DeLUX M800DB Manual

PRO-GAMING MOUSE
Thank you for choosing our gaming mouse. Please read the user
manual carefully before and when you use this product.
Packaqe content
Mouse x 1
Compatibility
Compatible with Windows 7, Windows 8, Windows 10,
Mac OS (Only basic function, no software available)
Keys Function
①
⑤
⑥
⑧
Specification
Mouse size
DPI
Working Voltage
Working Current
LR Key Switch
Battery
Foot pad material
Weight
Mouse Usage
1. Power Charging
Connecting the cable and mouse, when charging the indicator turn
red, after full charged the indicator turn off.
2. Wired/Wireless mode
When connected the device with cable, the mouse will enter wired
mode automatically; while only insert the USB receiver, the mouse
will enter wireless mode.
3. Wireless Pairing
Press the left button, right button and the scroll wheel at the same
time for 3s entering 2.4G pairing mode, the whole mouse light will
turn blue and flash. Then plug receiver to device, when the blue
light off and turn Neon mode, the mouse pairing successfully. If the
pairing failed, try it again.
4. Light mode switch
Press scroll wheel + backward key at the same time to switch
among 4 lighting modes: Neon, Steady, Breathing, Led off.
5. DPI
Press the DPI key switch among 5 gear DPI.
Scroll Wheel Light Color----DPI
Red--------------------------400DPI
Green-----------------------800DPI
6. Low battery
When low power occurs, the light of mouse turns red and flashes,
please charge in time.
Driver setting
1. Installation
Download the driver from
https://www.deluxworld.com/en/service/download/
and install the driver.
Note: Please make sure this mouse is already connected to
computer when setting the functions in the driver. After installing,
you can proceed button setting, lighting setting, DPI setting, Macro
setting and so on.
2. Settings
Open driver setting interface (mouse must be connected, otherwise
driver software unable to be opened):
a.Multi-group setting are available to be proceeded;
b.The battery power can be displayed in wireless mode, and the
charging status can be displayed in wired mode;
c.The default state can be restored after clicking the "Restore" button.
A.Button Setting
Click button list to set the button function, proceeding left button,
right button,middle button, forward, backward, three click, fire key,
key combination, DPI level, multimedia function, etc. Click it to load
automatically to complete the setting.
B.Power Manager
a. The battery down time can be set to 3-10 minutes. After sleep,
you need to click the button to wake up the mouse;
b. You can choose to turn off the light while mouse move. After
click,the decorative light will automatically turn off when the
mouse moves. When the mouse stops moving, the light keeps
on for 1 minute, and then enter hibernation mode.
C.DPI Setting
Click "DPI Setting" to proceed DPI gear, DPI value modification,
lighting color for different DPI value.
D.Lighting Setting
Click "Lighting " to set the overall lighting effect of the mouse and
select different lighting modes to make the mouse display different
lighting effects. Color and speed are adjustable.
E.Polling Rate Setting
Four level polling rate can be chosen: 125Hz-250Hz-500Hz-1000Hz.
F.LOD Setting
Click "Mouse LOD Height" to enter mouse mouse height lifted
setting, adjusting height low gear to be 1mm or 2mm.
G.Parameter Setting
Click "Mouse Parameter" to enter the system mouse setting interface.
H.Macro Setting
Click "Macro Editor", entering the macro setting interface, click
"new", input macro name, select "start record", during the recording
process, you can enter the required keys on the keyboard, then
click "stop record";
Operation instructions after entering Macro edition interface: select
the key you want to set, click "macro" in the drop-down list, select
and click the macro name to set successfully.
----- Wireless
Manual x 1
PRO-GAMING MOUSE
123.6x63.8x38.3mm
400-800(default)-1600-3200-5000
5V
≤ 500mA
60million
500mAH built-in battery
Teflon
70g
1.6m Type-C cable x 1
①
②
③
②
④
③
④
⑤
⑥
⑦
⑦
⑧
⑨
⑨
Blue-----------------------1600DPI
Purple---------------------3200DPI
Yellow---------------------5000DPI
Left click
Right click
Scroll wheel
DPI button
Forward Button
Backward Button
Charging Indicator
USB receiver
ON/OFF
1.
2.
3.
4.
5.
6.
7.
8.
9.
