Delta Electronics SMT Power Inductor SILM104 Specification Sheet

SMT Power Inductor
SILM104 & SILM106 Type
Features
RoHS compliant.
Low profile, SMD type.
Magnetically shielded, suitable for high density mounting.
High energy storage and low DCR.
Provided with embossed carrier tape packing.
Idel for power source circuits, DC-DC converter, DC-AC inverters
inductor applications.
In addition to the standard versions shown here, customized inductors
are available to meet your exact requirements.
Mechanical Dimension:
A
B

Electrical Characteristics:

L
PART NO.
(uH)
SILM104C - 0R3 0.3
SILM104B - 1R0 1.0
SILM104 - 1R5 1.5
SILM104 - 2R5 2.5
SILM104A - 3R0 3.0
SILM104 - 3R8 3.8
SILM104 - 5R2 5.2
SILM104A - 5R8 5.8
SILM104 - 7R0 7.0
SILM104 - 100 10.0
SILM104 - 150 15.0
SILM104 - 220 22.0
SILM104 - 330 33.0
SILM104 - 470 47.0
SILM104 - 680 68.0
SILM104 - 101 100.0
SILM104 - 151 150.0
SILM104 - 221 220.0
SILM104 - 331 330.0
SILM108 - 220 22.0
1. Tolerance of inductance :
2. Irated is the DC current which cause the inductance drop less than 35% of its nominal inductance without current
and the surface temperature of the part increase less than 45 C.
3. Operating temperature: -20 C to 105 C (including self-temperature rise).
DELTA ELECTRONICS, INC.
(TAOYUAN PLANT CPBG)
C
F
O
25 C : 100KHz, 0.1V
1 DCR 2
Irated
HEIGHT "C"
(m ) MAX
(Adc)
(mm)MAX
2.0 15.00
6.0 10.00
8.1 10.00
10.0 7.50
11.5 7.00
13.0 6.00
22.0 5.50
24.0 6.00
27.0 4.80
35.0 4.40
50.0 3.60
73.0 2.90
93.0 2.30
128.0 2.10
213.0 1.50
304.0 1.35
506.0 1.15
756.0 0.92
1090.0 0.70
45.0 4.00
3 0%.
o o
252, SAN YING ROAD, KUEISAN INDUSTRIAL ZONE, TAOYUAN SHIEN, 333, TAIWAN, R.O.C.
TEL: 886-3-3591968; FAX: 886-3-3591991
http://www.deltaww.com
RECOMMENDED PAD PA TTERNS
4.0
4.0
4.0
4.0
4.0
4.0
4.0
4.0
4.0
4.0
4.0
4.0
4.0
4.0
4.0
4.0
4.0
4.0
4.0
8.0
o
60
UNIT:mm/inch
A = 10 0.5 / 0.394 0.020
B = 10 0.5 / 0.394 0.020
D = 13.5 / 0.531 Max.
E = 7.2 0.3 / 0.283 0.012
F = 4.0 0.3 / 0.157 0.012
