- Page 1 GE864T-GPS Hardware User Guide Rev01 - 10.06.2013 Mustafa Kemal Mah. 2131 Sok. No: 32/2 06510 Söğütözü, Çankaya, ANKARA /TURKIYE Tel: +90 (312) 443 03 04 - Faks: +90 (312) 443 09 69...
- Page 2 Contents Description ……………………………………………………………………………………………….… 3 General Features ………………………………………………………………………………………… 4 Power …………………………………………………………………………………………………………. 5 Serial Port ………………………………………………………………………………………………..…. 5 Digital I/O & ADC …………………..………………………………………………………………….… 6 Antenna ………………………………………………………………………………………………….…… 6 Debug GPS Port …….…………….……………………………………………………………………… 7 Analog Audio ……………………………………………………………………………………………… 7 Mustafa Kemal Mah. 2131 Sok. No: 32/2 06510 Söğütözü, Çankaya, ANKARA /TURKIYE Tel: +90 (312) 443 03 04 - Faks: +90 (312) 443 09 69...
- Page 3 GE864T-GPS offers extended operating temperature, integrated TCP/IP stack,direct cont- rol by standard serial RS-232 interface and with a broad supply voltage range (5-32 VDC - Min1.2A), the GE864T-GPS terminal is a complete stand alone solution for m2m applicati- ons. GE864T-GPS Terminal is integrating full 48-channels A-GPS functionality. It combines the high performance from Telit's proven GSM/GPRS core technology with the latest SiRFstarIV™...
- Page 4 2 General Features * Quad-band EGSM 850/ 900 / 1800 /1900 MHz, * Embedded Python Version 1.5.2 , * Serial Debug GPS Port (Also 5.0V Fixed Voltage Output), * RS232 ınterface (DB9-Female), * Analog Audio Support (2.5mm jack, Mono-Mic & Mono-Ear), * 2 Digital Inputs, 2 Digital Outputs and 2 ADC Connections on GPIO socket, * Dimensions: 85 x 70 x 33 mm, * Weight: 140 grams,...
- Page 5 3 Power Front View Pin Descriptions: * GND: Ground Reference * Input Power: 7-35V @ 1.2A min. * Reset: Active when Pulls Down to GND Power Connector 4 Serial Port The RS-232 port is available through D-TYPE 9 pin connector The main characteristics are: * Baud rate from 300 to 115,200 bits/s * Autobauding (300 to 38,400 bits/s)
- Page 6 5 Digital I/O & ADC Front View The I/O port is available through 2x6 pin connector The Main Characteristics are: * 2 Digital Inputs (0-220VDC), * 2 Digital Open-Collector I/O Connector Outputs, * 2 ADC Inputs (0-2V) Input1—>GPIO8 Output1—>GPIO6 Input2 —>GPIO9 Output2—>GPIO3 6 Antenna GSM ANTENNA REQUIREMENTS...
- Page 7 7 Debug Port The Debug port is available Front View through 1x4 pin connector The Main Characteristics are: * 5V Fixed Output, * 5V Level Second Serial Port NMEA GPS Serial Port Connector (GPS_TX_AUX & GPS_RX_AUX) 8 Analog Audio 2.5mm Audio Connector The Main Characteristics are: * Headset Connection including MIC and EAR,...
- Page 8 Document Change Log Revision Date Changes GPS Serial Debug NMEA Rev02 07.07.2014 port added Rev03 02.09.2015 GPIO Description added Mustafa Kemal Mah. 2131 Sok. No: 32/2 06510 Söğütözü, Çankaya, ANKARA /TURKIYE Tel: +90 (312) 443 03 04 - Faks: +90 (312) 443 09 69...
