GP 7000F
M200, M200R, M400A, M400R, M600, M600R
Edition December 1999

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GR 7000F and is the answer not in the manual?

Questions and answers

Related Manuals for Fujitsu GR 7000F

Summary of Contents for Fujitsu GR 7000F

  • Page 1 All manuals and user guides at all-guides.com GP 7000F M200, M200R, M400A, M400R, M600, M600R Edition December 1999...

  • Page 2: Copyright And Trademarks

    All manuals and user guides at all-guides.com Copyright and Trademarks Copyright © Fujitsu Siemens Computers GmbH 1999. All rights reserved. Delivery subject to availability; right of technical modifications reserved. All hardware and software names used are trademarks of their respective manufacturers.
  • Page 3 All manuals and user guides at all-guides.com 1 Preface This manual contains the operating instructions for the GranPower7000 (GP 7000F) system from Fujitsu Siemens Computers. A chapter about the connection of Siemens specific de- vices precedes the actual operating instructions. U42335-J-Z775-1-76...
  • Page 4 All manuals and user guides at all-guides.com...
  • Page 5 2 Console connections to GP 7000F This chapter describes connections to the M200, M200R, M400A, M400R, M600 and M600R models of the Fujitsu Siemens Computers GP 7000F system with a view to attaching existing components of Siemens devices to Fujitsu equipment. Graphical or serial consoles can be connected.
  • Page 6 All manuals and user guides at all-guides.com Graphical console Console connections to GP 7000F The following technical requirements must be met in order to connect graphical consoles: – PCI graphics controller D:GP70F-CC10 The GP 7000F models can be made into a workstation or server with a graphical console by means of a PCI graphics card featuring a frame buffer.

  • Page 7: Serial Console

    All manuals and user guides at all-guides.com Console connections to GP 7000F Serial console 2.2 Serial console A converter is used here to convert the 25-pin connector of the GP 7000F system to the usual 9-pin V.24/COM connector. This converter is preinstalled at the factory. A VT100 or VT200 emulation must be available for a serial console to be used.

  • Page 8: Lan Console

    All manuals and user guides at all-guides.com Serial console Console connections to GP 7000F 2.2.1 LAN console A Solaris PC is connected as a LAN console via an RCA (Remote Communication Adapter) attached to the V.24 console interface. Up to six servers can be attached to one RCA. GP 7000F V.24 (A) system...
  • Page 9 All manuals and user guides at all-guides.com Console connections to GP 7000F Serial console 2.2.2 Standard PC with terminal emulation a) Windows 98 or NT (with NetTerm, for instance, but not with HyperTerminal) b) LINUX (with Minicom or Seyon) c) Solaris (cu) (NT, Windows) GP 7000F V.24 (A)
  • Page 10 All manuals and user guides at all-guides.com Teleservice Console connections to GP 7000F 2.2.3 TC20 or T100 Use of these terminals is intended as a migration solution only. α α α α console GP 7000F V.24 (A) system Teleservice V.24 (B) preferably 10/100 Mbit Eth Keyboard/mouse...
  • Page 11 All manuals and user guides at all-guides.com P321-E102-02EN USER'S MANUAL...
  • Page 12 All manuals and user guides at all-guides.com...

  • Page 13: For Safe Operation

    USE OF THE PRODUCT MAY CAUSE UNEXPECTED DAMAGE TO THE USERS OR BYSTANDERS. While all efforts have been made to ensure the accuracy of all information in this manual, FUJITSU assumes no liability to any party for any damage caused by errors or omissions or by statement of any kind in this manual, its updates or supplements, whether such errors are omissions or statements resulting from negligence, accidents, or any other cause.
  • Page 14 SUCH HAZARDOUS ENVIRONMENTS, FUJITSU LIMITED AND SUN MICROSYSTEMS, INC. DOES NOT WARRANT THEM AT ALL. FUJITSU reserves all the right to make changes to any products herein to improve reliability, function, or design, without further notice and without obligation. FCC Class A Notice This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules.

  • Page 15: Trademark Acknowledgments

    All rights reserved. This product and related documentation are protected by copyright and distributed under licenses restricting its use, copying, distribution, and recompilation. No part of this product or related documentation may be reproduced in any form by any means without prior written authorization of Fujitsu Limited and its licensors, if any.
  • Page 16 SPARC64 is a registered trademark or trademark of SPARC International, Inc. in the United States and other countries used under license by Fujitsu Ltd. Products bearing SPARC64 trademarks comply with SPARC V9 architecture developed by SPARC International, Inc. Products bearing the SPARC trademarks are based on an architecture originally developed by Sun Microsystems, Inc.
  • Page 17 All manuals and user guides at all-guides.com Preface This manual explains the function, configuration, and operation of GP7000F. This manual is intended for the experienced users who have a basic knowledge of computer systems. The structure of this manual is as follows: Introduction to Chapters CHAPTER 1 Product Outline Chapter 1 describes the distinctive features of GP7000F.
  • Page 18 All manuals and user guides at all-guides.com CHAPTER 12 External Interface Chapter 12 explains the external interface of the main cabinet such as UPS Control Interface, RS232C Interface, and Centronics Interface. CHAPTER 13 RCI Setting Chapter 13 explains the description of RCI commands to be used for managing nodes. CHAPTER 14 Troubleshooting Chapter 14 will help the user isolate the cause of system failures, and provides suggested solutions.
  • Page 19 All manuals and user guides at all-guides.com...

  • Page 20: Important Warnings

    All manuals and user guides at all-guides.com Important Warnings The following are cautions found in this manual. They have been compiled here with corresponding page references. A hazardous situation could result in minor or moderate personal injury if the CAUTION user does not perform the procedure correctly.
  • Page 21 All manuals and user guides at all-guides.com Task Warning System Installation Install "Basic Software Extension" or "Enhanced Support Facility"before operating the system. Without this package, incorrect front panel operations and hardware errors may cause the system to shutdown or destroy data. Disk Expansion Unit Be sure to replace the power supply fan when installing the Installation...
  • Page 22 All manuals and user guides at all-guides.com...

  • Page 23: Table Of Contents

    All manuals and user guides at all-guides.com CONTENTS CHAPTER 1 Product Outline Key Features : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : Operator Panel : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : External Interface...
  • Page 24 All manuals and user guides at all-guides.com CHAPTER 3 M200R Main Cabinet Overview : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : Device Configuration : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : Systemboard...
  • Page 25 All manuals and user guides at all-guides.com CONTENTS Systemboard : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : Disk Units : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : PCI Slots...
  • Page 26 All manuals and user guides at all-guides.com 10.2 Device Configuration : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : 10.3 Hot System Replacement : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : :...
  • Page 27 All manuals and user guides at all-guides.com CONTENTS 14.4 SCF Error Messages : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : :...
  • Page 28 All manuals and user guides at all-guides.com...
  • Page 29 All manuals and user guides at all-guides.com ILLUSTRATIONS Figure 1.1 Operator Panel (M200, M600) : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : Figure 1.2 Operator Panel (M200R, M400A, M400R, M600R) : : : : : : : : : : : : : : : : : : :...
  • Page 30 All manuals and user guides at all-guides.com Figure 6.2 Open View of M600 Main Cabinet : : : : : : : : : : : : : : : : : : : : : : : : : : : : Figure 6.3 Rear View of M600 Main Cabinet : : : : : : : : : : : : : : : : : : : : : : : : : : : :...
  • Page 31 All manuals and user guides at all-guides.com ILLUSTRATIONS Figure 12.1 Signal Configuration : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : Figure 12.2 Configuration of Signal Line when Connecting DCE Device(Example) : : : : : : : : : :...
  • Page 32 All manuals and user guides at all-guides.com TABLES Table 1.1 Data Protection for Components and Interfaces : : : : : : : : : : : : : : : : : : : : : : Table 1.2 POWER LED : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : Table 1.3...
  • Page 33 All manuals and user guides at all-guides.com TABLES Table 5.1 Fans : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : Table 5.2 Power Supply Units : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : :...
  • Page 34 All manuals and user guides at all-guides.com Table 11.5 8-mm Tape Cartridge Capacity : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : Table 11.6 QIC Tape Cartridge Capacity : : : : : : : : : : : : : : : : : : : : : : : : : : : : : : :...

  • Page 35: Product Outline

    All manuals and user guides at all-guides.com CHAPTER 1 Product Outline CONTENTS Key Features ..................Operator Panel .

  • Page 36: Key Features

    All manuals and user guides at all-guides.com CHAPTER 1 Product Outline 1.1 Key Features The GP7000F is SMP (Symmetric Multi-Processor) servers with 64-bit SPARC64 GP processors. Each model in the group has high-performance 64-bit processors, high-speed I/O interfaces and enhanced reliability, availability, and serviceability (RAS) features.

  • Page 37: Table 1.1 Data Protection For Components And Interfaces

    All manuals and user guides at all-guides.com 1.1 Key Features High-speed I/O interface  One built-in 40 MB/s UltraSCSI Single-Ended interface for internal devices.  One built-in 100BASE-TX interface (10/100 Mbps, auto-sensing).  The GP7000F has some 64-bits PCI (Peripheral Component Interconnect) buses.  Additional interfaces, such as 100BASE-TX, FDDI, ATM, can be provided by installing PCI cards.
  • Page 38 All manuals and user guides at all-guides.com CHAPTER 1 Product Outline  A SCF (System Control Facility), which has an integrated service processor, monitors the operation of SPARC64 GP processors, and reports erroneous events such as environmental monitoring explained below. With a GUI-based intelligent monitoring and reporting tool, which is provided in "Basic Software Extension"...

  • Page 39: Figure 1.1 Operator Panel (M200, M600)

    All manuals and user guides at all-guides.com 1.2 Operator Panel 1.2 Operator Panel The operator panel has a set of status LEDs, switches, and a LCD panel. The switches as well as built-in I/O device are covered with a panel cover that can be locked with a key. It prevents incorrect operations and ensures security for the internal I/O device as well as the switches.

  • Page 40: Table 1.2 Power Led

    All manuals and user guides at all-guides.com CHAPTER 1 Product Outline LED (CHECK LED/POWER LED) The POWER LED indicates whether the system is turned on while the CHECK LED indicates system operation by lighting up or blinking. Table 1.2 POWER LED Status Descriptions The power is on...
  • Page 41 All manuals and user guides at all-guides.com 1.2 Operator Panel Switches There are 4 switches on the operator panel, as below. POWER switch The user can turn on and off the system by pressing this switch. The POWER switch operation is managed by the setting of the MODE switch as well as software setting with "scftool".

  • Page 42: External Interface

    All manuals and user guides at all-guides.com CHAPTER 1 Product Outline Be sure to install software packages in the "Basic Software Extension" or CAUTION "Enhanced Support Facility". Otherwise, above switch functions or proper messages on LCD panel are not guaranteed. IMPORTANT Under the MANUAL and AUTO state, keyboard STOP+A command and terminal break command will abort booting-up the system or halt the system while operating system is running.

  • Page 43: Table 1.5 Connectors And Switches

    All manuals and user guides at all-guides.com 1.3 External Interface Table 1.5 Connectors and Switches Connector/ Marking Type Remarks Switch RS232C SERIAL A/B Dsub/25 pin* The same connector as Parallel 8-pin DIN Connect a mouse via a keyboard Parallel PARALLEL Dsub/25 pin* AT compatible 10 Mb/100Mb...

  • Page 44: Console

    All manuals and user guides at all-guides.com CHAPTER 1 Product Outline Console Serial Terminal If your GP7000F has no local graphic console, a serial terminal, such as Personal Computer, should be attached to the GP7000F in order to install the system and to run diagnostic programs. To attach a serial terminal :  Connect a terminal data cable to serial port A on your server.

  • Page 45: Power On/Off

    All manuals and user guides at all-guides.com 1.5 Power On/Off 1.5 Power On/Off Power On After connected cables necessary to the system as well as console (or local graphic display), take the following procedures. Turn on any peripherals and external IO devices attached to the main cabinet as well as a terminal (or local graphic display).

  • Page 46: Installation Of Basic Software Extension Or Enhanced Support Facility

    All manuals and user guides at all-guides.com CHAPTER 1 Product Outline 1.6 Installation of Basic Software Extension or Enhanced Support Facility To enable support of GP7000F specific functions, software packages in the "Basic Software Extension" or "Enhanced Support Facility"are needed to install on the system. Please refer to the user’s guide and installation guide of the "Basic Software Extension"...
  • Page 47 All manuals and user guides at all-guides.com CHAPTER 2 M200 Main Cabinet CONTENTS Overview ..................Device Configuration .

  • Page 48: Figure 2.1 Front View Of M200 Main Cabinet

    All manuals and user guides at all-guides.com CHAPTER 2 M200 Main Cabinet 2.1 Overview Appearance CHECK LED ( amber ) Lock POWER LED ( green ) Stabilizing Feet Figure 2.1 Front View of M200 Main Cabinet Key Features  Up to 2 processors  16 DIMM slots.

  • Page 49: Device Configuration

    All manuals and user guides at all-guides.com 2.2 Device Configuration 2.2 Device Configuration The M200 main cabinet consists of the following components:  Desk-side type cabinet  Basic power supply and optional expansion power supply unit  Cooling fans  Systemboard  Processor modules  DIMM (Dual Inline Memory Module)  Operator panel...
  • Page 50 All manuals and user guides at all-guides.com CHAPTER 2 M200 Main Cabinet Front view of the M200 main cabinet Operation Panel Panel Cover DAT unit,8-mm Tape Unit, QIC Tape Unit( option ) CD-ROM Unit Floppy Disk Unit Front Cover Stabilizing Feet Figure 2.2 Open View of M200 Main Cabinet Panel cover...
  • Page 51 All manuals and user guides at all-guides.com 2.2 Device Configuration Fans Table 2.1 lists the fans installed in the M200 main cabinet. Table 2.1 Fans Name Shape Location Fan #0 120-mm (4.7 inch) square fan Behind the Systemboard Fan #1 120-mm (4.7 inch) square fan Under the disk unit Fan #2...

  • Page 52: Figure 2.3 Rear View Of M200 Main Cabinet

    All manuals and user guides at all-guides.com CHAPTER 2 M200 Main Cabinet AC Main Line Switch AC Power Input PCI slot #6 PCI slot #5 100BASE-TX PCI slot #4 Keyboard PCI slot #3 PCI slot #2 RS232C PCI slot #1 ( Port A) RS232C ( Port B )

  • Page 53: Figure 2.4 Systemboard Layout Of M200

    All manuals and user guides at all-guides.com 2.3 Systemboard 2.3 Systemboard Systemboard layout CPU module slots, memory module slots, and PCI slots are located on the Systemboard as described in Figure 2.4 . NVRAM SCF BOARD ONLY PCI Slot #6 PCI Slot #5 PCI Slot #4 PCI Slot #3...
  • Page 54 All manuals and user guides at all-guides.com CHAPTER 2 M200 Main Cabinet Memory configuration The M200 has 16 DIMM slots, allowing for as much as 4 gigabytes of main memory. When installing the DIMMs, the following conditions must be satisfied:  When installing the first set of DIMM, install a set of 4 modules of the same size in slots 0 to 3.

  • Page 55: Disk Units

    All manuals and user guides at all-guides.com 2.4 Disk Units The denominator indicates the size of the memory module for a slot (unit: megabytes); 0* indicates a faulty slot. The numerator indicates the size of the memory that is actually available for use. The numerator 0 indicates that no memory is used.
  • Page 56 All manuals and user guides at all-guides.com CHAPTER 2 M200 Main Cabinet Disk Expansion Unit By using the Disk Expansion Unit, up to 8 disk drives can be installed in the M200 main cabinet. The Disk Expansion Unit consists of the following components:  Disk cage (including SCSI-BP)  PCI adapter (UltraSCSI Wide Single-Ended)  Expansion power supply unit (requires changing to 120-mm (4.7 inch) square fan: included)

  • Page 57: Pci Slots

    All manuals and user guides at all-guides.com 2.5 PCI Slots 2.5 PCI Slots PCI slots configuration PCI slots are located on the Systemboard as described in Figure 2.4 , and each PCI slots has the following specifications. There are 4 separate PCI Bus channels: A, B, C, and D. All PCI slots provide for the full 64-bit data path and can accommodate both 32-bit and 64-bit data path cards.

  • Page 58: Table 2.3 Installation Specifications Of M200 Main Cabinet

    All manuals and user guides at all-guides.com CHAPTER 2 M200 Main Cabinet IMPORTANT If the above conditions are not satisfied, the M200 main cabinet may be damaged. Be sure to follow these precautions. Installation specifications Table 2.3 Installation Specifications of M200 Main Cabinet (1) Item Specification Mass...

  • Page 59: Table 2.4 Installation Specifications Of M200 Main Cabinet

    All manuals and user guides at all-guides.com 2.6 Installation Table 2.4 Installation Specifications of M200 Main Cabinet (2) Item Specification External dimension (unit:mm) Width 230 Depth 630 Height 700 (Front View) (Side View) Service area (unit:mm) Service area Top of Service area Service area the unit...
  • Page 60 All manuals and user guides at all-guides.com...
  • Page 61 All manuals and user guides at all-guides.com CHAPTER 3 M200R Main Cabinet CONTENTS Overview ..................Device Configuration .

  • Page 62: Figure 3.1 Front View Of M200R Main Cabinet

    All manuals and user guides at all-guides.com CHAPTER 3 M200R Main Cabinet 3.1 Overview Appearance POWER LED (green) CHECK LED (amber) Lock Figure 3.1 Front View of M200R Main Cabinet Key Features  Up to 2 processors  16 DIMM slots, up to 4 gigabytes of memory.  64-bits width, 4 PCI buses provide 6 PCI slots ( 2*33/66MHz + 4*33MHz).

  • Page 63: Figure 3.2 Open View Of M200R Main Cabinet

    All manuals and user guides at all-guides.com 3.2 Device Configuration 3.2 Device Configuration The M200R main cabinet consists of the following components:  RackMount type cabinet  Basic power supply and option redundant power supply unit  Cooling fans  Systemboard  Processor modules  DIMM (Dual Inline Memory Module)  Operator panel...

  • Page 64: Table 2.1 Fans

    All manuals and user guides at all-guides.com CHAPTER 3 M200R Main Cabinet Fans The Table 3.1 lists the fans installed in the M200R main cabinet. Table 3.1 Fans Name Tray # Location Fan #0 Tray #0 Right (front view) of the cabinet Fan #1 Fan #2 Tray #1...
  • Page 65 All manuals and user guides at all-guides.com 3.2 Device Configuration Rear of the M200R main cabinet AC input, power supplies (FEP) and some connectors are located on the rear of the M200R main cabinet as shown in the Figure 3.3 AC Power Input FEP#1(option) FEP#0...

  • Page 66: Figure 3.4 Systemboard Layout Of M200R

    All manuals and user guides at all-guides.com CHAPTER 3 M200R Main Cabinet 3.3 Systemboard Systemboard CPU module slots and memory module slots are located on Systemboard as described in Figure 3.4 . DIMM Slot #1 DIMM Slot #3 DIMM Slot #5 DIMM Slot #7 DIMM Slot #9 DIMM Slot #11...
  • Page 67 All manuals and user guides at all-guides.com 3.3 Systemboard Processor Configuration Up to 2 processors can be installed in the M200R main cabinet. When installing the processor modules, the following conditions must be satisfied:  The installed processor modules must be the same type (including the cache size).  Install a processor module in slot 0 before installing one in slot 1.

  • Page 68: Disk Units

    All manuals and user guides at all-guides.com CHAPTER 3 M200R Main Cabinet Example for normal operation === Memory =================== Type : SDRAM SLOT# Size [ Valid (MB) / Existing (MB) ] Total 00- 0- 3 256 / 256 256 / 256 256 / 256 256 / 256 : 1024 / 1024 MB...

  • Page 69: Pci Slots

    All manuals and user guides at all-guides.com 3.5 PCI Slots 3.5 PCI Slots PCI slots configuration PCI slots are located on the Systemboard as described in Figure 3.4 . There are 4 separate PCI Bus channels: A, B, C, and D. All PCI Bus slots provide for the full 64-bit data path and can accommodate both 32-bit and 64-bit data path cards.

  • Page 70: Installation

    All manuals and user guides at all-guides.com CHAPTER 3 M200R Main Cabinet 3.6 Installation Purpose The following installation instruction is intended to provide the product safety requirements which must be addressed when the end-use product manufacturer installs this product in their equipment. Note that the acceptability of the combination of this product in a rack should be re-determined by an appropriate certification body, if that combination is differ from the Table 3.4 .

  • Page 71: Table 3.4 Mounting Combination For Expansion Rack

    All manuals and user guides at all-guides.com 3.6 Installation IMPORTANT High Leakage Current may flow through Power Strip Earthing Conductor, if all power supply cords of this unit are connected to one Power Strip. Earth connection essential before connecting supply. Table 3.4 Mounting Combination for Expansion Rack Mounting Portion Priority in the Rack...
  • Page 72 All manuals and user guides at all-guides.com CHAPTER 3 M200R Main Cabinet Installation specifications Table 3.5 Installation Specifications of M200R (1) Item Specification Mass Up to 40kg (approx.88 lb) Single phase Single phase Power condition Input voltage 100 to 120 VAC 200 to 240 VAC (+-10%) (+-10%)

  • Page 73: Table 3.5 Installation Specifications Of M200R

    All manuals and user guides at all-guides.com 3.6 Installation Table 3.6 Installation Specifications of M200R (2) Item Specification External dimension Width 482 Depth 779 (unit:mm) Height 174 (Front of the cabinet) (Side of the cabinet) Service area 650 *2 (unit:mm) 695 *3 Rear 1000...
  • Page 74 All manuals and user guides at all-guides.com...
  • Page 75 All manuals and user guides at all-guides.com CHAPTER 4 M400A Main Cabinet CONTENTS Overview ..................Device Configuration .

  • Page 76: Figure 4.1 Front View Of M400A Main Cabinet

    All manuals and user guides at all-guides.com CHAPTER 4 M400A Main Cabinet 4.1 Overview Appearance CHECK LED POWER LED (amber) (green) Lock Figure 4.1 Front View of M400A Main Cabinet Key Features  Up to 4 processors  Up to 32 DIMM slots, 8 gigabytes of memory.  Up to 64-bits width, 8 PCI buses provide 12 PCI slots ( 4*33/66MHz + 8*33MHz).

  • Page 77: Device Configuration

    All manuals and user guides at all-guides.com 4.2 Device Configuration 4.2 Device Configuration The M400A main cabinet consists of the following components:  Floor stand cabinet  Basic power supply and option redundant power supply unit  Cooling fans  Systemboard  Processor modules  DIMM (Dual Inline Memory Module)  Operator panel...

  • Page 78: Table 4.1 Fans

    All manuals and user guides at all-guides.com CHAPTER 4 M400A Main Cabinet Panel cover The panel cover can be opened from its right side after unlocking it. Then you can access switches on the operator panel, CD-ROM unit, Floppy drive unit, tape unit, and so on. Fans The Table 4.1 lists the fans installed in the M400A main cabinet.

  • Page 79: Figure 4.3 Rear View Of M400A Main Cabinet

    All manuals and user guides at all-guides.com 4.2 Device Configuration Rear of the M400A main cabinet AC input, AC main line switch, power supplies (FEP) and some connectors are located on the rear of the M400A main cabinet as shown in the Figure 4.3 PCI slot Expansion System Board FEP#2...

  • Page 80: Figure 4.4 Systemboard Layout Of M400A

    All manuals and user guides at all-guides.com CHAPTER 4 M400A Main Cabinet 4.3 Systemboard Systemboard CPU module slots and memory module slots are located on Systemboard as described in Figure 4.4 . NVRAM Base System Board NVRAM Expansion System Board Figure 4.4 Systemboard Layout of M400A...
  • Page 81 All manuals and user guides at all-guides.com 4.3 Systemboard Processor Configuration Up to 4 CPU can be installed in the M400A main cabinet. When installing the processor modules, the following conditions must be satisfied:  The installed processor modules must be the same type (including the cache size).  Install a processor module in slot 0 before installing one in slot 1.

  • Page 82: Disk Units

    All manuals and user guides at all-guides.com CHAPTER 4 M400A Main Cabinet Example for normal operation === Memory =================== Type : SDRAM SLOT# Size [ Valid (MB) / Existing (MB) ] Total 00- 0- 3 256 / 256 256 / 256 256 / 256 256 / 256 : 1024 / 1024 MB...

  • Page 83: Table 4.3 Pci Slot Specifications

    All manuals and user guides at all-guides.com 4.5 PCI Slots 4.5 PCI Slots PCI slots configuration PCI slots are located on the systemboard as described in Figure 4.4 . There are 7 separate PCI Bus channels: A, B, C, D, E, F, G, and H. All PCI Bus slots provide for the full 64-bit data path and can accommodate both 32-bit and 64-bit data path cards.

  • Page 84: Installation

    All manuals and user guides at all-guides.com CHAPTER 4 M400A Main Cabinet 4.6 Installation Notes on installation:  Do not block the ventilation slits.  Do not install the M400A main cabinet where it will be exposed to sunlight or sources of heat.  Do not install the M400A main cabinet in dusty places or places where it will be exposed to corrosive gas or sea breeze.
  • Page 85 All manuals and user guides at all-guides.com 4.6 Installation Installation specifications Table 4.4 Installation Specifications of M400A Main Cabinet (1) Item Specification Mass Up to 175kg (approx.385 lb) Single phase Single phase Power condition Input voltage 100 to 120 VAC 200 to 240 VAC (+-10%) (+-10%)

  • Page 86: Table 4.4 Installation Specifications Of M400A Main Cabinet

    All manuals and user guides at all-guides.com CHAPTER 4 M400A Main Cabinet Table 4.5 Installation Specifications of M400A Main Cabinet (2) Item Specification External dimension (unit:mm) Width 500 Depth 882 Height 700 (Front of the cabinet) (Side of the cabinet) Service area (unit:mm)
  • Page 87 All manuals and user guides at all-guides.com CHAPTER 5 M400R Main Cabinet CONTENTS Overview ..................Device Configuration .

  • Page 88: Figure 5.1 Front View Of M400R Main Cabinet

    All manuals and user guides at all-guides.com CHAPTER 5 M400R Main Cabinet 5.1 Overview Appearance POWER LED (green) CHECK LED (amber) Lock Figure 5.1 Front View of M400R Main Cabinet Key Features  Up to 4 processors  Up to 32 DIMM slots, 8 gigabytes of memory.  Up to 64-bits width, 8 PCI buses provide 12 PCI slots ( 4*33/66MHz + 8*33MHz).

  • Page 89: Figure 5.2 Open View Of M400R Main Cabinet

    All manuals and user guides at all-guides.com 5.2 Device Configuration 5.2 Device Configuration The M400R main cabinet consists of the following components:  Rack-mount cabinet  Basic power supply and option redundant power supply unit  Cooling fans  Systemboard  Processor modules  DIMM (Dual Inline Memory Module)  Operator panel...

  • Page 90: Table 3.1 Fans

    All manuals and user guides at all-guides.com CHAPTER 5 M400R Main Cabinet Fans The Table 5.1 lists the fans installed in the M400R main cabinet. Table 5.1 Fans Name Tray # Location Fan #0 Tray #04 Right (front view) of the cabinet Fan #1 Fan #3 Tray #01...

  • Page 91: Figure 5.3 Rear View Of M400R Main Cabinet

    All manuals and user guides at all-guides.com 5.2 Device Configuration Rear of the M400R main cabinet AC input, power supplies (FEP) and some connectors are located on the rear of the M400R main cabinet as shown in the Figure 5.3 . 100BASE-TX PCI slot Expansion System Board...

  • Page 92: Figure 5.4 Systemboard Layout Of M400R

    All manuals and user guides at all-guides.com CHAPTER 5 M400R Main Cabinet 5.3 Systemboard Systemboard CPU module slots and memory module slots are located on Systemboard as described in Figure 5.4 . NVRAM Base System Board NVRAM Expansion System Board Figure 5.4 Systemboard Layout of M400R...
  • Page 93 All manuals and user guides at all-guides.com 5.3 Systemboard Processor Configuration Up to 4 CPU can be installed in the M400R main cabinet. When installing the processor modules, the following conditions must be satisfied:  The installed processor modules must be the same type (including the cache size).  Install a processor module in slot 0 before installing one in slot 1.

  • Page 94: Disk Units

    All manuals and user guides at all-guides.com CHAPTER 5 M400R Main Cabinet Example for normal operation === Memory =================== Type : SDRAM SLOT# Size [ Valid (MB) / Existing (MB) ] Total 00- 0- 3 256 / 256 256 / 256 256 / 256 256 / 256 : 1024 / 1024 MB...

  • Page 95: Table 2.2 Pci Slot Specifications

    All manuals and user guides at all-guides.com 5.5 PCI Slots 5.5 PCI Slots PCI slots configuration PCI slots are located on the systemboard as described in Figure 5.4 . There are 7 separate PCI Bus channels: A, B, C, D, E, F, G, and H. All PCI Bus slots provide for the full 64-bit data path and can accommodate both 32-bit and 64-bit data path cards.

  • Page 96: Installation

    All manuals and user guides at all-guides.com CHAPTER 5 M400R Main Cabinet 5.6 Installation Purpose The following installation instruction is intended to provide the product safety requirements which must be addressed when the end-use product manufacturer installs this product in their equipment. Note that the acceptability of the combination of this product in a rack should be re-determined by an appropriate certification body, if that combination is differ from the Table 5.4 .

  • Page 97: Table 5.4 Mounting Combination For Expansion Rack

    All manuals and user guides at all-guides.com 5.6 Installation IMPORTANT High Leakage Current may flow through Power Strip Earthing Conductor, if all power supply cords of this unit are connected to one Power Strip. Earth connection essential before connecting supply. Table 5.4 Mounting Combination for Expansion Rack Mounting Portion Priority in the Rack...
  • Page 98 All manuals and user guides at all-guides.com CHAPTER 5 M400R Main Cabinet Installation specifications Table 5.5 Installation Specifications of M400R Item Specification Mass Up to 65kg (approx.143 lb) Single phase Single phase Power condition Input voltage 100 to 120 VAC 200 to 240 VAC (+-10%) (+-10%)

  • Page 99: Table 5.5 Installation Specifications Of M400R

    All manuals and user guides at all-guides.com 5.6 Installation Table 5.6 Installation Specifications of M400R (2) Item Specification External dimension Width 482 Depth 814 (unit:mm) Height 307 (Front of the cabinet) (Side of the cabinet) Service area 650 *2 (unit:mm) 695 *3 Rear 1000...
  • Page 100 All manuals and user guides at all-guides.com...
  • Page 101 All manuals and user guides at all-guides.com CHAPTER 6 M600 Main Cabinet CONTENTS Overview ..................Device Configuration .

  • Page 102: Figure 6.1 Front View Of M600 Main Cabinet

    All manuals and user guides at all-guides.com CHAPTER 6 M600 Main Cabinet 6.1 Overview Appearance CHECK LED( amber ) POWER LED( green ) Lock Figure 6.1 Front View of M600 Main Cabinet Key Features  Up to 8 processors  32 DIMM slots, up to 8 gigabytes of memory.  64-bits width, 7 PCI buses provide 13 PCI slots ( 4*33/66MHz + 9*33MHz).

  • Page 103: Figure 6.2 Open View Of M600 Main Cabinet

    All manuals and user guides at all-guides.com 6.2 Device Configuration 6.2 Device Configuration The M600 main cabinet consists of the following components:  Floor stand cabinet  Basic power supply and option redundant power supply unit  Cooling fans  Systemboard, PCI IO board  Processor modules  DIMM (Dual Inline Memory Module)  Operator panel...
  • Page 104 All manuals and user guides at all-guides.com CHAPTER 6 M600 Main Cabinet Panel cover The panel cover can be opened from its right side after unlocking it. Then you can access switches on the operator panel, CD-ROM unit, Floppy drive unit, tape unit, and so on. Fans The Table 6.1 lists the fans installed in the M600 main cabinet.

  • Page 105: Figure 6.3 Rear View Of M600 Main Cabinet

    All manuals and user guides at all-guides.com 6.2 Device Configuration Table 6.2 Power Supply Units Number of CPUs Number of PCI cards 1 - 6 7 - 13 3(FEP#2) PPU2 PPU3 3(PPU#2) PPU3-io 2(PPU3#4) PPU5 2(PPU5#1) PPU12 Note: In the Table 6.2 above, ( ) indicate additional power supply unit #. Rear of the M600 main cabinet AC input, AC main line switch, power supplies (FEP) and some connectors are located on the rear of the M600 main cabinet as shown in the Figure 6.3...

  • Page 106: Figure 6.4 Systemboard Layout Of M600

    All manuals and user guides at all-guides.com CHAPTER 6 M600 Main Cabinet 6.3 Systemboard Systemboard CPU module slots and memory module slots are located on Systemboard as described in Figure 6.4 . Figure 6.4 Systemboard Layout of M600...

  • Page 107: Table 6.3 Cpu Module Configurations

    All manuals and user guides at all-guides.com 6.3 Systemboard Processor Configuration Up to 8 CPU configuration is supported as described in Table 6.3 . Table 6.3 CPU Module Configurations CPU Slot # Additional Power Supply units 2CPU 3CPU 1DDC,1FEP 4CPU 1DDC 5CPU 1DDC,1PPU...
  • Page 108 All manuals and user guides at all-guides.com CHAPTER 6 M600 Main Cabinet Checking results of the memory diagnostics To check that the system recognizes installed memory modules correctly, execute the "show-post-results" command at the ok prompt. A module that does not satisfy any condition described in "Memory configuration"...

  • Page 109: Figure 6.5 Pci Io Board Layout Of M600

    All manuals and user guides at all-guides.com 6.4 Disk Units 6.4 Disk Units Disk drive configuration Up to 2 disk drives can be installed in the base configuration of the M600 main cabinet. To install more than 3 disk drive units, the Expansion File Unit must also installed. 6.5 PCI Slots PCI slots configuration PCI slots are located on the PCI IO board as described in Figure 6.5 .

  • Page 110: Table 3.3 Pci Slot Specifications

    All manuals and user guides at all-guides.com CHAPTER 6 M600 Main Cabinet Table 6.4 PCI Slot Specifications PCI slot # PCI Bus Slot width / card PCI clock Card input voltage width (bits) (MHz) 64 / 32, 64 33/66 3.3 V or universal 64 / 32, 64 33/66 3.3 V or universal...

  • Page 111: Installation

    All manuals and user guides at all-guides.com 6.6 Installation 6.6 Installation Notes on installation:  Do not block the ventilation slits.  Do not install the M600 main cabinet where it will be exposed to sunlight or sources of heat.  Do not install the M600 main cabinet in dusty places or places where it will be exposed to corrosive gas or sea breeze.

  • Page 112: Table 6.5 Installation Specifications Of M600 Main Cabinet

    All manuals and user guides at all-guides.com CHAPTER 6 M600 Main Cabinet Installation specifications Table 6.5 Installation Specifications of M600 Main Cabinet (1) Item Specification Mass Up to 250kg (approx.552 lb) (*1) Single phase Single phase Power condition Input voltage 100 to 120 VAC 200 to 240 VAC (+-10%)

  • Page 113: Table 6.6 Installation Specifications Of M600 Main Cabinet

    All manuals and user guides at all-guides.com 6.6 Installation Table 6.6 Installation Specifications of M600 Main Cabinet (2) Item Specification External dimension (unit:mm) Width 800 Depth 900 Height 1200 (Front of the cabinet) (Side of the cabinet) Service area (unit:mm) Rear 1000 Service area...
  • Page 114 All manuals and user guides at all-guides.com...
  • Page 115 All manuals and user guides at all-guides.com CHAPTER 7 M600R Main Cabinet CONTENTS Overview ..................Device Configuration .

  • Page 116: Figure 7.1 Front View Of M600R Main Cabinet

    All manuals and user guides at all-guides.com CHAPTER 7 M600R Main Cabinet 7.1 Overview Appearance POWER LED (green) CHECK LED (amber) Lock Figure 7.1 Front View of M600R Main Cabinet Key Features  Up to 8 processors  32 DIMM slots, up to 16 gigabytes of memory.  64-bits width, 8 PCI buses provide 12 PCI slots ( 4*33/66MHz + 8*33MHz).

  • Page 117: Figure 7.2 Open View Of M600R Main Cabinet

    All manuals and user guides at all-guides.com 7.2 Device Configuration 7.2 Device Configuration The M600R main cabinet consists of the following components:  Rack-mount cabinet  Basic power supply and option redundant power supply unit  Cooling fans  Systemboard, PCIBPR board, PCIRSR board, PCIIO2 board  Processor modules  DIMM (Dual Inline Memory Module)  Operator panel...

  • Page 118: Figure 7.3 Front View Of M600R Main Cabinet (Remove Front Cover)

    All manuals and user guides at all-guides.com CHAPTER 7 M600R Main Cabinet FEP#2 FEP#3 (additional) (redundant option) Figure 7.3 Front View of M600R Main Cabinet (remove Front cover) Panel cover The panel cover can be opened from its right side after unlocking it. Then you can access switches on the operator panel, CD-ROM unit, Floppy drive unit, tape unit, and so on.

  • Page 119: Figure 7.4 Rear View Of M600R Main Cabinet

    All manuals and user guides at all-guides.com 7.2 Device Configuration Power supplies The M600R main cabinet has 2 kinds of power supply units as well as DDC (DC-DC Converter) dedicated each processor module. FEP (Front End Bulk Power) unit has AC input, and provide +45V(to PPU) and +5V(to SCF).

  • Page 120: Figure 7.5 Systemboard Layout Of M600R

    All manuals and user guides at all-guides.com CHAPTER 7 M600R Main Cabinet 7.3 Systemboard Systemboard CPU module slots and memory module slots are located on Systemboard as described in Figure 7.5 . DIMMslot A1 DIMMslot A9 DIMMslot B1 DIMMslot B9 PPU2 #0 DIMMslot A3 DIMMslot A11...

  • Page 121: Table 7.3 Cpu Module Configurations

    All manuals and user guides at all-guides.com 7.3 Systemboard Processor Configuration Up to 8 CPU configuration is supported as described in Table 7.3 . Table 7.3 CPU Module Configurations CPU Slot # Additional Power Supply units 2CPU 3CPU 1DDC,1FEP 4CPU 1DDC 5CPU 1DDC,1PPU...

  • Page 122: Disk Units

    All manuals and user guides at all-guides.com CHAPTER 7 M600R Main Cabinet Checking results of the memory diagnostics To check that the system recognizes installed memory modules correctly, execute the "show-post-results" command at the ok prompt. A module that does not satisfy any condition described in "Memory configuration"...

  • Page 123: Figure 7.6 Pcibpr Board Layout Of M600R

    All manuals and user guides at all-guides.com 7.5 PCI Slots 7.5 PCI Slots PCI slots configuration PCI slots are located on the PCIBPR board and PCIRSR board as described in Figure 7.6 and Figure 7.7 . There are 8 separate PCI Bus channels: A, B, C, D, E, F, and G. All PCI Bus slots provide for the full 64-bit data path and can accommodate both 32-bit and 64-bit data path cards.
  • Page 124 All manuals and user guides at all-guides.com CHAPTER 7 M600R Main Cabinet Table 7.4 PCI Slot Specifications PCI slot # PCI Bus Slot width / card PCI clock Card input voltage width (bits) (MHz) 64 / 32, 64 33/66 3.3 V or universal 64 / 32, 64 33/66 3.3 V or universal...

  • Page 125: Installation

    All manuals and user guides at all-guides.com 7.6 Installation 7.6 Installation Purpose The following installation instruction is intended to provide the product safety requirements which must be addressed when the end-use product manufacturer installs this product in their equipment. Note that the acceptability of the combination of this product in a rack should be re-determined by an appropriate certification body, if that combination is differ from the Table 7.4 .

  • Page 126: Table 7.5 Mounting Combination For Expansion Rack

    All manuals and user guides at all-guides.com CHAPTER 7 M600R Main Cabinet IMPORTANT High Leakage Current may flow through Power Strip Earthing Conductor, if all power supply cords of this unit are connected to one Power Strip. Earth connection essential before connecting supply.
  • Page 127 All manuals and user guides at all-guides.com 7.6 Installation Installation specifications Table 7.6 Installation Specifications of M600R Item Specification Mass Up to 100kg (approx.220 lb) Single phase Single phase Power condition Input voltage 100 to 120 VAC 200 to 240 VAC (+-10%) (+-10%) Input frequency...

  • Page 128: Table 7.6 Installation Specifications Of M600R

    All manuals and user guides at all-guides.com CHAPTER 7 M600R Main Cabinet Table 7.7 Installation Specifications of M600R (2) Item Specification External Width 482 Depth 787 dimension (unit:mm) Height 530 (Front of the cabinet) (Side of the cabinet) Service area (unit:mm) 695 *3 Rear...
  • Page 129 All manuals and user guides at all-guides.com CHAPTER 8 Expansion Disk Cabinet CONTENTS Product Outline ................Device Configuration .

  • Page 130: Product Outline

    All manuals and user guides at all-guides.com CHAPTER 8 Expansion Disk Cabinet 8.1 Product Outline Key Features  2 separate 40MB/s differential UltraSCSI connections to the host per Expansion Disk Cabinet.  Up to 5 UltraSCSI disk units can be installed per UltraSCSI bus, and up to 10 UltraSCSI disk units can be installed per Expansion Disk Cabinet.

  • Page 131: Figure 8.1 Front View Of Expansion Disk Cabinet

    All manuals and user guides at all-guides.com 8.2 Device Configuration Front View of the unit Figure 8.1 shows the front view of the cabinet. Panel Cover CHECK LED ( amber ) POWER LED ( green ) Lock Stabilizing Feet Figure 8.1 Front View of Expansion Disk Cabinet 8.2 Device Configuration The Expansion Disk Cabinet consists of the following components.

  • Page 132: Figure 8.2 Drive Bays Of Expansion Disk Cabinet

    All manuals and user guides at all-guides.com CHAPTER 8 Expansion Disk Cabinet Disk configuration The Expansion Disk Cabinet has 2 UltraSCSI buses. Up to 5 drive units can be installed in the upper drive bays of the cabinet as shown in the Figure 8.2 below. Internally, they are connected to an interface board by a single-ended UltraSCSI bus.
  • Page 133 All manuals and user guides at all-guides.com 8.2 Device Configuration status LED A POWER LED and a CHECK LED are installed on the front of the cabinet. The POWER LED indicates if the power is on or off. And, the CHECK LED indicates if there is any hardware errors or not.

  • Page 134: Figure 8.3 Rear View Of Expansion Disk Cabinet

    All manuals and user guides at all-guides.com CHAPTER 8 Expansion Disk Cabinet Rear Panel The Figure 8.3 shows the rear panel of Expansion Disk Cabinet. SCSI OUT Connector SCSI IN Connector( Option ) SCSI OUT Connector SCSI IN Connector( Standard ) Service Pin RCI Port Power Supply Unit...

  • Page 135: Table 8.2 Leds

    All manuals and user guides at all-guides.com 8.3 Hot System Replacement Do not set the AC main line switch to OFF, nor disconnect the CAUTION power cable or RCI cable while the GP7000F main cabinet is powered on, unless absolutely necessary. Otherwise, the data may be destroyed in the disk units.

  • Page 136: Installation

    All manuals and user guides at all-guides.com CHAPTER 8 Expansion Disk Cabinet 8.4 Installation Notes on installation:  Do not block the air vents.  Do not install this cabinet where it is exposed to sunlight or heat.  Do not install this cabinet in dusty places or places where it is exposed to corrosive gas or sea air.
  • Page 137 All manuals and user guides at all-guides.com 8.4 Installation Installation specifications Table 8.3 Expansion Disk Cabinet Installation Specifications (1) Item Specification Mass Up to 38kg Single phase Single phase Power condition Input voltage 100 to 120 VAC 200 to 240 VAC (+-10%) (+-10%) Input frequency...

  • Page 138: Table 8.4 Installation Specifications Of Expansion Disk Cabinet

    All manuals and user guides at all-guides.com CHAPTER 8 Expansion Disk Cabinet Table 8.4 Installation Specifications of Expansion Disk Cabinet (2) Item Specification External dimension (unit:mm) Width 230 Depth 630 Height 700 (Front View) (Side View) Service area (unit:mm) Service area Top of Service area Service area...
  • Page 139 All manuals and user guides at all-guides.com CHAPTER 9 Expansion File Unit Type-2 (GP7B7FLxx) CONTENTS Product Outline ................Device Configuration .

  • Page 140: Figure 9.1 Front View Of Expansion File Unit Type-2

    All manuals and user guides at all-guides.com CHAPTER 9 Expansion File Unit Type-2 (GP7B7FLxx) 9.1 Product Outline Key Features  2 separate 40MB/s differential UltraSCSI connections to the host per Expansion File Unit Type-2.  By adding a File Unit Expansion Kit, the Expansion File Unit can accommodate up to 10 UltraSCSI disk units (5 UltraSCSI disk units is standard).

  • Page 141: Figure 9.2 Drive Bays Of Expansion File Unit Type-2

    All manuals and user guides at all-guides.com 9.2 Device Configuration 9.2 Device Configuration This file unit consists of the following components.  Rack mount cabinet  Basic power supply and expansion option power supply (for redundant configuration)  DC-DC converter  Cooling fans (redundant configuration)  SCSI-BP boards  Interface board...

  • Page 142: Figure 9.3 Drive Bays Of Expansion File Unit Type-2

    All manuals and user guides at all-guides.com CHAPTER 9 Expansion File Unit Type-2 (GP7B7FLxx) ACTIVE LED (Green) FAULT LED (Amber) Tape Unit Bay Kit Basic SCSI Unit tape bays tape bays Figure 9.3 Drive Bays of Expansion File Unit Type-2 status LED A POWER LED and a CHECK LED are installed on the front of the cabinet.

  • Page 143: Table 9.2 Leds

    All manuals and user guides at all-guides.com 9.3 Hot System Replacement The Expansion File Unit Type-2 is not powerd on/off by only the main line switch, but it linked to power on/off of the GP7000F main cabinet. Note that this file unit does not power on if the main line switch is OFF, even if the GP7000F main cabinet is powered on.

  • Page 144: Installation

    All manuals and user guides at all-guides.com CHAPTER 9 Expansion File Unit Type-2 (GP7B7FLxx) 9.4 Installation Purpose The following installation instruction is intended to provide the product safety requirements which must be addressed when the end-use product manufacturer installs this product in their equipment. Note that the acceptability of the combination of this product in a rack should be re-determined by an appropriate certification body, if that combination is differ from the Table 9.3 .

  • Page 145: Table 9.3 Mounting Combination For Expansion Rack

    All manuals and user guides at all-guides.com 9.4 Installation IMPORTANT High Leakage Current may flow through Power Strip Earthing Conductor, if all power supply cords of this unit are connected to one Power Strip. Earth connection essential before connecting supply. Table 9.3 Mounting Combination for Expansion Rack Mounting Portion Priority in the Rack...

  • Page 146: Table 9.4 Installation Specifications Of Expansion File Unit Type-2

    All manuals and user guides at all-guides.com CHAPTER 9 Expansion File Unit Type-2 (GP7B7FLxx) Installation specifications Table 9.4 Installation Specifications of Expansion File Unit Type-2 Item Specification Mass Up to 30kg (approx.70 lb) Single phase Single phase Power condition Input voltage 100 to 120 VAC 200 to 240 VAC (+-10%)

  • Page 147: Expansion File Unit

    All manuals and user guides at all-guides.com CHAPTER 10 Expansion File Unit (GP7B7FU1xx) CONTENTS 10.1 Product Outline ................10.2 Device Configuration .

  • Page 148: Figure 10.1 Front View Of Expansion File Unit

    All manuals and user guides at all-guides.com CHAPTER 10 Expansion File Unit (GP7B7FU1xx) 10.1 Product Outline Key Features  2 separate 40MB/s differential UltraSCSI connections to the host per Expansion File Unit.  Up to 5 UltraSCSI disk units can be installed per UltraSCSI bus, and up to 10 UltraSCSI disk units can be installed per Expansion File Unit.

  • Page 149: Figure 10.2 Drive Bays Of Expansion File Unit

    All manuals and user guides at all-guides.com 10.2 Device Configuration 10.2 Device Configuration This file unit consists of the following components.  Rack mount cabinet  Basic power supply and expansion option power supply (for redundant configuration)  DC-DC converter  Cooling fans (redundant configuration)  SCSI-BP boards  Interface board...

  • Page 150: Figure 10.3 Rear View Of Expansion File Unit

    All manuals and user guides at all-guides.com CHAPTER 10 Expansion File Unit (GP7B7FU1xx) status LED A POWER LED and a CHECK LED are installed on the front of the cabinet. The POWER LED indicate if the power is on or off. And, the CHECK LED indicates if there is any hardware errors or not.

  • Page 151: Table 10.2 Leds

    All manuals and user guides at all-guides.com 10.3 Hot System Replacement Be sure to install an UltraSCSI differential terminator plug to the SCSI OUT connector. Do not set the AC main line switch to OFF, nor disconnect the CAUTION power cable or RCI cable while the GP7000F main cabinet is powered on, unless absolutely necessary.

  • Page 152: Installation

    All manuals and user guides at all-guides.com CHAPTER 10 Expansion File Unit (GP7B7FU1xx) 10.4 Installation Purpose The following installation instruction is intended to provide the product safety requirements which must be addressed when the end-use product manufacturer installs this product in their equipment. Note that the acceptability of the combination of this product in a rack should be re-determined by an appropriate certification body, if that combination is differ from the Table 10.3 .

  • Page 153: Table 10.3 Mounting Combination For Expansion Rack

    All manuals and user guides at all-guides.com 10.4 Installation IMPORTANT High Leakage Current may flow through Power Strip Earthing Conductor, if all power supply cords of this unit are connected to one Power Strip. Earth connection essential before connecting supply. Table 10.3 Mounting Combination for Expansion Rack Mounting Portion Priority in the Rack...

  • Page 154: Table 10.4 Installation Specifications Of Expansion File Unit

    All manuals and user guides at all-guides.com CHAPTER 10 Expansion File Unit (GP7B7FU1xx) Installation specifications Table 10.4 Installation Specifications of Expansion File Unit Item Specification Mass Up to 32kg (approx.70 lb) Single phase Single phase Power condition Input voltage 100 to 120 VAC 200 to 240 VAC (+-10%) (+-10%)
  • Page 155 All manuals and user guides at all-guides.com CHAPTER 11 Input-Output Units CONTENTS 11.1 Disk Units ..................11.2 Floppy Disk Units .

  • Page 156: Table 11.1 Disk Units Leds

    All manuals and user guides at all-guides.com CHAPTER 11 Input-Output Units 11.1 Disk Units Key features The following features of the disk units are applied for the GP7000F main cabinet, Expansion Disk Cabinet and Expansion File Unit.  3.5-inch UltraSCSI wide disk drive, up to 40 MB/s transfer rate.  SCA-II (Single Connector Attachment II) connector, which support hot-swap.

  • Page 157: Figure 11.1 Floppy Disk Unit Front Panel

    All manuals and user guides at all-guides.com 11.2 Floppy Disk Units When replacing the disk unit, take the following precautions. If CAUTION these precautions are not taken, the disk unit or its data may be destroyed.  Do not subject the disk unit to strong shocks.  Do not bring a device generating a strong electromagnetic field such as a motor or a loudspeaker near the disk unit.

  • Page 158: Figure 11.2 Inserting Floppy Disks

    All manuals and user guides at all-guides.com CHAPTER 11 Input-Output Units Inserting floppy disks Insert floppy disks with the label facing opposite side of the eject button as shown in Figure 11.2 . A disk has been inserted properly if a clicking sound is heard and the eject button comes out. Floppy disk unit Eject button Floppy disk...
  • Page 159 All manuals and user guides at all-guides.com 11.2 Floppy Disk Units Table 11.2 Handling Floppy Disks Keep floppy Avoid pinching disks away from floppy disks with magnets; paper clips. otherwise,disk data may corrupted. Do not expose Do not bend floppy disks to floppy disks.

  • Page 160: Figure 11.3 Cd-Rom Unit Front Panel

    All manuals and user guides at all-guides.com CHAPTER 11 Input-Output Units 11.3 CD-ROM Unit Front Panel A headphone jack is installed on the front panel, so the CD-ROM unit can also be used to enjoy music. To play music on the CD-ROM unit, install the appropriate software driver to support the audio function.

  • Page 161: Figure 11.4 Mark On Cd-Rom Disk

    All manuals and user guides at all-guides.com 11.3 CD-ROM Unit Ejecting a CD-ROM disk If the system is running, check that the disk is in use or not. If the disk is in use, the process should be killed to eject the CD-ROM disk. Note that you should warn the users beforehand, if you kill a process.

  • Page 162: Tape Unit

    All manuals and user guides at all-guides.com CHAPTER 11 Input-Output Units Use the attached small brush to remove dust from the special cleaning brush of the CD-ROM cleaning disk. Then, store the brush in the case. If the CD-ROM disk is dirty, clean it from the center to the circumference using a soft cloth. Do not clean using a circular motion.

  • Page 163: Dat Unit

    All manuals and user guides at all-guides.com 11.5 DAT Unit 11.5 DAT Unit This section describes the front panel indicators and buttons of the 4-mm DAT unit, and explains how to use the DAT unit. Setting in operating system Before using the DAT unit, the /kernel/drv/st.conf file must be modified. The modification is described below.

  • Page 164: Figure 11.5 Dat Unit Front Panel

    All manuals and user guides at all-guides.com CHAPTER 11 Input-Output Units Front Panel The DAT unit has two LEDs and Eject switch as shown in Figure 11.5 . Tape Clean 1 Eject switch 3 Attention LED 2 Active LED Figure 11.5 DAT Unit Front Panel This section describes the functions of the switches and LEDs of the DAT unit.
  • Page 165 All manuals and user guides at all-guides.com 11.5 DAT Unit Table 11.3 LED Displays on The DAT Unit LED status display Indication Active Attention (green) (Amber) No data cartridge is loaded. A data cartridge is loaded. Blinking Loading or unloading a tape, or the tape (slow) unit is being self-diagnosed.

  • Page 166: Figure 11.6 Dds Logos

    All manuals and user guides at all-guides.com CHAPTER 11 Input-Output Units IMPORTANT Never use DAT audio media. Always use computer grade media with a DDS-1, DDS-2 and DDS-3 logos as shown in Figure 11.6 or with a MRS (Media Recognition System) logo as shown in Figure 11.7 .

  • Page 167: Figure 11.9 Dat Data Cartridge Write-Protection Tab

    All manuals and user guides at all-guides.com 11.5 DAT Unit Removing a data cartridge Check that the Active LED is off (the DAT unit is not operating). Press the eject switch to rewind and unload the tape. The Active LED blinks while the tape is being rewound and unloaded.
  • Page 168 All manuals and user guides at all-guides.com CHAPTER 11 Input-Output Units  Each data cartridge has an expendable service life. If the Attention LED blinks frequently or continuously after the magnetic head has been cleaned, the life of the data cartridge has expired. Generally, replace data cartridges with new ones after they have been used 300 times.

  • Page 169: 8-Mm Tape Unit

    All manuals and user guides at all-guides.com 11.6 8-mm Tape Unit 11.6 8-mm Tape Unit This section describes front panel indicators and buttons of the 8-mm tape unit, and explains how to use the 8-mm tape unit. Setting in operating system Before using the 8-mm tape unit, the /kernel/drv/st.conf file must be modified by the following steps.

  • Page 170: Figure 11.10 8-Mm Tape Unit Front Panel

    All manuals and user guides at all-guides.com CHAPTER 11 Input-Output Units Front Panel. The 8-mm tape unit has three LEDs and an eject switch as shown in Figure 11.10 . 2 Warning LED 1 Eject switch 4 Access LED 3 Ready LED Figure 11.10 8-mm Tape Unit Front Panel 1 Eject switch...

  • Page 171: Figure 11.11 8-Mm Tape Data Cartridge

    All manuals and user guides at all-guides.com 11.6 8-mm Tape Unit Inserting a data cartridge Check that the Access LED and Ready LED are off. Do not insert a cartridge during its power-on self test. Insert the tape cartridge into the 8-mm tape unit. Be careful to insert the data cartridge in the direction indicated by the label, and push gently on the cartridge.
  • Page 172 All manuals and user guides at all-guides.com CHAPTER 11 Input-Output Units  When storing the data cartridge for a long time, ensure the storage area meets the following environmental conditions and rewrite data once a year: Temperature: 5 to 32 degree Celsius (+41 to +89.6 F) Humidity: 20 to 60% RH Maximum wet bulb temperature: 24 degree Celsius (+75.2 F)  If the ambient temperature or humidity changes rapidly, allow the data cartridge to adjust to the...

  • Page 173: Figure 11.12 Cleaning Cartridge Of The 8-Mm Tape Unit

    Replace the cleaning cartridge with a new cartridge when there is no more tape on the left reel. Use either another Fujitsu labeled cleaning cartridge or an Exabyte "Premium Cleaning Cartridge" IMPORTANT When handling the cleaning cartridge, note the following items:  Use the cleaning cartridge in the operating environment of the 8-mm tape unit.

  • Page 174: Figure 11.14 Qic Tape Drive Front Panel

    All manuals and user guides at all-guides.com CHAPTER 11 Input-Output Units 11.7 QIC Tape Unit This section describes front panel indicator and button of the QIC tape unit, and explains how to use the QIC tape unit. Front Panel The QIC tape unit has a LED and an eject button as shown in Figure 11.14 . 1 Eject button 2 Load LED 3 Door...
  • Page 175 All manuals and user guides at all-guides.com 11.7 QIC Tape Unit Tape cartridge information This tape drive uses DC 9250 or equivalent 1/4-inch tape cartridges, which have maximum storage capacity of 2.5 Gbytes. The cartridges do not require preformatting. Table 11.6 QIC Tape Cartridge Capacity Format Length...

  • Page 176: Figure 11.15 Qic Data Cartridge

    All manuals and user guides at all-guides.com CHAPTER 11 Input-Output Units Head cleaning cycle To clean the magnetic head when:  The QIC tape cartridge unit is used for eight hours or longer from the last head cleaning.  One month has passed since the last head cleaning.  Tape errors occur frequently.
  • Page 177 All manuals and user guides at all-guides.com 11.7 QIC Tape Unit When using or storing the data cartridge, take the following CAUTION precautions. If these precautions are not taken, the QIC tape unit or its data may be destroyed.  Use the data cartridge in the operating environment of the QIC tape cartridge unit.
  • Page 178 All manuals and user guides at all-guides.com...

  • Page 179: External Interfaces

    All manuals and user guides at all-guides.com CHAPTER 12 External Interfaces CONTENTS 12.1 UPS Control Interface ............... . 12.2 RS232C Interface .
  • Page 180 All manuals and user guides at all-guides.com CHAPTER 12 External Interfaces 12.1 UPS Control Interface Overview The UPS control interface is used to perform temporary data saving processing. In this processing, a reserved interruption for software occurs when the uninterruptible power supply (UPS) is used to backup a power failure in the commercial AC power supply.

  • Page 181: Table 12.2 Input Circuits

    All manuals and user guides at all-guides.com 12.1 UPS Control Interface *BPS *BTL *UPSON UPSON *ACOFF ACOFF Interface cable GP 7000 Figure 12.1 Signal Configuration Electrical requirements: The UPS control interface must meet the following electrical requirements: Table 12.2 Input Circuits Signal names Input conditions *BPS...
  • Page 182 All manuals and user guides at all-guides.com CHAPTER 12 External Interfaces 12.2 RS232C Interface Overview The RS232C interface is the interface standard adopted by EIA (Electronic Industries Association) in the USA in accordance with the CCITT (comite consultatif international telegraphique et telephonique) recommendation.

  • Page 183: Table 12.5 Definitions Of Signal Lines

    All manuals and user guides at all-guides.com 12.2 RS232C Interface Table 12.5 Definitions of Signal Lines Signal Pin Nos. on the names and Voltage levels Description I/O device side pin Nos.on the host side (DSUB25P) '0'-off '1'-on TERMINAL-25P (*1) (*1) SD: 2 +8 V -8 V...
  • Page 184 All manuals and user guides at all-guides.com CHAPTER 12 External Interfaces Connection of signal lines Figure 12.2 shows a configuration of signal line on connecting DCE device. [Send Data] [Receive Data] [Request to Send] [Clear to Send] Controller/ I/O Device adapter (DTE) [Equipment Ready]...

  • Page 185: Parallel Interface

    All manuals and user guides at all-guides.com 12.3 Parallel Interface 12.3 Parallel Interface Parallel interface The Parallel interface is based upon IEEE1284. For details of the signal line configuration and electrical standard, refer to the IEEE1284 specifications. Besides the hardware verification mentioned above, the control codes (e.g., Chinese-character code and ESC sequence) supported by the connected system must be checked before attempting to use the interface.

  • Page 186: Table 12.7 Ieee1284-A Connector Terminal Distribution (Continued)

    All manuals and user guides at all-guides.com CHAPTER 12 External Interfaces Table 12.7 IEEE1284-A Connector Terminal Distribution (Continued) Pin # Source Compatible Nibble Byte NFault nDataAvail NInit nInit NSelection 1284 Active Signal Ground (nStrobe) Signal Ground (Data 1 and Data 2) Signal Ground (Data 3 and Data 4) Signal Ground (Data 5 and Data 6) Signal Ground (Data 7 and Data 8)
  • Page 187 All manuals and user guides at all-guides.com CHAPTER 13 RCI Setting CONTENTS 13.1 Overview ..................13.2 RCI Commands .
  • Page 188 All manuals and user guides at all-guides.com CHAPTER 13 RCI Setting 13.1 Overview The remote cabinet interface (RCI) function turns on/off the power of the expansion unit along with the main unit. The RCI function also reports any error that occurring in an expansion unit to the main unit. RCI displays the current node addresses, executes initialization, and requests the binding of a new node after hot system replacement.
  • Page 189 All manuals and user guides at all-guides.com 13.3 Liquid Crystal Display (LCD) Specifications The figure below shows a setting example. ok rci-config HOST: addres: 000101ff mode: 010038a0 status: c000 LIST: address status device-class sub-class 000101ff 0001 000301ff 0100 000302ff 0201 13.3 Liquid Crystal Display (LCD) Specifications A message is displayed when the service pin of an I/O node is pressed.
  • Page 190 All manuals and user guides at all-guides.com...

  • Page 191: Troubleshooting

    All manuals and user guides at all-guides.com CHAPTER 14 Troubleshooting CONTENTS 14.1 Overview ..................14.2 Commands at the ok prompt .

  • Page 192: Table 14.1 The 'Show-Post-Results' Command

    All manuals and user guides at all-guides.com CHAPTER 14 Troubleshooting 14.1 Overview This chapter will give you some tips to isolate hardware problems of the GP7000F. The GP7000F has some hardware features to diagnose and monitor the hardware, and it makes trouble shooting easy and less time consuming.

  • Page 193: Initial Diagnosis Sequence

    All manuals and user guides at all-guides.com 14.3 Initial Diagnosis Sequence 14.3 Initial Diagnosis Sequence LCD display Sequence The LCD display sequence is shown in the Figure 14.1 . There are many patterns in the second line. But, the following example shows only some of them. SCF:initial I/O Power on diagnostic alarm...

  • Page 194: Table 14.2 Obp Error Messages

    All manuals and user guides at all-guides.com CHAPTER 14 Troubleshooting OBP Error Messages Table 14.2 shows just examples of the error messages displayed when faults are detected. Table 14.2 OBP Error Messages Message level Location of detected abnormality (2nd line) CPUn n-th processor module SLOTnn...
  • Page 195 All manuals and user guides at all-guides.com 14.4 SCF Error Messages Power Unit configuration error If there is any violation of system hardware configuration, such as insufficient power supply or DC-DC converter required by the processors, the power-on sequence will be halted. In this case, any of the following error messages will be shown on the LCD panel.
  • Page 196 All manuals and user guides at all-guides.com CHAPTER 14 Troubleshooting Power, fan, environmental alarms With a redundant configuration, if a power supply unit’s failure occurs while the system is running, the system will display a message on operating system and will continue to running. However, a message may not be displayed for a non-redundant configuration, and the system will shut down immediately.
  • Page 197 All manuals and user guides at all-guides.com 14.4 SCF Error Messages Processor Monitoring Error Messages In the power-on diagnostics, the processors, external caches, memory modules, etc. are diagnosed. If a fault is detected in the processor during the power-on diagnostics and while the system is running, the following error messages will be shown on the LCD panel.
  • Page 198 All manuals and user guides at all-guides.com CHAPTER 14 Troubleshooting Other Error Messages An abnormality of the system monitoring feature itself as well as abnormality of main cabinet are indicated by error messages on the LCD panel. Table 14.7 Other Error Messages Message level Message content Description...
  • Page 199 All manuals and user guides at all-guides.com...
