- Page 1 GL865T-DUAL Hardware User Guide Rev01 - 02.10.2012 Mustafa Kemal Mah. 2131 Sok. No: 32/2 06510 Söğütözü, Çankaya, ANKARA /TURKIYE Tel: +90 (312) 443 03 04 - Faks: +90 (312) 443 09 69...
-
Page 2: Table Of Contents
Contents Description ……………………………………………………………………………………………….… 3 General Features ………………………………………………………………………………………… 4 Power …………………………………………………………………………………………………………. 5 Serial Port ………………………………………………………………………………………………..…. 5 Digital I/O & ADC …………………..………………………………………………………………….… 6 Antenna ………………………………………………………………………………………………….…… 6 Debug Port ………………………….……………………………………………………………………… 7 Analog Audio ……………………………………………………………………………………………… 7 Mustafa Kemal Mah. 2131 Sok. No: 32/2 06510 Söğütözü, Çankaya, ANKARA /TURKIYE Tel: +90 (312) 443 03 04 - Faks: +90 (312) 443 09 69... -
Page 3: Description
GL865T-DUAL offers extended operating temperature, integrated TCP/IP stack, direct control by standard serial RS-232 interface and with a broad supply voltage range (5-32 VDC - Min1.2A), the GL865T-DUAL terminal is a complete stand alone solution for m2m applications. GL865T-DUAL, supports Over-the-Air firmware update by means Premium FOTA Manage- ment. -
Page 4: General Features
2 General Features * Dual-band EGSM 900 / 1800 MHz, * Embedded Python Version 1.5.2 , * Serial Debug Port (Also 3.0V Fixed Voltage Output), * RS232 ınterface (DB9-Female), * Analog Audio Support (2.5mm jack, Mono-Mic & Mono-Ear), * 2 Digital Inputs, 2 Digital Outputs and 2 ADC Connections on GPIO socket, * Dimensions: 85 x 70 x 33 mm, * Weight: 140 grams, * SMA female, 50 Ohm RF connector,... -
Page 5: Power
3 Power Front View Pin Descriptions: * GND: Ground Reference * Input Power: 7-35V @ 1.2A min. * Reset: Active when Pulls Down to GND Power Connector 4 Serial Port The RS-232 port is available through D-TYPE 9 pin connector The main characteristics are: * Baud rate from 300 to 115,200 bits/s * Autobauding (300 to 38,400 bits/s) -
Page 6: Digital I/O & Adc
5 Digital I/O & ADC Front View The I/O port is available through 2x6 pin connector The Main Characteristics are: * 2 Digital Inputs (0-220VDC), * 2 Digital Open-Collector I/O Connector Outputs, * 2 ADC Inputs (0-2V) 6 Antenna ANTENNA REQUIREMENTS Standard Dual Band GSM/DCS frequency range or Standard Quad Band Frequency range GSM/DCS/PCS frequency range if used for all four bands... -
Page 7: Debug Port
7 Debug Port The Debug port is available Front View through 1x4 pin connector The Main Characteristics are: * 3V Fixed Output, * 2.8V Level Second Serial Port (RX_AUX & TX_AUX) Debug Connector 8 Analog Audio 2.5mm Audio Connector The Main Characteristics are: * Headset Connection including MIC and EAR, * Compatible with 2.5mm 3 channel... -
Page 8: Document Change Log
Document Change Log Revision Date Changes Mustafa Kemal Mah. 2131 Sok. No: 32/2 06510 Söğütözü, Çankaya, ANKARA /TURKIYE Tel: +90 (312) 443 03 04 - Faks: +90 (312) 443 09 69...
