Elite Industries EL-461 Assembly Instructions

Audio Rack
EL-461 –
Genuine Natural Cherry Wood Veneer.
EL-471 –
Durable Metallic Grey Matte Lacquer.
Extra deep to accommodate high-end components. 4 levels, including 3
adjustable shelves.
Overall Dimensions: H - 48", W - 25.75" (Front), W - 22.25" (Rear), D - 23.5".
E
F
B
*IMPORTANT: Make sure shelf pin holes on Side Panels B & C face inside during assembly.
FRONT EDGES of Side Panels B & C do NOT have holes at bottom. Curved Molding (Front
Metal Molding - H) will be inserted into Front Edge of Side Panels B & C with metal tabs
facing the back of unit.
BACK EDGES of Side Panels B & C DO have holes at bottom for installation of Back Metal
Bottom Rail (F). Straight Molding (Back Metal Top Molding - E) will be inserted into Back
Edges of Side Panels B & C with metal tabs facing the back of the unit.
EL-461/EL-471 Hardware
J
Screw - 3/16 x 1-7/8 - 4 pcs.
K
Screw - 5/32 x 13/16 - 5 pcs.
L
Screw - 5/32 x 1-3/16 - 8 pcs.
M
Screw - 3/16 x 1/4 - 2 pcs.
FOR PARTS & CUSTOMER SERVICE. PLEASE CALL 1-800-ELITE-48
CUSTOMER SERVICE HOURS EASTERN TIME 8:45 AM - 4:45 PM M-F
ASSEMBLY INSTRUCTIONS EL-461/EL-471
A
G
D
Screw - 1/4 x 3/8 - 2 pcs.
Screw - 1/8 x 3/8 - 2 pcs.
PLEASE DO NOT RETURN UNIT TO STORE
H
C
N
S
T
Strap for Wire Management (4)
U
Adjustable Floor
Levellers- 4 pcs.
ALREADY FACTORY
INSTALLED
Thank you for purchasing this ELITE product.
You will need the following tools:
• Regular straight blade screw driver
• Phillips head screwdriver
• Rubber or padded hammer
In order to protect the finish, we recommend
working on a padded or carpeted surface.
Before discarding the box, be sure that no parts
are left inside.
PLEASE NOTE: The following letters correspond
to the sketches in this instruction booklet.
A. Top Panel (1)
B. Left Side Panel (1)*
C. Right Side Panel (1)*
D. Glass Shelf (4-identical)
E. Back Metal Top Molding (1)
F. Back Metal Bottom Rail (1)
G. Metal Wire Management (1)
H. Front Metal Molding (1)
Shelf Pin with
hole for screw.
2 pcs.
O
P
Shelf
Pin
14 pcs.
