TOLSEN TOOLS 79506A Instruction Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
79506A
HAMMER DRILL
INSTRUCTION MANUAL
SAVE THIS MANUAL !
You will need this manual for safety instructions, operating procedures and warranty.
Put it and the original sales receipt in a safe dry place for future reference.
220-240V~50/60Hz 850W

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 79506A and is the answer not in the manual?

Questions and answers

Related Manuals for TOLSEN TOOLS 79506A

Summary of Contents for TOLSEN TOOLS 79506A

  • Page 1 79506A HAMMER DRILL INSTRUCTION MANUAL 220-240V~50/60Hz 850W SAVE THIS MANUAL ! You will need this manual for safety instructions, operating procedures and warranty. Put it and the original sales receipt in a safe dry place for future reference.

  • Page 2: General Power Tool Safety Warnings

    SAFETY IMPORTANT SAFETY INFORMATION General Power Tool Safety Warnings WARNING: Read all safety warnings and instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. Save all warnings and instructions for future reference. The term ”power tool” in the warnings refers to your mains-operated (corded) power tool or battery-operated (cordless) power tool.
  • Page 3 SAFETY that have the switch on invites accidents. and/or the battery pack from the power tool 14. Remove any adjusting key or wrench before before making any adjustments, changing turning the power tool on. A wrench or a key accessories, or storing power tools. Such le attached to a rotating part of the power tool preventive safety measures reduce the risk of may result in personal injury.

  • Page 4: Hammer Drill Safety Warnings

    It must be understood by the These carry important safety information. If operator that common sense and caution are unreadable or missing, contact TOLSEN Tools factors which cannot be built into this product, for a replacement. but must be supplied by the operator.

  • Page 5: Specifications

    SPECIFICATIONS SPECIFICATIONS Electrical Rating 220-240V, 50/60Hz Input Power 850W Rotational Speed : 0-3000/min Impact Rate 0-48,000 BPM Chuck Capacity 13mm Wood Capacity 25mm Concrete Capacity 13mm Steel Capacity 13mm Note: Symbology Double Insulated WARNING mark concerning Risk of Eye Injury. Wear ANSI-approved safety goggles with side shields Read the manual before set-up and/or use.

  • Page 6: Before Use

    SETUP SETUP Before Use Read the ENTIRE IMPORTANT SAFETY INFORMATION section at the beginning of this manual including all text under subheadings therein before set up or use of this product. WARNING: TO PREVENT SERIOUS INJURY FROM ACCIDENTAL OPERATION: Release the Trigger, make sure the Trigger lock is not engaged and unplug the tool from its electrical outlet before adjusting the tool or installing accessories.

  • Page 7: Installing Auxiliary Handle

    SETUP Installing Auxiliary Handle 1. Loosen the wing nut that joins the side handle to you to hold the tool firmly and comfortably. the drill. 3. Re-tighten the wing nut. 2. Rotate the handle to a position that will allow Installing Depth Gauge Rod 1.

  • Page 8: Forward-Reverse

    GENERAL OPERATING INSTRUCTIONS GENERAL OPERATING INSTRUCTIONS This tool is designed for drilling into almost any material. For drilling into wood, metal, and plastics, use it in the regular (non-hammer) setting. For drilling holes in stone or concrete, use special masonry drill bits and the hammer setting. Operating the chuck 1.
  • Page 9 GENERAL OPERATING INSTRUCTIONS Hammer Drill Setting MODE SWITCH (TOP VIEW) HAMMER DRILL SYMBOL SYMBOL To change the drill from regular drilling to the hammer drilling, wait until the drill has stopped turning, and slide the drilling and impact mode selector switch to the right, exposing the hammer pictograph. This will cause the drill to use percussion as well as turning action.
  • Page 10 GENERAL OPERATING INSTRUCTIONS Wood Drilling Tips 1. Use high speed bits or bits specially designed 4. To prevent or reduce “break out” when bit for wood drilling, such as brad point, spade bits, penetrates work piece, clamp a piece of scrap forstner bits, etc.

  • Page 11: Maintenance And Servicing

    MAINTENANCE AND SERVICING MAINTENANCE AND SERVICING WARNING: TO PREVENT SERIOUS INJURY FROM ACCIDENTAL OPERATION: Turn off the switch and unplug the tool from its electrical outlet before performing any inspection, maintenance, or cleaning procedures. TO PREVENT SERIOUS INJURY FROM TOOL FAILURE: Do not use damaged equipment. If abnormal noise or vibration occurs, have the problem corrected before further use.

  • Page 12: Troubleshooting

    TROUBLESHOOTING Troubleshooting Problem Possible Causes Likely Solutions Tool will not 1. Cord not connected. 1. Check that cord is plugged in. start. 2. No power at outlet. 2. Check power at outlet. If outlet is 3. Tool’s thermal reset breaker unpowered, turn off tool and check circuit tripped (if equipped).

  • Page 13: Ce Declaration Of Conformity

    CE DECLARATION OF CONFORMITY SUZHOU TOLSEN TOOLS CO.,LTD. 198 HUASHAN ROAD, ZHANGJIAGANG, JIANGSU, CHINA Declare that the product Electric drills Impact Drill "Rated voltage:220-240V~ Rated frequency:50/60Hz Rated input power:900W Protection class:Ⅱ Degree of production:IPX0" Serial number: N/A Complies with the essential health and safety requirements of the following...
  • Page 14 SUZHOU TOLSEN TOOLS CO.,LTD. www.tolsentools.com TOLSEN is a trademark or registered trademark of TOLSEN TOOLS. All rights reserved. SCAN TO VISIT TolsenWorld MADE IN CHINA PRODUCT LINK...
