Elite Industries EL-211 Assembly Instructions

little spanner in t j h e hardware package when assembling. alan key in t j h e hardware package when assembling.
ASSEMBLY INSTRUCTIONS
50" WIDE TV AUDIO MOUNT WITH SWIVEL ANGLE AND HEIGHT CHANGEABLE FROM 55"-50".
OVERALL DIMENSIONS: 30" W x 5.5" D x 55"H
EL-211 : Black powder coated metal.
You can have the option to attach it to the back of any of the following models:EL-221,EL-231,EL-241.EL-251.
PARTS
IMPORTANT NOTES & CAUTIONS/WARNINGS
• Carefully read and follow these instructions for assembly.
• Please handle parts carefully, some parts may be heavy and can have sharp edges – we recommend possibly
using cloth protective gloves for extra protection.
• To protect the unit and your flooring surface we recommend working on a padded or carpeted area, you may
also use the open box the unit came in for this purpose.
• For proper construction & integrity/assembly and for TV weight support and safety, all connections need to
be sufficiently tight. However, do not over-tighten connections to the point of stripping screw threadings. Parts
477856
PLEASE CALL 1-800-ELITE-48. CUSTOMER SERVICE HOURS EASTERN TIME 8:45 AM - 4:30 PM M-F
Thank you for purchasing this Elite product. This product is tools free : Please use t j h e
PLEASE DO NOT RETURN UNIT TO STORE FOR PARTS & CUSTOMER SERVICE.
VISIT OUR WEBSITE AT: www.elite-inds.com
are designed to fit together tightly, however, avoid excessive force but rather align & fit panels together
methodically and with patience.
• For some heavy or large units, it may be recommended for 2 people to work together on this assembly.
• It is extremely important to attach the BACK PANEL as instructed within this manual. Such panels are crucial
for the stability and structural support of the unit.
• Please read additional important safety information at the end of this instruction manual.
• We urge you to keep this manual with your unit for future reference.
Page 1/3 9.11.11
