Marsail TZESD14B Instruction Manual

Electric standing desk
Hide thumbs

Advertisement

Table of Contents

Electric Standing Desk Instruction Manual
Thank you for choosing this product! We strive to provide you with the best
quality products and service in the industry. Should you have any issues,
please don't hesitate to contact us at service.wowowo@gmail.com
TZESD14B / TZESD14V / TZESD14N
TZESD15B / TZESD15V / TZESD15N
Model:
Rev01(A)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TZESD14B and is the answer not in the manual?

Questions and answers

Related Manuals for Marsail TZESD14B

Summary of Contents for Marsail TZESD14B

  • Page 1 Electric Standing Desk Instruction Manual Rev01(A) Model: TZESD14B / TZESD14V / TZESD14N TZESD15B / TZESD15V / TZESD15N Thank you for choosing this product! We strive to provide you with the best quality products and service in the industry. Should you have any issues,...

  • Page 2: Specifications

    Specifications Height Adjustment Range: RATED 27.5″-46.7″ (70-118cm) Power Input Max Speed Operating Noise Max Load 100V-240V 25mm/s ＜50dB 176 lbs / 80kg Tools Needed (not included) Drill Phillips Screwdriver Supplied Parts and Hardware for Step 1 Bolt Bolt M6 x 25mm M6 x 16mm Set Screw x 12...
  • Page 3 Supplied Parts and Hardware for Step 2 Cable Desktop Panel Management Screw Screw Bracket Connector Desktop ST3.9 x 13mm ST5 x 16mm Wood Dowel Pin Note: An extra wood dowel pin is (for 48″) provided for the longer 55″ desk. (for 55″) Supplied Parts and Hardware for Step 3 Screw...

  • Page 4: Step 1: Assembling The Frame

    Drawer Slide Wood Dowel Pin Keyboard Tray Left Keyboard Right Keyboard Keyboard Tray Side Plate Tray Side Plate Stopper Supplied Parts and Hardware for Step 5 Power Cable Cable Clip Step 1: Assembling the Frame Align holes in the crossbar with holes in the desk legs, and insert four bolts. Partially and then fully tighten each pair of bolts, making sure the legs fit smoothly into the crossbar grooves.
  • Page 5 Insert four bolts through each leg base and into each leg. Partially and then fully tighten the bolts in each leg. Attach the side plates.
  • Page 6 Slide the rod coupler onto the end of the motor drive shaft on the right leg. Note: Make sure the holes for set screws face out. Fig 1 Adjust uneven desk legs: Before attaching the transmission rod, measure the heights of the two desk Fig 2 legs to see if they are set at the same level.
  • Page 7 Note: Ensure the transmission rod is properly inserted into the hole in If the transmission the left leg. Slide the rod coupler to the left to connect with the rod doesn't fit smoothly other end of the transmission rod. into the rod coupler, fine-tune with the wrench.
  • Page 8 Ensure the rubber pads are attached to the frame. If any have fallen off, reattach them or use the spare rubber pads. Tall rubber pads Step 2: Assembling the Desktop Attach the cable management bracket to the desktop. Phillips Drill Screwdriver (not included) (not included)
  • Page 9 For the 48″ long desk, use the five wood dowel pins to join the two desktop panels together. For the 55″ long desk, use the six wood dowel pins to join the two desktop panels together.
  • Page 10 Secure the desktop panels with the connectors. Step 3: Attaching the Desktop Attach the frame to the desktop. Phillips Drill Screwdriver (not included) (not included) You can use a drill (with suitable torque and speed) or a Phillips screwdriver. Note: An off-center screw hole is not a problem. The pre-drilled holes are only guides for easier screw-in.
  • Page 11 Put the AC adapter into the holder. Attach the controller, AC adapter with holder, and storage hooks to the desktop.
  • Page 12 Step 4: Assembling the Keyboard Tray Detach the inner and outer parts of the two drawer slides. Attach the outer parts of the two drawer slides to the left and right keyboard tray side plates. Phillips Drill Screwdriver (not included) (not included) You can use a drill (with suitable torque and speed)
  • Page 13 Attach the keyboard stoppers. Then attach the inner parts of the two drawer slides to the keyboard tray. Note: Note the position of the indents on the inner parts of the drawer slides in this step. Screw the cam bolts and push the wood dowel pins into the desktop. Attach the keyboard tray side plates to the desktop.

  • Page 14: Step 5: Connecting The Cables

    Step 5: Connecting the Cables Motor Cable Motor Cable Motor Cable Step 6: Inserting the Keyboard Tray Note: Note the position of the keyboard stoppers in this step.

  • Page 15: Using The Controller

    Using the Controller Note: Ensure that there are no obstacles when using the desk, that the desktop is not right next to the wall, and that all cables are long enough for the desk to move up and down freely. When the controller screen is off (power-saving mode), press any button to wake it before operating the desk.

  • Page 16: Troubleshooting

    Settings 1. Press and hold the button until the desk goes down to its lowest level, and then release the button. 2. Press and hold the button for 5 seconds until the screen displays Reset ‘RST,’ and then release the button with ‘RST’ flashing. 3.
