- Page 1 This Owner's Manual is provided and hosted by Appliance Factory Parts. RCA PSD3430ZWW Owner's Manual Shop genuine replacement parts for RCA PSD3430ZWW Find Your RCA Dishwasher Parts - Select From 5 Models -------- Manual continues below --------...
- Page 2 Dishwashers Owner’s Manual PSD1000 PSD2220 PSD3220 PSD3230 PSD3420 PSD3430 Part No. 165D3527P035 Pub. No. 79-5034 -1 8-97 CG...
- Page 3 Welcome to the RCA family. We’re proud of our quality products and we are committed to providing dependable service. You’ll see it in this easy-to-use manual and you’ll hear it in the friendly voices of our customer service department. Best of all, you’ll experience...
- Page 4 Safety Information ..4–7 RCA & You, A Service Partnership. Ask any RCA appliance owner and they will tell you we stand behind our products with unmatched quality service. However, did you know that most questions result from...
- Page 5 IMPORTANT SAFETY INFORMATION. READ ALL INSTRUCTIONS BEFORE USING. WARNING! For your safety, the information in this manual must be followed to minimize the risk of fire, explosion, electric shock, or to prevent property damage, personal injury, or loss of life. WATER HEATER SAFETY Under certain conditions hydrogen gas may be produced in a water heater that has not been used for two weeks or...
- Page 6 Use your dishwasher only for its intended purpose as described in this Owner’s Manual. PROPER INSTALLATION AND MAINTENANCE This dishwasher must be properly installed and located in accordance with the Installation Instructions before it is used. If you did not receive an Installation Instructions sheet with your dishwasher, you can receive one by calling us toll-free at the GE Answer Center ®...
- Page 7 IMPORTANT SAFETY INFORMATION. READ ALL INSTRUCTIONS BEFORE USING. WARNING! DO NOT… Do not tamper with controls. Do not allow children to play inside, on or with this Do not abuse, sit on, or stand appliance or any discarded on the door or dish rack of appliance.
- Page 8 WHEN USING YOUR DISHWASHER Use only powder or liquid Do not touch the heating detergents or wetting agents element during or recommended for use in a immediately after use. dishwasher and keep them Do not operate your out of the reach of children. dishwasher unless all Locate sharp items so that enclosure panels are properly...
- Page 9 About the dishwasher control panel. You can locate your model number on the tub wall just inside the door. Throughout this manual, features and appearance may vary from your model. Model PSD1000 HEATED Model PSD2220 WATER WATER SAVER SAVER POTS NORMAL NORMAL HEATED...
- Page 10 Control Settings Cycles POTS & PANS For heavily soiled dishes or cookware with dried-on or baked-on soils. Everyday dishes may be included. This cycle will not remove burned-on foods. NORMAL WASH For loads of everyday dishes, glasses and cookware with medium soils. NOTE: Many dishes have lighter soil than normal.
- Page 11 About the dial cycles. Water Saver (PSD2220, PSD3220 and PSD3230 only) For quickly washing loads of everyday dishes with light WATER SAVER soils that have not dried on. Be sure the door is unlatched. Select the NORMAL WASH cycle and any options. PLATE WARMER (HEATED DRY ON) (HEATED DRY OFF)
- Page 12 Start Delay (PSD3420 and PSD3430 only) The START DELAY will allow you to delay the start START START DELAY (HOURS) time of any cycle not on the Dial automatically for up to 6 hours. Be sure the door is unlatched. Select the wash cycle and option you want.
- Page 13 Using the dishwasher. Check the Water Temperature The entering water must be at least 120°F. and not more than 150°F., for effective cleaning and to prevent dish damage. Check the water temperature with a candy or meat thermometer. Turn on the hot water faucet nearest the dishwasher, place the thermometer in a glass and let the water run continuously into the glass until the temperature stops rising.
- Page 14 Proper Use of Detergent Use only detergent specifically made for use in dishwashers. Keep your detergent fresh and dry. Don’t put powder detergent into the dispenser until you’re ready to wash dishes. The amount of detergent to use depends on whether your water is hard or soft .
- Page 15 Loading the dishwasher racks. For best dishwashing results, follow these loading guidelines. Features and appearance of racks and silverware baskets may vary from your model. Upper Rack The upper rack is for glasses, cups and saucers. Cups and glasses fit best along the sides. This is also a secure place for dishwasher-safe plastics.
- Page 16 Lower Rack When loading the lower rack, do not load large platters or trays in the front right corner. They may prevent detergent from circulating during the wash cycle. The lower rack is best used for plates, saucers, and cookware. Large items such as broiler pans and racks should go along the sides.
- Page 17 Caring for the dishwasher. To clean the control panel use a lightly dampened cloth then dry thoroughly. To clean the exterior use a good appliance polish wax. Never use sharp objects, scouring pads or harsh cleaners on any part of the dishwasher. Protect Against Freezing If your dishwasher is left in an unheated place during the winter, ask a service technician to:...
- Page 18 Does Your Dishwasher Have an Air Gap? Two types of air gaps An air gap protects your dishwasher against water backing up into it if a drain clogs. The air gap is not a part of the dishwasher. It is not covered by your warranty.
- Page 19 About optional accessories. You can change the door and lower access panel appearance of your dishwasher by ordering one of these optional accessories: Color Panels 1/4” Wood Panel Trim Kit 3/4” Trimless Panel Kit These accessories are available at extra cost (VISA, MasterCard, or Discover cards accepted) by calling 800-626-2002.
- Page 20 Before you call for service… Troubleshooting Tips Review the charts on the following pages first and you may not need to call for service. Problem Possible Causes What To Do Replace fuse or reset Dishwasher won’t run Fuse is blown, or the •...
- Page 21 Before you call for service… Troubleshooting Tips Problem Possible Causes What To Do A small amount of clean Water standing in This is normal • water around the outlet on the bottom of the tub the tub bottom at the back of the tub keeps the water seal lubricated.
- Page 22 Problem Possible Causes What To Do Some detergents contain Stained tub interior • Detergent with colorant (pigment or dyes) colorant was used that will discolor the tub interior with extended use. Check the detergent cup for signs of any discoloration. If cup is discolored, change to detergent without any colorant.
- Page 23 Before you call for service… Troubleshooting Tips Problem Possible Causes What To Do To remove stubborn spots Spots and filming Extremely hard water • from glassware: on glasses and 1 Remove all metal flatware Low inlet water utensils from the temperature dishwasher.
- Page 24 Problem Possible Causes What To Do Remove the stain by hand, Yellow or brown film Tea or coffee stains • using a solution of 1/2 cup on tub bleach and 3 cups warm water. WARNING Before cleaning interior, wait at least 20 minutes after a cycle for the heating element to cool down.
- Page 25 Before you call for service… Troubleshooting Tips Problem Possible Causes What To Do Turn the Dial to OFF Detergent cup lid Dial is not in the OFF • and slide the door latch to won’t latch position the left. Reposition the dishes. Detergent left in Dishes are blocking the •...
- Page 26 Notes...
- Page 27 Notes...
- Page 29 Notes...
- Page 30 GE Service Protection Plus ™ GE, a name recognized worldwide for quality and dependability, offers you Service Protection Plus —comprehensive protection on ™ all your appliances —No Matter What Brand! Benefits Include: • Backed by GE • All brands covered We’ll Cover Any Appliance.
- Page 31 Consumer Product Ownership Registration Dear Customer: Thank you for purchasing our product and thank you for placing your confidence in us. We are proud to have you as a customer! Follow these three steps to protect your new appliance investment: 1 2 3 Complete and After mailing the...
- Page 32 RCA Dishwasher Warranty All warranty service provided by our Factory Service Centers, ® or an authorized Customer Care technician. For service, call 800-GE-CARES. For The Period Of: We Will Replace, At No Charge To You: Any part of the dishwasher which fails due to a defect in One Year materials or workmanship.
- Page 33 First, contact the people who serviced your appliance. Next, if you are still not pleased, write all the details—including your phone number—to: Manager, Consumer Relations, RCA Appliances, Appliance Park, Louisville, KY 40225. Finally, if your problem is still not resolved, write: Major Appliance Consumer Action Program 20 North Wacker Drive, Chicago, IL 60606.
