. Loosely Thread Loosely Thread Fully Tighten Fully Tighten NOTE: Please note the distinction between the bottom and top of mesh shelves. Bottom Recessed Mesh Recessed Mesh...
Page 7
STEP 2 Assemble the Side Table [16] x 1 [A] x 4 [K] x 1 NOTE: The support bars on desk legs [14] and [15] must face in with the lip toward the back. [5] x 1 [A] x 4 [K] x 1 [E] x 2 [J] x 1 [M] x 1 [29a] x 1 [29b] x 1...
Page 8
STEP 3 Connect the Desk Legs [18] x 1 [19] x 1 [20] x 1 [A] x 6 [K] x 1 NOTE: To avoid unsuccessful installation, follow the hole placement indicated on the diagram when placing the three horizontal tubes [18], [19], and [20]. [4] x 1 [24] x 2 [A] x 4 [K] x 1 Flip...
Page 10
STEP 4A Connect Two Sections of Desk Frame [21] x 1 [22] x 1 [23] x 1 [A] x 8 [G] x 1 [K] x 1 [L] x 1 NOTE: Large holes face up. Fully tighten these two bolts [A] before attaching the desktop.
Page 11
STEP 4B Connect Two Sections of Desk Frame [21] x 1 [22] x 1 [23] x 1 [A] x 8 [G] x 1 [K] x 1 [L] x 1 NOTE: Large holes face up. Fully tighten these two bolts [A] before attaching the desktop.
The installation process from this page to the end is the same for either Option A or Option B. Follow these instructions to install it correctly. STEP 5 Attach the Stand [13] x 2 [A] x 4 [K] x 1 [3] x 1 [26] x 1 [A] x 2 [K] x 1 [A] x 2 [K] x 1...
Page 13
STEP 6 Attach the Top Shelf [12] x 2 [C] x 4 [G] x 4 [K] x 1 [L] x 1 G G G G [25] x 2 [A] x 4 [K] x 1 [6] x 1 [7] x 1 [8] x 3 [D] x 12 [K] x 1...
Page 14
[A] x 4 [K] x 1 A A A A A A A A D D D D [D] x 4 [K] x 1 STEP 7 Attach the Support Bars on the Back [27] x 4 [A] x 4 [B] x 2 [G] x 6 [K] x 1 [L] x 1...
Page 15
STEP 8 Attach the Power Outlet and Light Strip [28] x 1 [30] x 1 [F] x 2 [M] x 1 Remember to fully tighten all bolts, screws and nuts. Level Adjustment Lower Lower Raise Raise NOTE: If the unit is not level, adjust the feet by turning to raise or lower each corner.
Using the Remote Control Static Brightness (-) Dynamic Speed (-) Power Off Power On Static Brightness (+) Dynamic Speed (+) Dynamic Mode Static Mode (16 Colors) NOTE: To use the remote control, it must be pointed directly at the sensor on the light strip. 860-00959-00 Rev02...
