Summary of Contents for Defy DGS568
- Page 1 DGS568 50X60 FULL GAS STOVE Page 1 Cooking Instruction manual Part number: 074893D...
-
Page 2: Table Of Contents
SOUTH AFRICA Dear Customer, Your new Defy oven was manufactured in a state-of-the-art facility and has passed the strictest quality control procedures. Please read this manual carefully before connecting the gas bottle or using your oven for the first time and then store it within easy reach for future reference. -
Page 3: General Information
Total gas consumption 10.5 kW be included with your appliance. Oven gas consumption 2.5 kW Accessories may be purchased from Defy spares. Rear right (RR) Rear left (RL) 2000W 2000W Front right (FR) Front left (FL) -
Page 4: Important Safety Instructions
2. Important Safety Instructions This section contains safety instructions that will help you avoid risk of injury and damage. All warranties will become void if you do not follow these instructions. General safety • This appliance is not intended for use by •... -
Page 5: Safety When Working With Gas
• If odour persists contact your nearest • The use of gas cooking appliances results Defy Service Centre for assistance. in the production of heat and moisture in • If you still smell gas leave the property. -
Page 6: Setup Unpacking
LPG Gas Only: Do not install this 3. Setup appliance in a room below ground Unpacking level unless it is open to ground level on at least one side. Failure to install Please ensure that packaging material is disposed appliances correctly is dangerous of in a responsible manner. -
Page 7: Important Information
Important information Always check for gas leaks after installation and • whenever a new or refilled gas bottle is used for Upon completion of the installation ensure that you the first time. are familiar with the following: a) The position of the isolation or shut-off valve in 1. -
Page 8: Gas Conversion
The new sticker can be purchased when buying natural gas injectors from your nearest Defy Service Center. In order to have the appliance's gas type changed, all the injectors must be changed and the flame adjustment for all valves must be set at the reduced flow rate position. -
Page 9: Anti-Tilt Mechanism
Anti-tilt mechanism All stoves can tilt if you or a child sit or lean on an open oven door. Safety regulations stipulate that the ANTI-TILT mechanism supplied with the stove, must be fitted as shown. “A” 1 x Stability chain Using a 8.0 mm concrete bit, drill a hole at •... -
Page 10: Operation Instructions
4. Operation Instructions Oven operation Oven flame failure – safety cut out. (Oven only) In the unlikely event of a flame blow out, The gas oven is operated by the gas oven control caused by an overflow of fluid at the knob. -
Page 11: Gas Hobs
Gas hobs Fitting the burner caps The size of the cooking vessel and the flame must be suited to each other. Adjust the gas flames so that they do not extend past the bottom of the cooking vessel Carefully align the hole in the burner body •... -
Page 12: Maintenance And Care
Service intervals Every twelve months the appliance should be • serviced by a Defy Service agent to ensure continued efficient and safe operation. If required, the cleaning of the valves should • only be carried out by a qualified Defy technician. -
Page 13: Removing The Oven Door
6 months. This may be done using a Gas Jet Cleaning • Kit which may be purchased from your nearest Defy Service Centre. The kit comprises of a sliding T-bar (A) a • socket (B) and a ‘Classic pin’ (C). -
Page 14: Important Notes
Follow the correct lighting not a fault. been correctly followed. procedure. OVER THE YEARS, DEFY'S SERVICE CENTRES HAVE IDENTIFIED THIS LIST OF DO'S AND DON'TS AS BEING IMPORTANT FOR CUSTOMER SATISFACTION AND SAFETY. PLEASE READ IT AND FAMILIARISE YOURSELF WITH ITS CONTENTS. Don’t Clean your appliance regularly. -
Page 15: Support
If you have followed the instructions and still have a problem or have any service or spares queries, please contact the customer care line by sending an email to service@defy.co.za or by calling 0861 00 3339. They will be able to advise you on any aspect of the appliance. -
Page 16: Warranty
8. Warranty This certificate is issued by DEFY APPLIANCES (PTY) LTD manufacturers of Defy and Ocean products, hereinafter the Company, to the original purchaser only, of the appliance described on the certificate and shall constitute the only warranty given in respect of this appliance.
