Two Fixed Ir Outputs Plus ...; ...Two Variable Ir Outputs; Up To 15 Equipment Locations With Identical Components; Specifications - Universal Remote Control Complete Control MRF-260 Specification

Two adjustable IR line outputs.

Up To 15 Equipment Locations with Identical Components

Every URC Complete Control remote is "addressable." They can be programmed to specifically control
components in a particular room by installing an MRF-260 base station at each location. In operation it's
simple: when you select a device located in the Den, the remote only sends commands to the Den. When
you select a device located in the Family Room, the remote only sends commands there.
A MRF-260 Can Control an Array of Identical Components
or Identical Zones of a Multi Zone Preamp/Matrix Switcher
Each MRF-260 has four "addressable" IR Line Outputs. For example, you can control up to four identical
TV's with one MRF-260 or route volume commands for a specific zone to a particular zone IR input on a
multi-zone preamp. If you have more than four identical components or zones, up to 15 additional MRF-
260s can be installed to control them (thus allowing up to 60 identical components or zones in one house).

Specifications

Power Supply: 9V DC
IR Flasher Line Outputs: 3.5mm Mono Mini Jack
COMPLETE
COMPLETE
CONTROL

Two Fixed IR Outputs Plus ...

The MRF-260 is equipped with two fixed IR line outputs with standard
NOTE: The MRF-260 is ONLY compatible with Narrow Band remotes: the current versions of
the MX-3000, MX-950, MX-900, TX-1000, MX-850, MX-650 and the MX-350 remote controls. The
MRF-260 is compatible with all MX-950s, MX-900s and TX-1000s, but is NOT compatible with
MX-850, MX-650 or MX-350 remote controls manufactured before November 1, 2006 or an
MX-3000 built before April,2005.You can identify the build date of a remote control by looking at
the serial number. The first 6 digits indicate the build date. If the serial number appears as 122905
014054, the first 6 digits indicate that the remote was built on December 29, 2005.
(AC Adapter included)
™
500 Mamaroneck Avenue, Harrison, NY 10528
3.5 jacks for standard IR emitter/ flashers.

...Two Variable IR Outputs

The MRF-260 is equipped with two adjustable IR line outputs.
Each output can be individually matched to rear panel
RF Frequency: 418MHz Narrow Band RF
Size: 5" x 3.5" x 1.2" (W x D x H) w/o antenna
Weight: 1.3lbs.
The Pioneer in Control Technology
www.universalremote.com
IR inputs on any component that is designed
to be operated by a standard IR repeater.
The outputs utilize a 3.5mm jack and are
compatible with standard IR emitter/flashers
as well.
Two fixed IR line outputs.
Phone: (914) 835-4484 Fax: (914) 835-4532
